As a leading manufacturer with over a decade of expertise, Qingdao Yongke Machinery Co., Ltd. proudly presents our advanced High-Speed HDPE Hollow Wall Winding Spiral Sewage Pipe Extrusion Line. Engineered for superior performance and reliability, this production line is specifically designed to manufacture high-quality, durable HDPE spiral wound pipes essential for modern sewage systems, storage tanks, and large-scale drainage projects. Our commitment to innovation and quality, backed by ISO certifications, ensures that our equipment delivers exceptional value, helping our clients worldwide to enhance their production capabilities and meet stringent infrastructure demands efficiently.
This extrusion line integrates cutting-edge technology to produce pipes with excellent mechanical properties, corrosion resistance, and long service life. The hollow wall structure significantly reduces material usage while maintaining high ring stiffness, making the final pipes both cost-effective and structurally sound for demanding underground and above-ground applications.
Key Features and Technical Advantages:
High-Efficiency Production: The line is designed for continuous, high-speed operation, maximizing output and reducing production cycle times. The winding process is precisely controlled to ensure consistent pipe quality.
Precision Winding Technology: Utilizes advanced servo or frequency conversion drive systems to achieve precise control over the winding angle, pitch, and wall thickness, resulting in pipes with uniform dimensions and superior structural integrity.
Intelligent Control System: A centralized PLC with a user-friendly touch screen interface allows for easy parameter setting, real-time monitoring, fault diagnosis, and production data recording, ensuring stable and automated operation.
Robust Construction & Durability: Built with high-grade components and a sturdy frame, the machine is designed for 24/7 operation in industrial environments, ensuring long-term reliability and minimal maintenance.
Energy-Saving Design: Incorporates efficient heating and cooling systems to optimize energy consumption, reducing operational costs and environmental impact.
Versatility in Production: Capable of producing a wide range of pipe diameters and wall thicknesses by changing molds and adjusting parameters, offering great flexibility to meet diverse project specifications.
Technical Specifications Table:
| Parameter | Specification / Capability |
|---|---|
| Applicable Material | HDPE Granules (PE80, PE100) |
| Produced Pipe Diameter Range | Typically 200 mm to 3000 mm (Customizable) |
| Wall Thickness Range | Adjustable, depending on diameter and application |
| Main Drive Power | Configured based on pipe size and speed requirement |
| Control System | PLC with Touch Screen HMI |
| Heating Method | Electric Heating with PID Control |
| Cooling Method | Water Cooling or Forced Air Cooling |
| Machine Footprint | Varies with configuration, detailed layout available upon request |
Benefits for Your Business:
Enhanced Productivity: Streamline your pipe manufacturing process with automated, high-speed production, leading to increased output and faster order fulfillment.
Superior Product Quality: Produce HDPE spiral pipes with excellent dimensional accuracy, consistent wall thickness, and high ring stiffness, meeting or exceeding industry standards for sewage and drainage applications.
Material and Cost Savings: The hollow wall design optimizes material use, lowering raw material costs per meter of pipe without compromising performance.
Operational Simplicity: The intuitive control system reduces the need for highly specialized operators and minimizes human error, ensuring smooth production runs.
Reliable After-Sales Support: Backed by our experienced technical team, we provide comprehensive installation guidance, operator training, and spare parts support to ensure your production line runs smoothly for years.
With a strong foundation since 2010, operating from a modern factory spanning 10,000-30,000 square meters, and an annual export value reaching US$1.5 Million, Qingdao Yongke Machinery has established itself as a trusted partner for industries across North America, South America, Europe, Asia, Africa, and Oceania. Our ISO9001, ISO14000, and OHSAS18001 certifications are a testament to our unwavering commitment to quality management, environmental responsibility, and occupational health and safety. This extrusion line embodies our dedication to providing robust, efficient, and value-driven machinery. We invite you to contact us to discuss how this High-Speed HDPE Hollow Wall Winding Spiral Sewage Pipe Extrusion Line can become a cornerstone of your production facility, delivering reliable performance and a strong return on investment.
Frequently Asked Questions (FAQ):
What is the main advantage of the hollow wall structure in the produced pipes?
The hollow wall design provides high ring stiffness and pressure resistance while using less raw material compared to solid wall pipes. This results in a lighter, more cost-effective pipe that is easier to transport and install, without sacrificing performance for sewage and drainage applications.Can this line produce pipes for purposes other than sewage?
Absolutely. While optimized for sewage pipes, this line is highly versatile. It can produce HDPE spiral wound pipes suitable for various applications, including industrial drainage, culverts, stormwater management, and as liners for storage tanks or silos.How is the production speed controlled and what is the typical output?
Production speed is precisely controlled through the PLC system and drive motors. The actual output (meters per hour) depends on the target pipe diameter, wall thickness, and material grade. Specific output data for your required specifications can be provided upon request.What kind of training and technical support do you provide after purchase?
We provide comprehensive support, including detailed machine manuals, on-site or remote installation guidance, hands-on operator training, and ongoing technical consultation. Our team is available to assist with troubleshooting and optimization.Are the key components like PLC and motors from reputable brands?
Yes, we use internationally recognized brands for critical components such as PLCs, servo drives, and motors (e.g., Siemens, Mitsubishi, ABB, or equivalent) to ensure reliability, precision, and ease of maintenance. Specific brand preferences can be discussed during customization.Is it possible to customize the line for a specific pipe diameter outside the standard range?
Yes, customization is a core strength. We can engineer and manufacture the extrusion and winding heads, molds, and supporting equipment to meet specific diameter, wall thickness, or special profile requirements for your projects.What are the power requirements for operating this production line?
Power requirements vary based on the machine configuration and production capacity. We will provide detailed electrical specifications, including total connected load and voltage requirements (e.g., 380V/50Hz or 440V/60Hz), during the quotation process based on your needs.How do you ensure consistent pipe quality throughout a production run?
Consistency is achieved through multiple factors: precise temperature control in extrusion, stable material feeding, high-precision servo winding control, and integrated online monitoring systems that track key parameters and alert operators to any deviations.
