Product Description
Product Description
Introduction
LORK is an excellent high super alloy manufacturer in China.
Hastelloy G-30 (UNS N06230 / W.Nr. 2.4603) is an improved version of nickel-chromium-iron-molybdenum-copper alloy G-3. With higher chromium, added cobalt and tungsten, the G-30 shows superior corrosion resistance over most other nickel and iron based alloys in commercial phosphoric acids as well as complex environments containing highly oxidizing acids. The resistance of the alloy to the formation of grain boundary precipitates in the heat-affected zone makes it suitable for use in most chemical process applications in the as-welded condition.
Specifications
| Trademark | GB | GOST | ASTM | UNS | DIN | W.Nr. | NF | BS | JIS | SS |
| Hastelloy G-3 Nicrofer 4023hMo |
NS3404 | - | Hastelloy G-3 | N06985 | - | 2.4619 | - | - | - | - |
Chemical Compositions Of Hastelloy G-3 Nickel Alloy
| Alloy | C | Si | Mn | P | S | Cr | Ni | Co | Mo | W | Nb+Ta | Cu | Fe |
| Hastelloy G-3 | ≤0.015 | ≤1.00 | ≤1.00 | ≤0.04 | ≤0.03 | 21.0-23.5 | Bal | ≤5.00 | 6.0-8.0 | ≤1.50 | ≤0.50 | 1.5-2.5 | 18.0-21.0 |
Typical Physical And Mechanical Properties (RT, Solution Annealed)
| Density, g/cm3 | Melting Point, ºC | Tensile Strength, MPa | Yield Strength, MPa | ELongation, % | Hardness, HB |
| 8.14 | 1260-1343 | 690 | 321 | 50 | - |
Product Forms And Standards
| Rod, Bar, Wire and Forgings | ASTM B581, ASME SB581, DIN 17752 |
| Plate, Sheet and Strip | ASTM B582, ASME SB582, DIN 17750, ISO 6208 |
| Pipe and Tube | ASTM B619, ASTM B622, ASTM B626, ASTM B751, ASTM B775, ASTM B829, ASME SB619, ASME SB622, ASME SB626, ASME SB751, ASME SB775, ASME SB829 |
| Welding Product | - |
| Others | ASTM B366, ASME SB366 |
Available Sizes And Specifications
| Hastelloy G-3 available sizes and specifications | |
| Grade | Hastelloy G-3 |
| Nickel plate | Thickness: 0.3mm - 150.0mm Width: 1000mm - 3000mm |
| Nickel strip/ nickel foil | Thickness: 0.02mm - 16.0mm Width: 5mm - 3000mm |
| Nickel coil | Thickness: 0.3mm - 16.0mm Width: 1000mm - 3000mm |
| Nickel pipe | Outside diameter: 6mm - 1219mm Thickness: 0.5mm - 100mm |
| Nickel Capillary Pipe | Outside diameter: 0.5mm - 6.0mm Thickness: 0.05mm - 2.0mm |
| Nickel bar | Diameter: Ф4mm - Ф600mm |
| Nickel wire rod | Diameter:Ф0.01mm - Ф6mm |
Company Profile
Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from Φ6 toΦ762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from Φ15 to Φ2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
