Help CenterSupply of DV185WHM-NM1 BOE Technology NM2 18.5-inch LCD Screen With LED, Kai-Xian, Pufen, High Resolution, High Brightness
Product Spotlights
Related Products
-
DV270FHB-P20-N20 BOE Technology 27-inch MonitorUS$ 67MOQ: 10 Blades -
DV332X2M-NV0 33.2-inch Square Screen, BOE Technology, KaixianUS$ 190MOQ: 10 Blades
-
Supply of EV190E0M-N10 by BOE Technology, a 19-inch LED Display With Full and Wide Viewing Angles, Kai-Xian Technology’s 4:3 Square Screen, LGUS$ 58MOQ: 10 Blades
-
MV215FHM-N40 BOE21.5-inch Industrial Display, Touchscreen, All-in-one, Query Machine, Queueing Machine, Advertising Machine, Industrial MonitorUS$ 65MOQ: 10 Blades
-
MV238QUB-N20 BOE Technology 23.8-inch 4K Industrial Display, Touchscreen, All-in-one, Kiosk, Queueing Machine, Industrial Monitor.US$ 130MOQ: 10 Blades
DV185WHM-NM2 is an 18.5-inch LCD module product launched by BOE Technology Group Co., Ltd. The following are its detailed parameters:
1.?Basic Information: The panel type is a-Si TFT-LCD; operating temperature is 0 - 50°C, storage temperature is -20 - 60°C; vibration resistance is 1.5G (14.7m/s2); surface treatment is matte (Haze 25%), Hard coating (3H); it adopts LVDS (1 ch, 8-bit) signal interface with 30 pins, connected by terminals, the driving voltage is 5.0V (Typ.), and the typical vertical refresh rate is 60Hz.
2.?Appearance Parameters: The display area is 409.8×230.4mm, the overall dimension is 430.4×254.6×11.4 (Typ./Max.) mm, and the net weight of the product is 1.30Kgs (Typ.).
3.?Optical Parameters: The display brightness is 500cd/m2, the contrast ratio is 1000∶1, the viewing angle is 89/89/89/89 (Typ.) (CR≥10) (L/R/U/D), the display color is 16.7M, the color saturation is 99% (sRGB), and the response time is 14 (Typ.) (G to G) ms.
4.?Backlight Parameters: The light source type is WLED, using 6S4P WLED edge-lit light source (right side), the service life of the light source is 50K hours, and there is no backlight driver.
5.?Pixel Parameters: The resolution is 1366×768 (WXGA), the pixel arrangement is RGB vertical stripe, the aspect ratio is 16∶9, the pixel pitch is 0.300×0.300mm, the dot pitch is 0.100×0.300mm, and the resolution is 84PPI.
BOE 18.5-inch LCD display
Model: DV185WHM-NM2
Resolution: 1366*768
Brightness: 500cd/m2
Viewing angle: 89/89/89/89
Contrast ratio: 1000:1
Operating temperature: 0 - 50°C, Storage temperature: -20 - 60°C
Send Inquiry to This Supplier
