Laser-cut triangular brackets | Building curtain walls/Equipment support Thickened plate processing
Hello, friends in the engineering field! Recently, we've received quite a few inquiries about "irregular-shaped brackets" and "thickened brackets", especially for triangular brackets. Today, let's talk about this topic and see how laser cutting can handle such products.
1. How wide is the application of triangular brackets?
Don't underestimate the simple triangular structure. It's a "frequent visitor" in the engineering field:
Building curtain wall field:
Curtain wall keel support
Glass curtain wall connectors
Fixing brackets for aluminum alloy curtain walls
Support angle codes for steel structure canopies
Equipment support field:
Mechanical equipment base brackets
Automation equipment fixtures
Power equipment brackets
Industrial pipeline support frames
Why do people love using triangles? Because it has good stability, strong load-bearing capacity, and the most reasonable mechanical structure!
2. What are the considerations for laser cutting thickened plates?
Many friends are worried whether the laser can cut and cut well when they hear "thickened plates". In fact, the technology is completely mature now!
The thickness we can process:
Carbon steel plate: 3mm～25mm
Stainless steel: 3mm～20mm
Aluminum alloy: 3mm～16mm
Galvanized plate: 3mm～12mm
Difficulties and solutions for thickened plate cutting:
| Difficulties | Our solutions |
|---|---|
| Rough cut | High-power laser + Professional cutting parameters |
| Serious slag hanging | Optimize gas pressure and nozzle design |
| Large thermal deformation | Layered cutting + Cooling fixtures |
3. Why choose laser cutting for triangular brackets?
Compared with traditional processes, the advantages of laser cutting are very obvious:
✅ No need for mold opening: Direct cutting from CAD drawings, suitable for small batches
✅ High precision: Dimension error ≤±0.1mm, no assembly troubles
✅ Complex shapes: Triangles, L-shapes, U-shapes, and various irregular shapes can be formed in one go
✅ Cut quality: Less dross, thin oxide layer, simple subsequent processing
✅ Fast delivery: Samples in 24 hours, batches in 3 - 5 days
Previously, a customer made triangular support parts for curtain walls. Using the stamping process before, they spent more than 20,000 yuan on mold fees alone, and the construction period was delayed by half a month. After using laser cutting, they didn't spend any money on molds and the products were delivered in 3 days, saving thousands of yuan directly!
4. Sharing of typical application cases
Case 1: Triangular corner codes for curtain walls
Material: 3mm galvanized sheet
Quantity: 2000 pieces
Delivery time: 4 days
Customer evaluation: The dimensions are just right, and the assembly passed at one time
Case 2: Equipment support brackets
Material: 12mm carbon steel plate
Quantity: 50 pieces
Process: Cutting + Welding + Painting
Customer evaluation: The load-bearing test passed, and long-term cooperation is established
Case 3: Irregular steel structure connectors
Material: 20mm stainless steel
Quantity: 100 pieces
Feature: Cutting with an angle, precision requirement of ±0.5°
Customer evaluation: It's even better than expected
5. Our processing capabilities
Equipment configuration:
6000W fiber laser cutting machine
12000W high-power model (specially for thick plates)
Automatic loading and unloading system
Professional fixture tooling
Processable shapes:
Regular triangles, L-shapes, U-shapes
Complex special-shaped brackets
Integrally formed parts with holes and notches
Large-size long strip brackets (up to 3 meters long)
Subsequent process matching:
Bending, welding
Surface treatment (spray painting, baking finish, galvanizing)
Drilling, tapping
Packaging and shipping
6. Questions that customers care about the most
Q: Will the thickened plate deform during cutting?
A: We have optimized the cutting parameters. There are special process cards for different thicknesses, and the thermal deformation is controlled within a reasonable range. We will level important parts.
Q: How is the price calculated for large quantities?
A: The larger the quantity, the better the price! It specifically depends on the material, thickness, quantity, and accuracy requirements. Welcome to provide drawings for a quotation.
Q: Can you offer free shipping?
A: For large quantities, we can discuss logistics across the country. The prices of our cooperating logistics companies are very affordable.
7. Summary
The core advantages of laser cutting triangular brackets are:
High precision + No mold + Fast delivery + Cost savings
Whether it is the corner codes of building curtain walls, the bases of equipment supports, or various special-shaped brackets, we can help you make them quickly.
Have a drawing? Send it over! Get a free evaluation and quotation, and a sampling plan will be provided within 24 hours～
