Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Turnkey Project Beetroot Alcohol Making Machine Line Plant
Turnkey Project Beetroot Alcohol Making Machine Line Plant
US$ 50000 - 400000
MOQ: 1 Set
Key Specifications
Get Latest Price
processing:
Other
video outgoing-inspection:
Provided
machinery test report:
Provided
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Distillation Machinery Column Tower Dehydration ColumnUS$ 50000 - 100000MOQ: 1 Set -
Factory Genyond Automatic Citrus Peel Grinder Grinding Equipment Orange Skin Essential Oil Extractor Machine Extraction LineUS$ 16500.00MOQ: 1 Set
-
Cold Press Citrus Fruit Oil Extraction MachineUS$ 16500.00MOQ: 1 Set
-
5L 10L 20L Home & Lab Use Small Commercial Use Shop Display Essential Oil Distillation Distiller Equipment Extraction MachineUS$ 980.00 - 1380.00MOQ: 1 Set
-
50-100L Magnolia Flower Essential Oil Extractor Machine Essential Oil Distillation Extraction MachineUS$ 8000.00MOQ: 1 Set
processing
Other
video outgoing-inspection
Provided
machinery test report
Provided
core components
Pressure Vessel
place of origin
China
brand name
Genyond
model number
GY-200C
voltage
380V
power(w)
100kw
weight
1000 KG
warranty
1 Year
name
ethanol plant
Applicable Industries
Manufacturing Plant, Food & Beverage Factory, Food & Beverage Shops
Showroom Location
None
Marketing Type
New Product 2020
Warranty of core components
1 Year
Condition
New
Customization of ethanol production line
Specifications
95%-99.9% Alcohol/ethanol distillation equipment
DDGS dryer machine
Fermenting
ASME, ISO, CE
Produce as your requirement
Alcohol equipment, Differential pressure, fuel ethanol equipment, dehydration alcohol/ethanol equipment, distillation columns
Spiral plate Heat exchanger, Shell and tube heat exchanger, Condenser, Reboiler, Preheater, Evaperator, Dryer machinery
1. It is a turn-key whole set equipment, simple equipment, less worker, less area, less cost.
2. We can design, manufacture, install and adjust 1000L-1000000L 95%-99.9%alcohol (ethanol) per day.
3.We can use corn, wheat, cassava, molasses, rice, potato, chinese date, beetroot,sugar cane ect which contains starch or sugar material to produce alcohol.
4. We can do the turn key system or section part.
5. We can improve and rebuild old alcohol(ethanol) production line .
You can choose single distill tower to save money, also can choose 2-8 distill column to get good quality alcohol(ethanol).
|
Energy Consumption & Quality Indicator Table Of Five-Column Three-Effect Distillation Process for Super-fine Alcohol |
||||
| No. | Item | Unit | Traditional Process | New Process |
| 1 | Steam Consumption | t/t | 3.0 | 2.3 |
| 2 | Colority | No. | 9.5 | 8 |
| 3 | Alcohol | %(v/v) | 95.5 | 96.5 |
| 4 | Sulfuric Acid Test | No. | 70 | 9 |
| 5 | ()Aldehyde (as acetaldehyde) | mg/l | 28 | 2 |
| 6 | Methanol | mg/l | 18 | 3 |
| 7 | n-propyl alcohol | mg/l | 15 | 2 |
| 8 | +Isobutanol+isoamylol | g/l | 27.5 | 2 |
| 9 | ()Acid(as acetic acid) | mg/l | 19 | 9 |
| 10 | ()Ester (as acetic ether) | mg/l | 22 | 16 |
| 11 | Nonvolatile matter | mg/l | 23 | 12 |
| 12 | (Pb)Heavy metal | mg/l | 0.65 | 0.4 |
| 13 | ( | mg/l | 3.7 | 2 |
| Energy Consumption & Quality Indicator Table Of Double-Mash-Column Three-Effect Distillation Process for Super-fine Alcohol |
||||
| No. | Item | Unit | Traditional Process | New Process |
| 1 | Electricity Consumption | kwh/t | 15 | 20 |
| 2 | Steam Consumption | t/t | 2.3 | 1.4 |
| 3 | Water Consumption | t/t | 7 | 5 |
| 4 | Colority | No. | 9.5 | 8 |
| 5 | Alcohol | %(v/v) | 95.5 | 95.5 |
| 6 | Sulfuric Acid Test | No. | 70 | 55 |
| 7 | Aldehyde (as acetaldehyde) | mg/l | 28 | 25 |
| 8 | Methanol | mg/l | 100 | 55 |
| 9 | n-propyl alcohol | mg/l | 75 | 35 |
| 10 | +Isobutanol+isoamylol | mg/l | 27.5 | 26 |
| 11 | ()Acid(as acetic acid) | mg/l | 19 | 18 |
| 12 | ()Ester (as acetic ether) | mg/l | 22 | 20 |
| 13 | Nonvolatile matter | mg/l | 23 | 21 |
| 14 | (Pb)Heavy metal | mg/l | 0.65 | 0.5 |
| 15 | ( | mg/l | 3.7 | 3 |
