Welcome to Greater for heater machines!
Auto Tube Cutting Machine GT-ACT29
GT-ASCT19 auto coil tube straightening and cutting machine
Item Number:GT-ASCT19
Function: straighten coil copper tube and cut
Recommend diameter: Φ6-Φ12mm
Auto tube cutting machine use to cut tubes for heating elements autocratically.Mainly for heater production in large production. Suitable for copper pipes, iron pipes, stainless steel pipes, aluminum pipes, etc.
★Main details
1. Auto feeding, cutting, pipe breaking, and auto unload tubes.
2. Can cut two different length.
3. Only need to manual put the tubes on the rack, and take the finished cut tubes. One person can take care of several machines.
4. Quality pneumatic rotary chuck, to clamp the tube more stable.
5. With touch screen, easy operation.
6. Actions are controlled by time, easy to operate and less failure.
7. Tubes with few burrs after cutting.
Function:
Straighten the coil tube auto, and auto cut the tube according to the length need. Machine suitable for coil copper tube, aluminum tube to straight and cut.
Application:
Copper coil tube straight and cut, such as copper water heater produciton.
Main Data:
1. Suitable OD of tube: Φ4-Φ19mm;
2. Wall-thickness: 0.2-2.0mm;
3. Feeding speed: 0-60mm/min;
4. Cutting method: rotary cutting;
5. Min length to cut: 25mm;
6. Power supply: 3phase 380V, 50HZ or according to order;
7. Air supply: 0.4-0.8Mpa clean compressed air;
Information need for order GT-ASCT19 auto coil tube straightening and cutting machine:
Tube diameter to cut
Length to cut
Electrical supply (for example, 1 phase in 220v , 3 phase in 380V, 50hz)
model |
Recommend diameter/length |
productivity |
Feeding speed |
power |
air supply |
size |
weight |
GT-ACT29 |
Ф6-15mm; 4500 or 6000mm |
5000-10000pcs/8h |
Max 100m/min (can be adjustable) |
380V/50Hz/ 0.7Kw |
0.5-0.7Mpa |
8600*800*14500mm |
400Kg |
