ABB REF615 HBFFAEAGNDA1ABA11G is a digital feeder protection and control device. It is an integrated unit dedicated to the protection, control, and monitoring of feeders (cables, overhead lines) in utility and industrial distribution systems. It integrates five core capabilities: accurate fault protection, real-time parameter measurement and control, remote communication, event recording, and adaptive protection schemes. As a key component of ABB medium‑voltage distribution automation solutions, it is widely used in substations, industrial plants, distribution networks, renewable energy power stations, and other scenarios. It is suitable for radial, loop, and mesh distribution networks (including distributed generation applications), provides comprehensive protection for overhead lines and cable feeders, effectively prevents fault escalation, and ensures the stability, reliability, and efficient operation of distribution systems.
This device mainly performs core protection tasks for feeders, including overcurrent, short‑circuit, and earth‑fault protection. It simultaneously monitors electrical parameters such as current, voltage, and power in real time. It features fault location, event recording, and alarm functions, and can automatically adjust protection parameters according to distribution system operating conditions to achieve adaptive protection, ensuring sensitivity and selectivity. It is compatible with the ABB Relion® product ecosystem, supports mainstream communication protocols such as IEC 61850, and can seamlessly connect to upper‑level monitoring systems and substation automation systems. It is compatible with conventional current/voltage transformers, Rogowski coils, and other sensors, complying with international power industry standards to ensure compliance and long‑term operational reliability in various distribution applications.
It features a compact industrial design that balances durability and ease of maintenance. A plug‑and‑pull structure enables fast installation and testing. It is equipped with a large LCD screen displaying single‑line diagrams, with a simple and intuitive human‑machine interface (HMI) for easy operation, supporting local parameter setting and fault query. The enclosure uses industrial‑grade protective materials, suitable for complex environments such as power equipment rooms and outdoor distribution installations. It has excellent electromagnetic interference immunity, dustproof and moisture‑proof performance, and can operate stably in harsh industrial environments.
1. Technical Specifications
Power SpecificationsMultiple supply voltage options are supported (universal AC/DC, typical values 110/220 VAC/VDC), with a voltage tolerance of ±15% and short‑term surge immunity, adapting to on‑site power fluctuations in power systems.Low rated power consumption without extra energy burden, suitable for long‑term continuous operation in substations and distribution rooms.Comprehensive power protection is provided, including overvoltage, overcurrent, and reverse polarity protection, effectively preventing damage to the device from abnormal power supplies and improving operational safety.
Protection Function SpecificationsFull‑featured feeder protection, including non‑directional/directional overcurrent protection, short‑circuit protection, and earth‑fault protection (including high‑sensitivity multi‑frequency admittance earth‑fault protection), covering continuous, transient, and intermittent earth faults with excellent sensitivity and selectivity.Supports auxiliary protection functions such as negative‑sequence overcurrent protection, phase‑failure protection, thermal overload protection, and circuit‑breaker failure protection, and can be flexibly adapted to different distribution system types (isolated neutral, resistance‑earthed, compensated neutral, etc.).Equipped with high‑speed output interfaces, reducing operating time by 4–6 ms compared with conventional binary outputs, effectively mitigating the effects of arc faults.Supports fault location, accurately identifying short‑circuit faults in radial networks and earth faults in effectively earthed and low‑resistance earthed networks. It can also locate earth faults in isolated neutral networks when the fault current is not lower than the load current.
Measurement and Monitoring SpecificationsReal‑time acquisition and monitoring of core electrical parameters including three‑phase current, voltage, power, frequency, and energy, with high measurement accuracy and fast response, providing reliable data support for distribution system performance evaluation and operation optimization.Event recording function, which logs system fault events and operation logs with timestamps in detail for later fault tracing and analysis.Equipped with a local HMI LCD screen that intuitively displays single‑line diagrams, real‑time parameters, and fault information, supporting manual operation and parameter setting.
Communication and Compatibility SpecificationsSupports IEC 61850 Edition 1 and Edition 2, including HSR, PRP redundancy protocols, GOOSE messaging, and IEC 61850‑9‑2 LE, reducing wiring and enabling supervised communication.Compatible with mainstream industrial communication protocols such as Modbus, DNP3, and IEC 60870‑5‑103. Profibus DPV1 is supported via the SPA‑ZC 302 protocol adapter.Supports IEEE 1588 v2 high‑precision time synchronization, ensuring accuracy in station‑level Ethernet communication.Equipped with dedicated communication interfaces for seamless connection to upper‑level monitoring systems and substation automation systems, enabling remote monitoring, control, and parameter setting.Compatible with conventional current/voltage transformers, Rogowski coils, and other sensors to meet the monitoring requirements of different distribution systems.
