Product Overview
In the production of building materials and chemical processing, achieving precise fineness is critical to the quality of the final product. Our Cement Lime Powder Making Mill is a premier industrial ball mill engineered specifically for the continuous, high-volume pulverization of cement clinker, quicklime, hydrated lime, and related industrial minerals.
This mill excels at dry grinding, transforming coarse raw materials into ultra-fine, uniform powders that meet strict international standards for cement reactivity and lime purity. Built for 24/7 heavy industrial environments, it is the cornerstone equipment for modern cement plants, mortar mixing facilities, and chemical processing lines.
Key Features & Product Benefits
● Optimized for High-Fineness Powder: The internal chamber is designed to achieve an exceptional specific surface area, ensuring that the finished cement or lime powder reacts perfectly in downstream hydration and mixing applications.
● Dual-Chamber Grinding Efficiency: Features a multi-chamber design separated by precise diaphragms. The first chamber focuses on high-impact crushing using larger steel balls, while the second chamber uses smaller balls or cylpebs to perform intensive attrition grinding for ultra-fine finishing.
● Advanced Air-Swept Openings: Engineered to seamlessly integrate with air classification systems. The continuous, dry air draft draws out qualified fine powder instantly, preventing over-grinding, reducing heat buildup within the drum, and drastically boosting throughput.
● Premium Heat & Wear Resistant Liners: Grinding cement clinker and quicklime generates significant thermal energy and friction. The mill is lined with specialized alloy steel plates that maintain their structural integrity and wear-resistance even under high continuous operating temperatures.
● Dust-Free, Eco-Friendly Operation: The fully enclosed negative-pressure sealing system prevents powder leakage into the workplace. It links directly with modern dust collectors to ensure a clean, safe, and environmentally compliant plant environment.
Dynamic Grinding Mechanism
The mill functions through a horizontal rotating cylinder driven by a robust synchronous motor and girth gear system. As the raw cement clinker or lime enters the drum, it is subjected to the kinetic energy of falling grinding media.
By utilizing a calculated balance of impact forces (to shatter coarse material) and friction forces (to smooth and polish into fine powder), the machine delivers a highly consistent particle size distribution that directly enhances the binding strength of cement and the chemical reactivity of lime.
Core Industrial Applications
This specialized powder-making mill is highly effective for processing:
● Cement Production: Raw meal grinding, cement clinker pulverization, and slag-blended cement manufacturing.
● Lime Processing: Quicklime (calcium oxide) crushing, hydrated lime production, and desulfurization lime powder preparation for power plants.
● Industrial Minerals: Gypsum, talc, calcium carbonate, fly ash, and coal powder for industrial kilns.
Complete Project & Engineering Support
We offer comprehensive turnkey solutions for cement and lime powder production lines. Beyond manufacturing the mill itself, our engineering team assists with full system integration—including material feeders, high-efficiency powder separators, bucket elevators, and bag filters. With our global spare parts warehouse and expert field technicians, we guarantee reliable lifecycle support to maximize your uptime and profitability.
