As a professional manufacturer, Jiangsu Manqi Machinery Co., Ltd., established in 2017, specializes in producing high-performance geared motors for global industrial markets. Our R77 Coaxial Helical Geared Motor with Cast Iron Housing is engineered to meet IEC standards, offering a reliable and robust solution for demanding transmission applications. Operating from a modern facility in Suzhou, we combine precision manufacturing with stringent quality control to deliver products that enhance operational efficiency and durability for our clients in Eastern Europe, Southeast Asia, Africa, and South Asia.
This geared motor integrates a helical gear set within a sturdy cast iron housing, providing superior strength and resistance to shock loads. The coaxial (inline) design ensures a compact footprint, simplifying installation and saving space in your machinery layout. It is a versatile component designed to transmit power smoothly and efficiently in various industrial settings.
Key Features & Technical Advantages:
- Robust Cast Iron Housing: Offers excellent mechanical strength, vibration damping, and long-term durability under harsh operating conditions.
- Helical Gear Design: Provides smooth, quiet operation with high efficiency and increased load-carrying capacity compared to spur gears.
- Coaxial Configuration: Input and output shafts are aligned, creating a compact, space-saving design ideal for integrated systems.
- IEC Standard Compliance: Designed to align with international electrical and mechanical standards, facilitating compatibility and global acceptance.
- High Transmission Efficiency: Minimizes energy loss, contributing to lower operational costs and improved system performance.
- Customizable Options: Available in various power ratings, torque outputs, and mounting configurations (foot or flange) to match specific application requirements.
Technical Specifications & Parameters:
| Parameter | Description / Range |
| Model Series | R77 |
| Housing Material | Cast Iron |
| Gear Type | Helical |
| Mounting Type | Coaxial (Inline) |
| Standard Reference | IEC Standard Transmission |
| Typical Applications | Conveyor Systems, Mixing Equipment, Agitators, Industrial Drives |
| Input Power Compatibility | Standard IEC motor frames (details available upon request) |
| Output Speed Range | Customizable via gear ratio selection |
Benefits for Your Business:
- Enhanced Reliability: The durable construction reduces failure rates, minimizing downtime and maintenance costs.
- Operational Efficiency: High gear efficiency translates to lower energy consumption for your driven equipment.
- Space Optimization: The compact coaxial design allows for more efficient machine layout and design.
- Global Compatibility: Adherence to IEC standards ensures easier integration into international projects and supply chains.
- Long Service Life: Cast iron housing and hardened helical gears provide extended operational life even in tough environments.
Jiangsu Manqi Machinery supports its products with a solid manufacturing foundation. Our 10,000-30,000 square meter factory enables scalable production, and our team of 11-50 dedicated employees focuses on quality and precision. We have successfully served markets across Eastern Europe, Southeast Asia, Africa, and South Asia, with shipments efficiently handled via the Port of Shanghai. This R77 Geared Motor represents our commitment to delivering robust, standardized transmission components that meet the needs of industrial buyers seeking dependable performance. For detailed specifications, torque curves, or custom requirements, please contact us to discuss how this product can be tailored to your application.
Frequently Asked Questions (FAQ):
-
What does "coaxial" mean in this geared motor?
Coaxial, or inline, means the input shaft (motor side) and the output shaft (load side) are on the same centerline axis. This creates a straight-line, compact drive package. -
Why is cast iron used for the housing?
Cast iron provides high rigidity, excellent resistance to deformation under load, and good vibration damping properties, making it suitable for heavy-duty industrial applications. -
How does a helical gear differ from other gear types?
Helical gears have teeth cut at an angle (helix), which allows for smoother, quieter engagement and can transmit higher loads compared to straight-cut spur gears. -
What are the advantages of complying with IEC standards?
IEC standards ensure dimensional, performance, and safety compatibility with motors and equipment globally, simplifying procurement and system integration. -
Can this geared motor be customized for specific speed or torque requirements?
Yes. We can customize the gear ratio within the R77 series to achieve your desired output speed and torque. Specific power ratings and mounting options are also available. -
What typical industries or applications use this R77 geared motor?
Common applications include conveyor drives, mixing and stirring equipment, packaging machinery, material handling systems, and various industrial automation drives. -
What maintenance is required for this geared motor?
Regular lubrication according to specifications is key. The robust design requires minimal maintenance, but periodic checks for wear and seal integrity are recommended. -
How is the motor typically shipped, and what are the lead times?
Products are shipped from the Port of Shanghai. Lead times depend on order specifications and quantity; standard models may have shorter availability.
