As a leading manufacturer with over a decade of expertise, Qingdao Yongke Machinery Co., Ltd. proudly presents our advanced HDPE Helically Wound Tank Machine. This state-of-the-art equipment is engineered to empower businesses in producing robust, leak-proof, and corrosion-resistant storage solutions essential for the demanding chemical industry. Our commitment to quality, backed by ISO9001, ISO14000, and OHSAS18001 certifications, ensures that every machine delivers precision, reliability, and long-term value for your production line, helping you meet the stringent requirements of global markets from North America to Southeast Asia.
Our HDPE Helically Wound Tank Machine is designed for high-efficiency, continuous production of large-capacity storage tanks. The helical winding process creates a seamless, monolithic structure, significantly enhancing the tank's structural integrity and chemical resistance compared to traditional methods. This machine is the cornerstone for fabricating tanks that safely store a wide range of industrial chemicals, acids, alkalis, and wastewater.
Key Features and Technical Advantages:
- Seamless Construction: The continuous helical winding technique eliminates longitudinal seams, which are common failure points, resulting in a tank with superior strength and leak resistance.
- Precision Winding Control: Equipped with a sophisticated PLC and touchscreen HMI, the machine ensures consistent wall thickness, precise filament placement, and repeatable quality across all production runs.
- High Production Capacity: Engineered for 24/7 operation, it enables the manufacture of large-diameter and tall tanks (commonly up to 5 meters in diameter and 15 meters in height) to meet diverse storage needs.
- Material Efficiency: Optimizes the use of high-density polyethylene (HDPE) material, reducing waste and controlling raw material costs while maintaining product integrity.
- Customizable Configurations: We offer semi-automatic and fully automatic models to suit different production scales and investment levels. Key parameters like winding speed, pitch, and layer count are fully adjustable.
- Durability and Low Maintenance: Built with high-grade steel frames and industrial-grade components, the machine is designed for longevity with minimal downtime, ensuring a high return on investment.
The machine's technical specifications can be tailored, but a standard configuration includes the following core parameters:
| Parameter | Specification / Capability |
| Tank Diameter Range | Customizable, typically 1000 - 5000 mm |
| Tank Height Range | Customizable, typically up to 15000 mm |
| Winding Speed | Adjustable, optimized for material and design |
| Control System | Programmable Logic Controller (PLC) with Human-Machine Interface (HMI) |
| Power Requirements | Standard: 380V, 50Hz (Customizable for other standards) |
| Machine Footprint | Varies with model; design considers factory space efficiency |
For your business, this translates into tangible benefits: the ability to produce high-margin, custom-sized tanks on demand, reducing reliance on external suppliers and lead times. You gain a competitive edge by offering tanks with proven longevity and safety for corrosive chemicals. Furthermore, the efficiency of the machine helps lower your per-unit production cost, improving overall profitability.
Trust in our proven track record. Operating from a 10,000-30,000 square meter facility with a dedicated team of 51-100 professionals, we have consistently delivered reliable machinery to clients across six continents, achieving an annual export value of US$1-1.5 Million. Our machines are shipped globally from the Port of Qingdao, supported by a comprehensive international logistics network. Investing in our HDPE Helically Wound Tank Machine means partnering with a certified manufacturer dedicated to your production success. Contact us today to discuss how this machine can be customized for your specific chemical storage tank manufacturing requirements and to receive a detailed quotation.
Frequently Asked Questions (FAQ):
-
What is the main advantage of a helically wound tank over a vertically welded one?
Helically wound tanks are seamless in the longitudinal direction, which distributes stress more evenly and eliminates the weak points associated with long vertical welds. This results in superior structural strength, better leak resistance, and enhanced performance under chemical and pressure loads. -
Can this machine use different grades of HDPE or other plastics?
The machine is primarily designed for high-quality HDPE suitable for chemical storage. The use of alternative polyethylene grades or composite materials can be explored based on specific project requirements and should be discussed during the customization phase. -
What level of training is provided with the machine?
We provide comprehensive operational and maintenance training at your site after installation. This includes hands-on instruction for your technicians on machine setup, programming, routine maintenance, and basic troubleshooting. -
How is the wall thickness of the tank controlled during production?
Wall thickness is precisely controlled through the PLC system, which regulates the speed of the winding carriage and the extrusion/output of the HDPE material. Multiple layers can be wound to achieve the desired total thickness and mechanical properties. -
What is the typical lead time for delivery and installation?
Lead time depends on the machine model and customization level. Standard models typically have a shorter lead time. A detailed production and delivery schedule will be provided upon order confirmation, factoring in manufacturing, testing, and shipping from Qingdao port. -
Do you offer after-sales support and spare parts?
Yes, we provide reliable after-sales technical support and maintain an inventory of critical spare parts. Remote assistance is available, and on-site service can be arranged if needed to ensure minimal disruption to your production. -
Can the machine produce tanks with different end configurations (e.g., flat bottom, conical bottom)?
Absolutely. The machine produces the cylindrical shell. The end caps (flat, conical, dished) are typically manufactured separately using other processes like rotational molding or thermoforming and are then welded to the shell. We can advise on complete tank fabrication solutions. -
What factory utilities are required for installation?
The main requirements are a stable three-phase electrical supply (e.g., 380V/50Hz), a level and solid concrete foundation, and adequate space for material handling and the finished tank. Compressed air may be needed for certain auxiliary functions. Detailed site requirements are provided in the pre-installation manual.
