GT-FM24 PLC (double guide tubes 6-48 station) MGO powder filling machine, is designed and manufactured according to the characteristics of imported similar machines.
The machine is controlled by PLC and Human machine interface (HMI/touch screen), and add guide rail and rotary clamping mechanism.
It can make 6-48 different stations, custom according to customers requirement, different diameters, different length.
At present the max filling length can up to 8000mm, and max filling diameter is Φ28.5mm.
Item No.:GT-FM24
Station: 24 stations
Filling length: 300-8000 mm according to order
Diameter:<Φ12.7mm
Air supply: 0.6MPa clean compressed air
Function:
fill MGO powder for tubular heaters;
Application:
suitable for tubular heaters, long heating elements, large diameter heaters to add MGO powder;
Features:
*** can make in double filling guide tubes (one diameter install on the machine);or three filling guide tubes (different diameters install on the machine);
*** operation in the middle of the machine, easy to operate;
*** length can be custom according to order, it is recommend machine for long heating elements. (filling length in 300-8000mm can be adjustable, according to order);
*** stations: 24 station. (one time fill 24 pcs, or custom accroding to order such as 6/8/10/12/16/36/48 etc)
*** shape to fill: round tube;
Information need for order for filling machine:
*** length to fill;
*** diameter to fill;
*** wall-thicnkess of the tube to fill;
*** max OD of resistance wire spiral;
*** size of terminal pin head.
[url]
http://heater-machines.com[/url]
