Intermediate Hanger Bearing - XLY
Product Name: Intermediate Hanger Bearing - XLY | Model: XLY | MOQ: 1 Piece | Customizable: Yes | Delivery Time: 7-14 Days
Get Quotation Now | Contact Us for Customization | Factory Direct Supply | Quality Certified
Product Overview
The XLY intermediate hanger bearing is a core component for screw conveyors/feeders, used to connect and support two screw shafts/inner tubes. Equipped with a self-lubricating bushing, it can reduce vibration by over 30%, extend equipment service life by over 25%, and is suitable for 80% of industrial material conveying scenarios.
Core Features & Advantages
High-Quality Material & Precision: Carbon steel (HRC 45-50 after quenching) or optional aluminum alloy; precision machining with tolerance ≤±0.02mm, suitable for working temperature of -40℃~120℃.
Self-Lubricating & Low Maintenance: Equipped with a self-lubricating bushing, the maintenance cycle is extended to 2 years, reducing maintenance costs by 40% compared with ordinary bearings.
Stable & Vibration-Reducing: Precise alignment (error ≤0.03mm), vibration reduction over 30%, reducing wear of related components by 25%.
Easy Installation: Quick assembly, installation time ≤15 minutes, no need to move the screw shaft; compatible with 90% of mainstream screw conveyor models.
Customizable: Customizable size (inner diameter 100-500mm), 20-tooth spline (tooth diameter 40mm optional), material customization completed within 7 working days.
Cost-Effective: Factory direct price 30% lower than distributors, MOQ 1 piece, 5% discount for bulk orders ≥100 pieces, delivery time 7-14 days.
Product Specifications
Parameter |
Specification |
Optional |
Model |
XLY |
Customizable Model |
Inner Diameter |
168mm(6"), 219mm(8"), 273mm(10"), 323mm(12") |
100-500mm (Customizable) |
Working Temperature |
-40℃~120℃ |
Customizable |
Maintenance Cycle |
2 years |
Adjustable |
Technical Data
| Type | Model | Shaft Size | Suitable Conveyor | DIN5482 | Weight |
|---|---|---|---|---|---|
| XLR Aluminum | XLR040B015 | 40 mm | ES168 | 40×36 | 3.5 kg |
| XLR Aluminum | XLR040B017 | 40 mm | ES193 | 40×36 | 3.5 kg |
| XLR Aluminum | XLR040B020 | 40 mm | ES219 | 40×36 | 3.9 kg |
| XLR Aluminum | XLR040B025 | 40 mm | ES273 | 40×36 | 4.5 kg |
| XLR Aluminum | XLR040B030 | 40 mm | ES323 | 40×36 | 5.0 kg |
| SI Cast Iron | SI168 | 40 mm | SC168 | 40×36 | 3.5 kg |
| SI Cast Iron | SI219 | 40 mm | SC219 | 40×36 | 3.9 kg |
| SI Cast Iron | SI273 | 40 mm | SC273 | 40×36 | 4.5 kg |
| SI Cast Iron | SI323 | 40 mm | SC325 | 40×36 | 5.0 kg |
| SI Cast Iron | SI325 | 60 mm | SC323 | 60×55 | 13.0 kg |
| SI Cast Iron | SI407 | 60 mm | SC407 | 60×55 | 15.0 kg |
| XLY Cast Iron | XLY045H020 | 45 mm | TU219 | 40×36 | 4.5 kg |
| XLY Cast Iron | XLY045H025 | 45 mm | TU273 | 40×36 | 4.7 kg |
| XLY Cast Iron | XLY045H030 | 45 mm | TU323 | 40×36 | 5.0 kg |
| XLY Cast Iron | XLU406H035 | 60 mm | TU406 | 60×55 | 14.0 kg |
