Ball Mill With Large Diameter Sizes

Ball Mill With Large Diameter Sizes thumbnail-1
Ball Mill With Large Diameter Sizes thumbnail-2
Ball Mill With Large Diameter Sizes thumbnail-3
Ball Mill With Large Diameter Sizes thumbnail-4
Ball Mill With Large Diameter Sizes thumbnail-5
Ball Mill With Large Diameter Sizes photo-1
Ball Mill With Large Diameter Sizes photo-2
Ball Mill With Large Diameter Sizes photo-3
Ball Mill With Large Diameter Sizes photo-4
Ball Mill With Large Diameter Sizes photo-5

Product Spotlights

Capacity & Efficiency
Ultra-High Throughput
Massive Processing Capacity
Optimized Grinding Efficiency
Maximized Economy of Scale
High Reduction Ratio
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Ball Mill
Warranty:
1 year
Motor Power:
Other
Contact Supplier Request Quote Chat Now
Henan Staurk Machinery Co.,Ltd
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjing Shanghai
Delivery Detail:
30 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Ball Mill
Warranty 1 year
Motor Power Other
After-sales Service 24/7 technical support
Condition New
Motor Type AC Motor
Rotationl Speed Other
Application Mine
Materials Gold
Transport Package Standard
Specification Customized
Trademark Staurk
Origin China

Working Principle

The operation of the Large Diameter Ball Mill relies on advanced rotational mechanics. As the massive drum rotates, the specially designed internal lifters and liners carry the mixture of grinding balls and raw materials up to a precise high point. Driven by gravity, the media then cascades and cascades down in a powerful "cataracting" action.

The combination of high-impact dropping forces and continuous attrition/shearing rapidly reduces the material size. The finely ground particles are then continuously discharged through the grate or overflow trunnion, ensuring a seamless, high-yield production flow.

Why Partner With Us?

Investing in large-scale equipment requires absolute confidence. We don't just sell machinery; we deliver complete engineering peace of mind:

● Tailored Engineering: Every mill diameter and length is optimized via advanced simulation software to match your specific ore characteristics and layout constraints.

● Global Support Network: From heavy-lift installation guidance and commissioning to on-site operator training, our field engineers are ready worldwide.

● Lifecycle Parts Guarantee: We ensure a reliable, long-term supply of premium wear liners, lifters, and critical mechanical components to minimize your unplanned downtime.

Scale Up Your Operations Today

Don't let bottlenecked grinding capacity hold back your plant's potential. Upgrade to a Large Diameter Ball Mill and experience the synergy of massive scale and refined efficiency.

Technical Specifications


Model Cylinder RPM (r/min) Ball Load (t) Feeding Size (mm) Discharging Size (mm) Capacity (t/h) Motor Model Power (kW) Weight (t)
MQG600*1800 45.5 0.5 ≤ 10 0.074-0.5 0.2-0.5 Y160M-6 7.5 2.5
MQG900*1800 38 1.8 ≤ 20 0.074-0.6 0.8-2 Y180L-6 15 5.8
MQG900*3000 37.4 2.7 ≤ 20 0.074-0.3 0.8-3 Y200L2-6 22 7.5
MQG1200*2400 32 4.8 ≤ 25 0.074-0.6 1.5-4 Y225M-6 30 9.8
MQG1200*4500 30 5.2 ≤ 25 0.074-0.6 1.5-6 Y280S-6 45 13.2
MQG1300*4000 36 5.8 ≤ 25 0.074-0.6 2-6 Y280S-8 45 14.8
MQG1500*3500 28.8 8.3 ≤ 25 0.074-0.6 3-6 YR280M-8 90 17.6
MQG1500*4500 28.8 10 ≤ 25 0.074-0.4 4-8 JR125-8 95 22.3
MQG1500*5700 28.8 12 ≤ 25 0.074-0.4 5-10 JR126-8 110 26.7
MQG1500*6400 28.8 13 ≤ 25 0.074-0.4 8-12 JR127-8 130 29.2
MQG1830*3600 24.5 12 ≤ 25 0.074-0.4 5-10 JR127-8 130 31.4
MQG1830*5400 24.5 15 ≤ 25 0.074-0.4 5-20 JR137-8 210 33.6
MQG1830*6400 24.5 19 ≤ 25 0.074-0.4 6-25 JR137-8 210 36.5
MQG1830*7000 24.5 20 ≤ 25 0.074-0.4 8-30 JR138-8 245 39.6
MQG2100*3600 24.1 21 ≤ 25 0.074-0.6 8-20 YR355L1-8 210 43.2
MQG2100*4500 24.57 26 ≤ 25 0.074-0.6 8-35 JR138-8 280 53.6
MQG2200*3600 21.8 22 ≤ 25 0.074-0.6 9-25 JR138-8 245 47.8
MQG2200*4500 21.4 27 ≤ 25 0.074-0.6 10-30 JR138-8 280 54.7
MQG2200*7500 21.8 35 ≤ 25 0.074-0.6 10-40 JR158-8 380 68.4
MQG2200*9000 21.4 36 ≤ 25 0.074-0.6 10-45 JR1510-8 475 76.5
MQG2400*3600 21.26 26 ≤ 25 0.074-0.6 10-40 JR138-8 280 63.8
MQG2400*7000 21.8 36 ≤ 25 0.074-0.6 10-45 JR1510-8 475 82.4
MQG2400*8000 21.8 42 ≤ 25 0.074-0.6 13-50 JR630-8 560 85.7
MQG2400*10000 21 65 ≤ 25 0.074-0.6 15-60 YR560-8 710 88.6
MQG2600*8000 19.6 52 ≤ 25 0.074-0.6 16-70 JR1512-8 630 97.8
MQG2700*3600 21.4 39 ≤ 25 0.074-0.4 13-75 JR158-8 380 86.8
MQG2700*4500 21.4 43 ≤ 25 0.074-0.4 13-90 JR1510-8 475 91.8
MQG3000*5400 19 58 ≤ 25 0.074-0.6 - TDMK-30 630 119.7
MQG3000*9000 18.3 78 ≤ 25 0.074-0.4 20-90 YR1000-8/1180 1000 152.4
MQG3000*11000 18 100 ≤ 25 0.074-0.6 30-90 YR6306-8 1120 166.7
MQG3200*3600 18.6 56.5 ≤ 25 0.074-0.6 20-80 YR6302-8 630 127.4
MQG3200*4500 18.6 65 ≤ 25 0.074-0.6 20-90 YR6302-8 800 138.6
MQG3200*5400 18 72 ≤ 25 0.074-0.6 30-100 YR1000-8 1000 146.7
MQG3200*9000 18 85 ≤ 25 0.074-0.6 30-100 YR6302-8 1250 168.6
MQG3600*4500 18 86 ≤ 25 0.074-0.6 30-100 YR6302-8 1250 158.7
MQG3600*6000 18 117 ≤ 25 0.074-0.6 45-180 - 14000 195.6
MQG4000*6000 16.9 145 ≤ 25 0.074-0.6 60-230 - 1800 221.7
MQG4500*6000 15.6 180 ≤ 25 0.074-0.6 80-300 - 2300 269.6
