Help CenterFactory Genyond Turnkey Project Industrial 95%-99.9% Alcohol Distillation Distillery Machine Cellulose Ethanol Production Line
Related Products
-
Turnkey Project Beetroot Alcohol Making Machine Line PlantUS$ 50000 - 400000MOQ: 1 Set -
Distillation Machinery Column Tower Dehydration ColumnUS$ 50000 - 100000MOQ: 1 Set
-
Factory Genyond Automatic Citrus Peel Grinder Grinding Equipment Orange Skin Essential Oil Extractor Machine Extraction LineUS$ 16500.00MOQ: 1 Set
-
Cold Press Citrus Fruit Oil Extraction MachineUS$ 16500.00MOQ: 1 Set
-
5L 10L 20L Home & Lab Use Small Commercial Use Shop Display Essential Oil Distillation Distiller Equipment Extraction MachineUS$ 980.00 - 1380.00MOQ: 1 Set
Customization of ethanol production line
Specifications
95%-99.9% Alcohol/ethanol distillation equipment
DDGS dryer machine
Fermenting
ASME, ISO, CE
Produce as your requirement
Alcohol equipment, Differential pressure, fuel ethanol equipment, dehydration alcohol/ethanol equipment, distillation columns
Spiral plate Heat exchanger, Shell and tube heat exchanger, Condenser, Reboiler, Preheater, Evaperator, Dryer machinery
1. It is a turn-key whole set equipment, simple equipment, less worker, less area, less cost.
2. We can design, manufacture, install and adjust 1000L-1000000L 95%-99.9%alcohol (ethanol) per day.
3.We can use corn, wheat, cassava, molasses, rice, potato, chinese date, beetroot,sugar cane ect which contains starch or sugar material to produce alcohol.
4. We can do the turn key system or section part.
5. We can improve and rebuild old alcohol(ethanol) production line .
You can choose single distill tower to save money, also can choose 2-8 distill column to get good quality alcohol(ethanol).
|
Energy Consumption & Quality Indicator Table Of Five-Column Three-Effect Distillation Process for Super-fine Alcohol |
||||
| No. | Item | Unit | Traditional Process | New Process |
| 1 | Steam Consumption | t/t | 3.0 | 2.3 |
| 2 | Colority | No. | 9.5 | 8 |
| 3 | Alcohol | %(v/v) | 95.5 | 96.5 |
| 4 | Sulfuric Acid Test | No. | 70 | 9 |
| 5 | ()Aldehyde (as acetaldehyde) | mg/l | 28 | 2 |
| 6 | Methanol | mg/l | 18 | 3 |
| 7 | n-propyl alcohol | mg/l | 15 | 2 |
| 8 | +Isobutanol+isoamylol | g/l | 27.5 | 2 |
| 9 | ()Acid(as acetic acid) | mg/l | 19 | 9 |
| 10 | ()Ester (as acetic ether) | mg/l | 22 | 16 |
| 11 | Nonvolatile matter | mg/l | 23 | 12 |
| 12 | (Pb)Heavy metal | mg/l | 0.65 | 0.4 |
| 13 | ( | mg/l | 3.7 | 2 |
| Energy Consumption & Quality Indicator Table Of Double-Mash-Column Three-Effect Distillation Process for Super-fine Alcohol |
||||
| No. | Item | Unit | Traditional Process | New Process |
| 1 | Electricity Consumption | kwh/t | 15 | 20 |
| 2 | Steam Consumption | t/t | 2.3 | 1.4 |
| 3 | Water Consumption | t/t | 7 | 5 |
| 4 | Colority | No. | 9.5 | 8 |
| 5 | Alcohol | %(v/v) | 95.5 | 95.5 |
| 6 | Sulfuric Acid Test | No. | 70 | 55 |
| 7 | Aldehyde (as acetaldehyde) | mg/l | 28 | 25 |
| 8 | Methanol | mg/l | 100 | 55 |
| 9 | n-propyl alcohol | mg/l | 75 | 35 |
| 10 | +Isobutanol+isoamylol | mg/l | 27.5 | 26 |
| 11 | ()Acid(as acetic acid) | mg/l | 19 | 18 |
| 12 | ()Ester (as acetic ether) | mg/l | 22 | 20 |
| 13 | Nonvolatile matter | mg/l | 23 | 21 |
| 14 | (Pb)Heavy metal | mg/l | 0.65 | 0.5 |
| 15 | ( | mg/l | 3.7 | 3 |
GENYOND MACHINERY INDUSTRIAL GROUP
It has 6 factories in China for food machine and packing machine.
Shanghai Genyond Technology Co Ltd; Zhangjiagang Genyond Machinery Co Ltd
Shanghai Jou Yu industrial Co Ltd; Shanghai Keyfood Machinery Co Ltd
Sino topone machinery; Nantong Yihai Machinery; Kunshan Kpack Machinery
Our products have been exported to more than 160 countries with Annual sales reaching 80 millions in 2022 and it raises by yearly average 10% above.
Genyond machine has more than 100 engineers for the installation of oversea projects.
You just need to give us your idea on final product to be made, processing capacity, way of packing, we will make the proposals for your checking. You can also give us your budget, we can also design a line to meet your budget accordingly.
A satisfying project will be given; A long-term cooperation will come.
