**Technical Specification and Description for Honeywell Enraf S0690915 Power Board**
**General Description**
The Honeywell Enraf S0690915 Power Board is a critical component designed for integration within the Honeywell Enraf tank gauging and inventory management systems. This printed circuit board (PCB) functions as the primary power distribution and regulation unit, converting raw input power into the regulated voltages necessary for the operation of connected processor boards, communication modules, and sensor interfaces. It is engineered for high reliability in continuous, 24/7 industrial applications, ensuring stable performance in demanding environments such as oil terminals, refineries, and chemical storage facilities.
**Electrical Specifications**
The board accepts a wide range of AC or DC input voltages, typically rated for 100-240 VAC or 24-48 VDC to accommodate various site power infrastructures. It provides multiple regulated output rails, primarily +5 VDC and +24 VDC, with precise tolerance levels to support digital logic and analog sensor circuits. The power output is rated for a maximum continuous power delivery, commonly up to 50 Watts, depending on the system configuration. The unit includes built-in overcurrent protection, short-circuit protection, and thermal shutdown features to safeguard both the power board and downstream equipment.
**Physical and Environmental Characteristics**
The S0690915 Power Board is constructed on a standard-sized, industry-grade PCB with a conformal coating to resist moisture, dust, and corrosive vapors. Its dimensions are approximately 200 mm x 100 mm x 30 mm, with mounting holes designed for secure installation within an Enraf system enclosure. The operating temperature range is typically -40°C to +70°C, making it suitable for both outdoor and indoor installations. The board features robust terminal blocks for input and output connections, ensuring reliable wiring under vibration and thermal stress.
**Functional Features**
Key functional attributes include an integrated power-on reset circuit, which ensures that connected processors start in a known state. The board also provides isolated power outputs to minimize noise interference between analog and digital circuits. An onboard diagnostic LED indicator signals operational status, including normal operation, fault conditions, or input power loss. The design complies with relevant EMC directives and industrial safety standards, enhancing system immunity to electrical noise and transient surges commonly found in industrial environments.
**Compatibility and Application**
This power board is specifically designed for use with the Honeywell Enraf series of field communication units and inventory controllers, such as the SmartRadar and 854 ATG
