Product Overview
The Intelligent Spraying Curing System is an automatic concrete maintenance equipment specially designed for box girder, beam yard, bridge deck and highway concrete curing. It adopts multi-channel solenoid valve control, realizing timed, quantitative and automatic cycle spraying. It can effectively prevent concrete cracks caused by uneven water loss, ensuring the curing quality and strength of concrete structures.
Key Features
✅ Intelligent Automatic Control: 23/39/55/70 optional channels, with timing and cycle control function, 24V solenoid valve for stable operation.✅ Uniform Spraying Coverage: Equipped with high-quality nozzles to ensure full coverage of the concrete surface, eliminating dead corners.✅ Labor-saving & Efficient: Realizes automatic water adding, walking and returning, greatly reducing manual operation and improving curing efficiency.✅ Stable & Durable: Adopts anti-corrosion pipeline and high-quality control components, suitable for long-term outdoor construction site use.✅ Customizable Scheme: Supports customized number of channels and spraying paths according to different beam lengths and project requirements.
Technical Specifications
| Parameter | Details |
|---|---|
| Control Channels | 23 / 39 / 55 / 70 (Optional) |
| Control Mode | Timed cycle automatic control |
| Solenoid Valve Voltage | DC 24V |
| Application | Box girder, beam yard, bridge deck, highway concrete curing |
Applications
Concrete curing for prefabricated box girders, T-beams and hollow slabs
Bridge deck, highway and municipal road concrete maintenance
Large-scale concrete structure curing in beam yards and construction sites
The High Speed Grout Mixer (ZJ-900) is a high-efficiency mixing equipment designed for cement slurry preparation in prestressed grouting projects. It adopts high-speed stirring blades to quickly mix cement, water and additives into uniform slurry, with large capacity and fast mixing speed, widely used in bridge, highway and railway prestressed engineering.
Key Features
✅ High Efficiency Mixing: 7.5kW high-power motor, 960r/min rotating speed, fast mixing to ensure uniform and stable slurry quality.
✅ Large Capacity & High Output: 800L tank volume, 20m³/h mixing capacity, meeting the slurry demand of large-scale grouting projects.
✅ Durable Structure: Thickened tank body and wear-resistant mixing blades, long service life, suitable for continuous construction.
✅ Easy Operation & Maintenance: Simple structure, easy to clean and maintain, reducing downtime on site.
✅ Stable Performance: Stable operation with low noise, suitable for various construction site environments.
Technical Specifications
| Parameter | Details |
|---|---|
| Model | ZJ-900 |
| Motor Power | 7.5kW |
| Tank Volume | 800L |
| Rotating Speed | 960r/min |
| Mixing Capacity | 20m³/h |
| Application | Cement slurry preparation for prestressed grouting |
Applications
Slurry preparation for prestressed grouting in bridges, highways and railways
Slurry mixing for foundation reinforcement and anti-seepage projects
Cement slurry preparation for tunnel and culvert engineering
Product Overview
The High Speed Grout Mixer (ZJ-900) is a high-efficiency mixing equipment designed for cement slurry preparation in prestressed grouting projects. It adopts high-speed stirring blades to quickly mix cement, water and additives into uniform slurry, with large capacity and fast mixing speed, widely used in bridge, highway and railway prestressed engineering.
Key Features
✅ High Efficiency Mixing: 7.5kW high-power motor, 960r/min rotating speed, fast mixing to ensure uniform and stable slurry quality.
✅ Large Capacity & High Output: 800L tank volume, 20m³/h mixing capacity, meeting the slurry demand of large-scale grouting projects.
✅ Durable Structure: Thickened tank body and wear-resistant mixing blades, long service life, suitable for continuous construction.
✅ Easy Operation & Maintenance: Simple structure, easy to clean and maintain, reducing downtime on site.
✅ Stable Performance: Stable operation with low noise, suitable for various construction site environments.
Technical Specifications
Parameter Details Model ZJ-900 Motor Power 7.5kW Tank Volume 800L Rotating Speed 960r/min Mixing Capacity 20m³/h Application Cement slurry preparation for prestressed grouting Applications
Slurry preparation for prestressed grouting in bridges, highways and railways
Slurry mixing for foundation reinforcement and anti-seepage projects
Cement slurry preparation for tunnel and culvert engineering
