Introduction
◎ Mainly used for pilot production experiments in scientific research institutes and factory workshops to obtain a certain quantity of product samples;
◎ Equipped with sensors and control systems for general strain fermentation operating characteristics;
◎ The control system's signal transmission, drive, main control, and human-machine interface are modularly designed with a complete set of newly designed embedded systems and upper computer configuration software, with strong expandability;
◎ Facilitates the connection of multi-tank fermentation systems to achieve parallel group experiments, using custom CAN protocol, RS232 protocol, and standard MODBUS protocol, with the CCS control system unifying the collection of data from each tank and curve comparison;
◎ Industrial control platform: Latest Siemens PLC, with powerful software data processing capabilities, facilitating the optimization and amplification of bioprocesses;
◎ GasMix workstation, equipped with a unique stirring and gas-liquid mixing design, can meet various requirements for high-density culture;
◎ This series of products can be specially designed for tank, stirring form, measurement and control parameters, sterilization methods, CIP or SIP, and other content according to user product requirements.
Volume |
100L/150L/200L/300L/500L/1000L |
Model |
SS-F3100/F3150/F3200/F3300/F3500/F3001T |
Material |
SUS316L |
Stirring method |
Top mechanical stirring/magnetic stirring |
Control parameters |
Stirring, temperature, pH, OD, DO, defoaming, pressure, air flow, feeding |
Mixed gas workstation |
AIR、N₂ 、O₂ 、CO₂ (optional) |
|
Extended Configuration |
Tank lid lifting system, CIP system, multi-channel feeding, feeding weighing, tank weighing, turbidity, biomass, outlet gas analysis (CO₂, O₂), liquid level, mass (balance), pressure, glucose, lactic acid, ammonium salt, sodium salt, potassium salt, methyl (ethyl) alcohol, bacterial concentration, and other online testing |
