Help CenterShanghai Cebo High-Pressure Homogenizer CBNANO-15, Flow Rate 15L, Laboratory Dispersing and Homogenizing, Cell Disruption, Nanometer Homogenization
Related Products
-
Shanghai Cebo Vacuum Centrifugal Concentrator CBNSY Series Heating and Cooling Concentration Equipment 2ml*240 Rotor 2000rpm Rotation SpeedNegotiableMOQ: 1 Combo -
Tuohe Ultra-Micro Spectrophotometer UV Tnano-800 Laboratory Photometer for 0.5-2ul Sample Detection of Nucleic Acids, Proteins, and Cell SolutionsNegotiableMOQ: 1 Piece
-
Shanghai Cebo Multi-Sample Tissue Grinder CEBO-24, Tissue Homogenization Grinder, Cell Disruption Homogenizer, Material DispersionNegotiableMOQ: 1 Set
-
Tuohe Integrated Ultrasonic Cell Disrupter JY96-IIN-YT Laboratory High-Capacity Disrupter 2500ml, Power AdjustableNegotiableMOQ: 1 Combo
-
Tuohe UV Cross-linking Instrument SZ03 Laboratory UV Irradiation Cross-linking Instrument DNA Cleavage and RecA Mutation Screening in Agarose GelNegotiableMOQ: 1 Piece
Homogenization is a process of treating a suspension (or emulsion) system to make the dispersed particles fine and uniform. This treatment simultaneously reduces the size of the dispersed particles and improves their uniform distribution.
Application fields:
In the pharmaceutical industry, the preparation of fat particles, drug-loaded lotion homogenization, liposomes, nano-suspensions, and microcapsules, etc;
Cell disruption, intracellular substance extraction, and homogenization of bioengineering products;
Production and preparation of fine chemicals, carbon nanotubes, graphene, conductive pastes, and resistive pastes;
Personal care products - Homogeneous dispersion of lipid nanoparticles;
Homogenization and emulsification of food and industrial products to enhance product stability;
Product advantages:
① Structural Features: Single ceramic plunger drive, precise control of discharge flow. Optional plunger lubrication device for longer seal service life.
② Homogeneous pressure: The maximum design pressure is 200MPa/2000bar/29000psi, and a sanitary digital diaphragm pressure gauge is selected.
③ Homogeneous flow: With a minimum sample size of 25ml, it is particularly suitable for the production of expensive pharmaceuticals. It features automatic material suction, eliminating the need for feeding equipment.
④ Component Technology: The homogeneous valve seat assembly can be made of materials such as zirconia, tungsten steel, diamond, and stellite, with single/double-sided processing. When used on both sides, the service life is doubled. The secondary valve disperses and emulsifies, ensuring a more uniform distribution of materials.
⑤ Energy-saving technology: The equipment features variable frequency control and can be used by connecting to 220V mains power. Imported brand components ensure greater stability, lower energy consumption, and a higher energy efficiency ratio.
Product model: CBNANO-15
Design flow rate (L/H) ：12~15
Design maximum pressure：
(mpa/bar/psi) 200/2000/29000
Voltage (V) ：Customizable according to your needs
Number of plungers (pieces) ：1
Power (kw) ：2.2
Main functions: homogenization, wall breaking, and refinement (optional chiller for temperature control)
Minimum processing volume: 25ml
Product process viscosity: 2000cp
Maximum feed particle size ≤300μm
Work pressure display Digital pressure gauge
Control mode > Manual operation
Maximum product feeding temperature: 90℃
Weight: 120kg
