Industrial Wireless Liquid Level Sensor | NB-IoT/LoRa | Explosion Proof | Battery Powered | For Water/Fuel/Chemical Tanks
Product Spotlights
Industrial wireless liquid level sensors (submersible/radar). No wiring needed, cuts 80% installation cost. 3-5 year battery life, no external power. NB-IoT/LoRa global coverage. IP68 waterproof, optional explosion-proof. High accuracy ±0.2%FS. Plug & play, MQTT/Modbus compatible.
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Measuring Range:
0-1m, 0-5m, 0-10m, 0-20m, 0-50m
Accuracy:
±0.2%FS
Resolution:
1mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
7 days
Related Products
-
Industrial Wireless Time-Lapse Camera | WIFI Ethernet Dual Connection | Auto FTP Upload | Battery Powered for Construction Site Project MonitoringNegotiableMOQ: 1 Set -
698 Photovoltaic Protocol Converter Photovoltaic Inverter Power Generation Electricity Consumption Information CollectionUS$ 0.00001 - 70MOQ: 1 Piece
-
Photovoltaic Inverter Interface Converter Combined With 698 Protocol Converter to Achieve Information Collection of Inverter Power Generation and ConsumptionUS$ 0.00001 - 15MOQ: 1 Piece
-
Power IEC104 Protocol Server Client Master and Slave Protocol Debugging Software ToolUS$ 0.00001 - 11MOQ: 1 Unit
-
4G/NB-IOT/LoRa/WiFi Wireless Industrial Laser Ranging SensorNegotiableMOQ: 1 Piece
Measuring Range
0-1m, 0-5m, 0-10m, 0-20m, 0-50m
Accuracy
±0.2%FS
Resolution
1mm
Communication
NB-IoT / LoRa
Power Supply
3.6V Lithium Thionyl Chloride Battery (1
Battery Life
3-5 years (1-hour reporting)
Operating Temperature
-40°C ~ +85°C
Protection Grade
IP68 (probe) / IP67 (body)
Compatible Media
Water, oil, weak acids/alkalis
Transport Package
Carton Box
Specification
1 set
Trademark
Shanghai DAQ-IOT Technology Company
Origin
Shanghai,China
Wireless Liquid Level Sensor | NB-IoT/LoRa/4G | Industrial Grade
1.Core Advantages
✅ No Wiring Required - Cut 80% installation cost & time
✅ 3-5 Year Battery Life - Ultra-low power, no external power needed
✅ Global Coverage - NB-IoT/LoRa/4G Cat.1 for any remote site
✅ IP68 Waterproof & Explosion-Proof - Works in harsh industrial environments
✅ Plug & Play - Auto-connect to cloud, no complex configuration
2.Technical Specifications
| Parameter | Submersible Wireless Level Sensor |
|---|---|
| Measuring Range | 0-1m, 0-5m, 0-10m, 0-20m, 0-50m |
| Accuracy | ±0.2%FS |
| Resolution | 1mm |
| Communication | NB-IoT / LoRa / 4G Cat.1 |
| Power Supply | 3.6V Lithium Thionyl Chloride Battery (19Ah) |
| Battery Life | 3-5 years (1-hour reporting) |
| Operating Temperature | -40°C ~ +85°C |
| Protection Grade | IP68 (probe) / IP67 (body) |
| Explosion-Proof | Optional Ex ia IIB T4 Ga |
| Process Connection | M20×1.5 Thread / DN50 Flange |
| Compatible Media | Water, oil, weak acids/alkalis |
3.Product Review
4.Typical Applications:
---Petroleum & Chemical: Crude oil tanks, refined oil tanks, chemical storage tanks
---Water Treatment: Sedimentation tanks, aeration tanks, sludge tanks, sewage tanks
---Municipal Water: Secondary water supply tanks, fire water tanks, reservoirs
---Food & Beverage: Beverage tanks, raw material tanks, fermentation tanks
---Agriculture: Irrigation reservoirs, wells, livestock water tanks
---Energy & Power: Cooling towers, hydroelectric reservoirs, fuel storage
