Help CenterEnameled Copper Flat Wire 0.5mm x 2mm for Transformer Windings
Product Spotlights
Related Products
-
Class 180 Enameled Copper Flat Wire With 3% Conductivity ToleranceNegotiableMOQ: 500 Kilograms -
Polyesterimide Insulated Flat Copper Wire for Automotive CoilsNegotiableMOQ: 500 Kilograms
-
Rectangular Enameled Copper Wire 2.0mm x 4.0mm for Motor RewindingNegotiableMOQ: 500 Kilograms
-
Rectangular Magnet Wire With 10-Year Oxidation WarrantyNegotiableMOQ: 500 Kilograms
-
Enameled Flat Copper Wire for EV Traction Motor ManufacturingNegotiableMOQ: 500 Kilograms
Precision Engineered Enameled Flat Wire for High-Efficiency Transformers
Shandong Huilong Electrical Material Co., Ltd., established in 1970 with over 50 years of expertise in electrical materials manufacturing, delivers premium enameled copper flat wire specifically engineered for transformer applications. Our 10,000-30,000 sqm ISO-certified facility combines advanced production capabilities with stringent quality control to provide wires that enhance energy transfer efficiency while minimizing eddy current losses. This 0.5mm x 2mm rectangular wire features optimized dimensional accuracy for compact winding designs, making it ideal for power transformers, inductors, and high-frequency applications.
Technical Specifications & Performance Advantages:
- Superior Conductivity: Oxygen-free copper core ensures minimal electrical resistance (typical conductivity: 101% IACS)
- Advanced Insulation: Triple-layer enamel coating provides exceptional dielectric strength (>8000V) and thermal endurance
- Dimensional Precision: Tight tolerance control (±0.01mm) enables consistent winding density
- Mechanical Durability: Withstands bending radius 3x wire thickness without insulation cracking
- Thermal Performance: Continuous operation at 180°C with Class H temperature rating
| Parameter | Value | Testing Standard |
|---|---|---|
| Conductor Cross-Section | 1.0 mm² | IEC 60317-13 |
| Insulation Thickness | 0.05mm ±0.005mm | IEC 60851-3 |
| Breakdown Voltage | Min. 8000V AC | IEC 60851-5 |
| Elongation at Break | ≥25% | ASTM B193 |
This flat wire configuration significantly reduces skin effect losses compared to round wires at high frequencies, while its rectangular profile allows up to 20% higher fill factor in winding slots. The uniform enamel coating ensures consistent inter-turn insulation resistance even under thermal cycling conditions, extending transformer service life. Custom spooling configurations and packaging are available to match automated winding equipment requirements.
Frequently Asked Questions:
-
Q: What is the minimum order quantity?
A: Standard MOQ is 50kg, with sample quantities available for testing. -
Q: Can custom dimensions be produced?
A: Yes, we offer customization from 0.1mm to 5.0mm width with thickness adjustments. -
Q: What certifications apply to this product?
A: Manufactured under ISO9001, ISO14000, and OHSAS18001 certified systems with IEC 60317 compliance. -
Q: What packaging options are available?
A: Standard plastic spools (OD 300mm), wooden reels, or custom packaging per request. -
Q: How does flat wire benefit high-frequency transformers?
A: Reduced AC resistance and lower proximity effects improve efficiency above 10kHz. -
Q: What is the lead time for orders?
A: Stock items ship in 7 days; custom orders typically 15-20 days after confirmation. -
Q: Are test reports provided?
A: Full material certification including dimensional, electrical and mechanical test data accompanies each shipment.
With over $100 million in annual exports serving markets across 6 continents through ports including Qingdao and Shanghai, our manufacturing expertise ensures reliable global supply. Our 51-100 dedicated technical team provides comprehensive application support from prototype development to volume production. Experience the Huilong advantage – where five decades of specialization in electromagnetic materials translates to measurable performance gains in your transformer designs. Request your technical datasheet today to optimize your winding applications.
