Item:GT-WGMA201
★Description
Multi-Angle Bending Machine with 3 elbow, suitable to bend M SHAPE,U shape and square shape heaters. The machine with smooth, continuous, high control accuracy, used in tubular heaters bending.
★Main details
1. power supply: 220V;
2. motor power: 5.1KW;
3. Air supply: clean compressed air 0.5-0.7MPa;
4. with touch screen and PLC control;
5. with 3 bending elbow;
6. max can store 20 designs;
7. for 6.6mm heater, can bend 3-4 pcs one time,;
8. for 8mm heater, can bed 1-2 pcs one time;
9. length to bend: 400-3000mm；
Function:
Bend heater in multi shape/angle.
Main features:
**power supply: 220V;
**motor power: 5.1KW;
**air supply: 0.5Mpa;
**with touch screen and PLC control;
**with 3 bending elbow;
**max can store 20 designs;
**for 6.6mm heater, can bend 3-4 pcs one time,;
**for 8mm heater, can bed 2 pcs one time;
**length to bend: 400-3000mm；
**Woking speed: U shape/2 second;
**Size: 2.2*1.5*0.88m;
Application:
Bend heaters, specially for tubular heater bending in bulk production.
Information need for order GT-WGMA203 Multi Angle Bending Machine:
Drawing of heater to bend;
Diameter of heater, such as 8.5mm
Length of heater to bend;
Electrical supply (for example, 1 phase in 220v , 3 phase in 380V, 50hz)；
