Power Electronic Coil for Steel Plant Induction Heating Systems 1500KVA
Product Spotlights
High-power 1500KVA induction coil engineered for steel plants. Features high-purity copper construction, efficient water-cooling, and H-class insulation for reliable operation in harsh environments. Customizable design ensures optimal heating performance, boosting productivity and energy efficiency. Manufactured under ISO9001 standards for consistent quality, suitable for global export.
US$ 1500
≥1 Piece
Key Specifications
Get Latest Price
Application:
Other, Steel Plant Induction Heating Systems
Rated Power Capacity:
1500 KVA
Material:
High-Purity Copper Conductor
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
12KV/35KV Outdoor Vacuum Circuit Breaker With Spring Operating Mechanism for Power DistributionUS$ 999MOQ: 10 Units -
35KV High Voltage Vacuum Circuit Breaker for Wind and Solar Power Generation SystemsUS$ 999MOQ: 10 Units
-
12KV Outdoor Vacuum Circuit Breaker for Mining and Heavy Industrial ApplicationsUS$ 999MOQ: 10 Units
-
Outdoor High Voltage Vacuum Circuit Breaker AC 50Hz 12KV/35KV Three Phase 20KA Breaking CapacityUS$ 999MOQ: 10 Units
-
12KV Outdoor Vacuum Circuit Breaker With Detailed Installation Guide and Technical SupportUS$ 999MOQ: 10 Units
Application
Other, Steel Plant Induction Heating Systems
Rated Power Capacity
1500 KVA
Material
High-Purity Copper Conductor
Insulation Class
H Class (180°C)
Cooling Method
Water-Cooled (Standard)
Certification
ISO9001 Quality Management System
Customization
Available upon request
Core Type
Custom-designed for induction heating
As a professional manufacturer of electrical equipment, Jinhua Dika Electrical Equipment Co., Ltd. specializes in providing robust and efficient solutions for demanding industrial applications. Our Power Electronic Coil for Steel Plant Induction Heating Systems is engineered to meet the rigorous demands of modern steel production, delivering reliable performance and enhanced thermal efficiency. With over a decade of experience and a commitment to quality backed by our ISO9001 certification, we design this 1500KVA coil to be the heart of your induction heating process, ensuring consistent, high-quality heating for critical steel forming and treatment operations.
This power electronic coil is not just a component; it's a precision tool designed to optimize your steel plant's energy consumption and operational throughput. Its robust construction and advanced design translate directly into reduced downtime, lower maintenance costs, and improved product quality for your finished steel products.
Key Features & Technical Advantages:
- High-Efficiency Design: Optimized electromagnetic design minimizes energy losses, ensuring maximum power is transferred to the workpiece, leading to faster heating cycles and reduced electricity costs.
- Exceptional Thermal Management: Utilizing a high-purity copper conductor and a forced water-cooling system, the coil maintains stable temperatures even under continuous, high-power operation, preventing thermal degradation and extending service life.
- Robust Construction for Harsh Environments: Built with industrial-grade materials and H-class insulation, the coil is resistant to thermal shock, vibration, and the aggressive atmosphere typical in steel plants, ensuring long-term reliability.
- Customizable Geometry: While we offer standard designs, our engineering team can tailor the coil's shape, size, and inductance to match your specific furnace geometry and heating requirements, ensuring optimal performance for your unique application.
- Precision Manufacturing: Every coil undergoes rigorous quality control checks, including electrical testing and pressure testing of the cooling circuit, to guarantee performance and safety standards are met before shipment.
Detailed Technical Specifications:
| Parameter | Specification |
| Rated Power | 1500 KVA |
| Rated Frequency | Customizable (e.g., 50Hz - 10kHz typical range) |
| Primary Conductor Material | High-Purity, High-Conductivity Copper |
| Insulation System | Class H (180°C), Mica-based or equivalent |
| Cooling System | Internal Water Cooling Channels, Standard |
| Cooling Water Pressure | Typically 0.3 - 0.6 MPa (Configurable) |
| Electrical Connections | Heavy-Duty Copper Busbars or Flexible Braids |
| Mechanical Protection | Stainless Steel or Powder-Coated Steel Structural Support |
Benefits for Your Steel Plant Operation:
- Increased Productivity: Efficient and rapid heating reduces cycle times, allowing for higher throughput in billet heating, slab reheating, or heat treatment processes.
- Improved Energy Efficiency: The optimized design directly lowers your kWh consumption per ton of heated steel, contributing to significant operational cost savings.
- Enhanced Process Control: Provides uniform and repeatable heating profiles, leading to consistent metallurgical properties and superior quality in the final steel product.
- Reduced Maintenance Downtime: The durable construction and effective cooling system minimize failures, leading to longer intervals between maintenance and higher overall equipment availability.
Frequently Asked Questions (FAQ):
-
What is the typical lead time for a standard 1500KVA coil?
Lead times vary based on order complexity and current production schedule. For standard designs, typical lead time is 4-6 weeks. Custom designs may require additional engineering time. -
Can this coil be designed for a specific frequency outside the typical range?
Yes. As a manufacturer with strong R&D capabilities, we can design and produce coils optimized for specific frequency requirements of your induction power supply. -
What water quality is required for the cooling system?
We recommend using deionized or soft water to prevent scaling and corrosion inside the cooling channels. Specific water quality parameters will be provided in the installation manual. -
Do you provide installation support or technical drawings?
Yes, we provide detailed CAD drawings, installation manuals, and can offer remote or on-site technical support to assist with integration into your existing system. -
How does the ISO9001 certification impact product quality?
Our ISO9001 certified quality management system ensures consistent processes from material sourcing to final testing. This systematic approach minimizes defects and ensures every coil meets the specified performance criteria. -
What are the main failure modes, and how are they mitigated?
Common concerns include insulation breakdown and cooling blockages. We mitigate these through high-grade insulation materials, robust impregnation processes, and clear design of cooling channels with accessible inspection points. -
Is the coil compatible with different induction heater brands?
Our coils are designed to be electrically compatible with standard industrial induction power supplies. We require your power supply specifications (voltage, current, frequency) to ensure a perfect match. -
What is your packaging method for safe overseas shipment?
Coils are securely mounted within a wooden crate with waterproof and shock-absorbing materials. This packaging is suitable for long-distance sea freight to our global markets, including North America, Europe, and Southeast Asia.
Trust in a partner with a proven track record. Jinhua Dika Electrical Equipment Co., Ltd. exports its industrial-grade electrical components to a wide range of markets across the globe, demonstrating international acceptance and reliability. Our team of 11-50 dedicated professionals is focused on delivering solutions that perform under pressure. This 1500KVA Power Electronic Coil embodies our commitment to quality and efficiency, designed to be a durable and high-performing asset for your steel plant. Contact us today to discuss your specific requirements and experience the difference that a professionally engineered induction heating coil can make for your productivity and bottom line.