Environmental SpecificationsOperating temperature range: -25°C to +70°C. The wide‑temperature design withstands extreme temperature fluctuations in power equipment rooms and outdoor distribution installations without additional temperature control equipment.Storage temperature range: -40°C to +85°C, suitable for long‑term storage of industrial spare parts.Protection class: IP54 (or higher, subject to physical product). The sealed design effectively resists dust, water splashing, dust, and humidity in industrial environments.Excellent electromagnetic interference immunity complying with power industry standards, ensuring stable operation in strong EMI environments.Natural cooling design with no mechanical failure points, enabling maintenance‑free operation and extended service life.
2. Features
Comprehensive feeder protection with outstanding sensitivity and selectivityIntegrates core protection functions including overcurrent, short‑circuit, and earth‑fault protection. The unique multi‑frequency admittance earth‑fault technology greatly improves sensitivity and selectivity for earth faults, handling various complex earth‑fault scenarios.Supports adaptive protection schemes that automatically adjust parameters based on system operating conditions, adapting to different distribution networks to ensure accurate and reliable operation and prevent fault escalation.
Integrated protection, control, and monitoring with accurate and traceable dataCombines protection, control, measurement, and monitoring in one unit without additional devices, simplifying the distribution system architecture.Real‑time collection of electrical parameters with high accuracy and fast updates.Complete event recording and fault location with timestamped logs enable maintenance personnel to quickly identify root causes and reduce downtime.
Strong communication and system integration capabilitiesFully supports mainstream protocols including IEC 61850 with redundant communication to ensure stable and reliable data transmission.Seamlessly integrates with the ABB Relion® family, substation automation systems, and supervisory systems for remote monitoring, control, parameter setting, and fault diagnosis, streamlining O&M and improving efficiency.High‑precision time synchronization ensures coordinated station‑level communication.
User‑friendly HMI and easy installation and maintenanceLarge LCD with single‑line diagram display and intuitive HMI for local setting, fault query, and manual operation.Plug‑and‑pull design allows fast installation, commissioning, and replacement.Configurable via PCM 600 software with 12 standard configurations for typical feeder applications, eliminating complex engineering.
High reliability for complex power environmentsIndustrial‑grade components and sealed construction provide excellent EMI, dust, moisture, and vibration resistance, complying with strict power industry standards.Wide‑temperature operation for extreme environments with low long‑term failure rates.Comprehensive power protection and self‑diagnosis monitor status continuously and issue alarms for anomalies, safeguarding both the device and the distribution system.
3. Applications and Case Examples
Substation Feeder ProtectionActs as the core feeder protection device in various substations, protecting outgoing feeders (cables, overhead lines) with complete overcurrent, short‑circuit, and earth‑fault protection. It monitors parameters in real time and works with substation automation systems to enable remote control and unattended operation, ensuring stable distribution system performance.
Industrial Plant Distribution ProtectionProtects internal feeders in metallurgical, chemical, manufacturing, and other industrial plants, preventing electrical accidents caused by equipment faults or short circuits. It monitors power parameters to support energy optimization and O&M, ensuring continuous power supply for production.
Renewable Power Station Distribution ProtectionProtects internal and grid‑connection feeders in PV, wind, and other renewable stations, adapting to distributed generation. It provides fault protection and parameter monitoring to ensure stable grid connection and safe operation, avoiding generation losses due to faults.
Urban Distribution Network ProtectionProtects radial, loop, and mesh lines in urban distribution networks, accurately locating and quickly isolating faults to reduce outages and improve power supply reliability for residents and businesses.
4. Product Advantages
Comprehensive, accurate, and reliable protection: Covers all feeder fault types; multi‑frequency admittance earth‑fault protection enhances sensitivity and selectivity; adaptive schemes suit various networks, preventing fault spread and ensuring system safety.
Integrated design for simplified integration: Combines protection, control, measurement, and monitoring to reduce hardware, complexity, and project costs while speeding up deployment.
Communication‑ready and highly scalable: Supports major protocols and precision time synchronization, integrating easily with automation systems of all sizes.
Easy maintenance and cost efficiency: Plug‑and‑play, intuitive HMI, and PCM 600 simplify installation and commissioning; precise fault location and traceable events reduce O&M workload.
High reliability and wide adaptability: Industrial‑grade build with excellent immunity, wide temperature range, dustproof and moisture‑proof design, certified to strict industry standards for stable long‑term operation in harsh environments.
