Help CenterQUECTEL SC200L-CE、SC200L-EM、SC200L-EU Cat4 4G Smart Module
Related Products
-
QUECTEL SC20ESC-8GB-UGND SC20AUSC-8GB-UGND SC20AUSA-8GB-STD SC20JSA-8GB-STD Cat4 4G Smart ModuleUS$ 70 - 90MOQ: 1 Unit -
Telit 4G Module LE910-NA1US$ 60 - 70MOQ: 1 Piece
-
Telit 4G Module LE910-EU1US$ 60 - 80MOQ: 1 Piece
-
Telit 4G Module LE910C4-NFUS$ 70 - 80MOQ: 1 Piece
-
SIERRA AR7586US$ 30 - 35MOQ: 2 Pieces
LTE Cat 4 intelligent module
40.5 mm × 40.5 mm × 2.85 mm
About 10.2 g
LCC LGA packaging
Operating temperature: -30 °C ~ 75 °C
Deploy Lux quad-core 64-bit ARM Cortex-A53 processor
Equipped with the ARM Mali T820 high-performance graphics engine
Android 10 / Linux* operating system
Bluetooth 4.2
Supports 1080 P @ 30 fps video playback
Integrated multi-constellation GNSS receiver
The SC200L series is a multi-network intelligent LTE Cat 4 module launched by Quectel Wires based on the Zenrui quad-core 64-bit ARM Cortex-A53 processor, featuring a built-in ARM Mali-T820 high-performance graphics engine and running Android 10/Linux* operating systems. This series of modules is powerful and rich in multimedia functions, meeting customers' demands for high speed and multimedia capabilities in industrial and consumer applications. The SC200L series includes two versions: SC200L-CE and SC200L-EM.
The SC200L series integrates a wide range of features (such as LCM, camera, touchscreen, microphone, speaker, UART, USB, I2C, and SPI interfaces), expanding its applications in the M2M field, making it widely used in smart cash registers, smart POS, smart security, in-vehicle devices, high-end information collection devices, smart robots, smart homes, smart hardware, industrial smart handheld devices, drones, audio and video recorders, smart intercom devices, smart wearables, Vending machines, logistics cabinets, and other fields.
Introduction to SC200L:
The SC200L series is a multi-network intelligent LTE Cat 4 module launched by Quectel Wires based on the Zenrui quad-core 64-bit ARM Cortex-A53 processor, featuring a built-in ARM Mali-T820 high-performance graphics engine and running Android 10/Linux* operating systems. This series of modules is powerful and rich in multimedia functions, meeting customers' demands for high speed and multimedia capabilities in industrial and consumer applications. The SC200L series includes two versions: SC200L-CE and SC200L-EM.
The SC200L series supports Multiple Input Multiple Output (MIMO) technology, allowing multiple receiving antennas at the receiving end to allow signals to be received through multiple antennas, thereby improving download speeds, reducing bit error rates, and enhancing communication quality. At the same time, the module supports GPS GLONASS or GPS BDS positioning systems, enabling fast and precise positioning. The SC200L series integrates feature-rich interfaces such as LCM, camera, touchscreen, microphone, speaker, and U ...