Upgrade your powder production capabilities today. Contact our engineering team for a customized process layout and quotation!
Technical Specifications
| Model | Cylinder RPM (r/min) | Ball Load (t) | Feeding Size (mm) | Discharging Size (mm) | Capacity (t/h) | Motor Model | Power (kW) | Weight (t) |
| MQG600*1800 | 45.5 | 0.5 | ≤ 10 | 0.074-0.5 | 0.2-0.5 | Y160M-6 | 7.5 | 2.5 |
| MQG900*1800 | 38 | 1.8 | ≤ 20 | 0.074-0.6 | 0.8-2 | Y180L-6 | 15 | 5.8 |
| MQG900*3000 | 37.4 | 2.7 | ≤ 20 | 0.074-0.3 | 0.8-3 | Y200L2-6 | 22 | 7.5 |
| MQG1200*2400 | 32 | 4.8 | ≤ 25 | 0.074-0.6 | 1.5-4 | Y225M-6 | 30 | 9.8 |
| MQG1200*4500 | 30 | 5.2 | ≤ 25 | 0.074-0.6 | 1.5-6 | Y280S-6 | 45 | 13.2 |
| MQG1300*4000 | 36 | 5.8 | ≤ 25 | 0.074-0.6 | 2-6 | Y280S-8 | 45 | 14.8 |
| MQG1500*3500 | 28.8 | 8.3 | ≤ 25 | 0.074-0.6 | 3-6 | YR280M-8 | 90 | 17.6 |
| MQG1500*4500 | 28.8 | 10 | ≤ 25 | 0.074-0.4 | 4-8 | JR125-8 | 95 | 22.3 |
| MQG1500*5700 | 28.8 | 12 | ≤ 25 | 0.074-0.4 | 5-10 | JR126-8 | 110 | 26.7 |
| MQG1500*6400 | 28.8 | 13 | ≤ 25 | 0.074-0.4 | 8-12 | JR127-8 | 130 | 29.2 |
| MQG1830*3600 | 24.5 | 12 | ≤ 25 | 0.074-0.4 | 5-10 | JR127-8 | 130 | 31.4 |
| MQG1830*5400 | 24.5 | 15 | ≤ 25 | 0.074-0.4 | 5-20 | JR137-8 | 210 | 33.6 |
| MQG1830*6400 | 24.5 | 19 | ≤ 25 | 0.074-0.4 | 6-25 | JR137-8 | 210 | 36.5 |
| MQG1830*7000 | 24.5 | 20 | ≤ 25 | 0.074-0.4 | 8-30 | JR138-8 | 245 | 39.6 |
| MQG2100*3600 | 24.1 | 21 | ≤ 25 | 0.074-0.6 | 8-20 | YR355L1-8 | 210 | 43.2 |
| MQG2100*4500 | 24.57 | 26 | ≤ 25 | 0.074-0.6 | 8-35 | JR138-8 | 280 | 53.6 |
| MQG2200*3600 | 21.8 | 22 | ≤ 25 | 0.074-0.6 | 9-25 | JR138-8 | 245 | 47.8 |
| MQG2200*4500 | 21.4 | 27 | ≤ 25 | 0.074-0.6 | 10-30 | JR138-8 | 280 | 54.7 |
| MQG2200*7500 | 21.8 | 35 | ≤ 25 | 0.074-0.6 | 10-40 | JR158-8 | 380 | 68.4 |
| MQG2200*9000 | 21.4 | 36 | ≤ 25 | 0.074-0.6 | 10-45 | JR1510-8 | 475 | 76.5 |
| MQG2400*3600 | 21.26 | 26 | ≤ 25 | 0.074-0.6 | 10-40 | JR138-8 | 280 | 63.8 |
| MQG2400*7000 | 21.8 | 36 | ≤ 25 | 0.074-0.6 | 10-45 | JR1510-8 | 475 | 82.4 |
| MQG2400*8000 | 21.8 | 42 | ≤ 25 | 0.074-0.6 | 13-50 | JR630-8 | 560 | 85.7 |
| MQG2400*10000 | 21 | 65 | ≤ 25 | 0.074-0.6 | 15-60 | YR560-8 | 710 | 88.6 |
| MQG2600*8000 | 19.6 | 52 | ≤ 25 | 0.074-0.6 | 16-70 | JR1512-8 | 630 | 97.8 |
| MQG2700*3600 | 21.4 | 39 | ≤ 25 | 0.074-0.4 | 13-75 | JR158-8 | 380 | 86.8 |
| MQG2700*4500 | 21.4 | 43 | ≤ 25 | 0.074-0.4 | 13-90 | JR1510-8 | 475 | 91.8 |
| MQG3000*5400 | 19 | 58 | ≤ 25 | 0.074-0.6 | - | TDMK-30 | 630 | 119.7 |
| MQG3000*9000 | 18.3 | 78 | ≤ 25 | 0.074-0.4 | 20-90 | YR1000-8/1180 | 1000 | 152.4 |
| MQG3000*11000 | 18 | 100 | ≤ 25 | 0.074-0.6 | 30-90 | YR6306-8 | 1120 | 166.7 |
| MQG3200*3600 | 18.6 | 56.5 | ≤ 25 | 0.074-0.6 | 20-80 | YR6302-8 | 630 | 127.4 |
| MQG3200*4500 | 18.6 | 65 | ≤ 25 | 0.074-0.6 | 20-90 | YR6302-8 | 800 | 138.6 |
| MQG3200*5400 | 18 | 72 | ≤ 25 | 0.074-0.6 | 30-100 | YR1000-8 | 1000 | 146.7 |
| MQG3200*9000 | 18 | 85 | ≤ 25 | 0.074-0.6 | 30-100 | YR6302-8 | 1250 | 168.6 |
| MQG3600*4500 | 18 | 86 | ≤ 25 | 0.074-0.6 | 30-100 | YR6302-8 | 1250 | 158.7 |
| MQG3600*6000 | 18 | 117 | ≤ 25 | 0.074-0.6 | 45-180 | - | 14000 | 195.6 |
| MQG4000*6000 | 16.9 | 145 | ≤ 25 | 0.074-0.6 | 60-230 | - | 1800 | 221.7 |
| MQG4500*6000 | 15.6 | 180 | ≤ 25 | 0.074-0.6 | 80-300 | - | 2300 | 269.6 |
