Key Features & Benefits:
Unmatched Power & Dual-Channel Efficiency: Powered by a robust 5.5KW motor, this unit generates a massive 11,000N (approx. 2470 lbs) pulling force. Its unique dual-channel drive system allows for simultaneous or sequential cable pulling, effectively replacing two single machines. This drastically improves workflow and halves storage/transport space requirements.
High-Speed, Intelligent Control: Achieve precise speed control from 0 to 36 meters per minute with 4 preset gears plus stepless variable speed adjustment. Operate effortlessly via the integrated control panel or the convenient wireless remote control. Features include instant start/stop and one-button pull/push direction switching.
Advanced Multi-Unit Synchronization: Equipped with a master/slave control module as standard. Synchronize multiple "Double Flight No.2" units wirelessly from a single remote for coordinated operations on large-scale or complex runs, ensuring consistent speed and tension.
Built for Durability & Stability: Engineered for heavy-duty use, it provides smooth, stable, and low-noise operation even under maximum load. The rugged construction ensures reliability on the toughest job sites.
User-Centric Design: The combination of panel and remote control offers unparalleled operational flexibility and safety, allowing the operator to manage the machine from the optimal vantage point.
Technical Specifications:
Model: Double Flight No.2
Power Supply: Standard: AC380V (3-Phase)
Control Modes: Integrated Control Panel + Wireless Remote Control
Motor Power: 5.5 KW
Max. Pulling Force: 11,000 N
Transport Speed Range: 0 – 36 m/min
Drive Method: Dual-Channel Conveyor System
Dimensions (L x W x H): 89 x 84 x 67 cm
Net Weight: 245 kg
Manufacturer: Changyun Technology
Ideal For:
High-volume pulling of extra-large power cables, bundled cables, and heavy conduits.
Major infrastructure projects, utility transmission lines, and industrial plant installations.
Any application requiring extreme pulling force, high speed, or the efficiency of dual-line operation.
Product Advantages
| Small size, strong pulling force and fast speed | ||||||||
| Four speed gears, stepless speed change, start and stop at any time, can be synchronized with other equipment online | ||||||||
| Effective protection for special cables such as flame-retardant, halogen-free, low-smoke, and fiber-optic composite cables | ||||||||
| Precision conveyor with real-time control of output tension to prevent excessive cable stretching | ||||||||
| Works with a cable winch for forward push and reverse pull, tackling long distances and high-friction conditions. | ||||||||
Product application scenarios
Certificate
FQA
1.What is the quality of the product? Is there a quality guarantee?
We prioritize product quality. All our products are CE and ISO certified and come with a 12-month warranty. If you experience any quality issues with the product you received, please contact us within 7 days of receipt and we will resolve the issue.
2.Is there any color difference between the product picture and the actual product?
We strive to capture the product's color accurately under professional lighting. However, slight color differences may occur due to different monitors, lighting, and other factors. This is not a product quality issue and we apologize for any inconvenience.
3.What are the raw materials/main ingredients of the product?
High-strength carbon steel, aluminum alloy, crawler tracks, high wear-resistant polyurethane. If you need more details, please contact me directly.
4.How do I place an order?
My contact information is below, or you can contact me directly on the website page and tell me the model of the machine. I will make a quotation for you. If you are satisfied, I will send you a contract for the transaction.
5.What payment methods do you accept?
We support a variety of safe and convenient payment methods, including: letter of credit, PayPal, bank transfer
6.Do you ship internationally? How much does it cost?
Yes, we ship to most countries worldwide. Shipping costs vary depending on the destination country, product weight, and the shipping method you choose (land, sea, or air). Provide me with the model and port you need to ship to, and I willcalculate the shipping costs for you and include them in the quote.
7.How long does it take for my order to be delivered?
The goods will be shipped within 3-5 working days after the payment is received, and will arrive at the designated destination within 15-50 working days after shipment.
8.How can I contact you?
Live Chat: [Recommended! Fastest response]
Email: changyunhaley@gmail.com (We'll respond within 12 hours)
WhatsApp: +86 17838311778
9.Is a factory tour possible?
We are a manufacturer that produces and sells our own products. We are a leader in the cable conveyor industry in China. You can contact me to confirm a time to visit our factory. We will arrange a professional receptionist to pick you up at the airport and follow up with an on-site factory inspection and machine explanation.
