WAW-300 300kN 30Ton Computer Servo Hydraulic Horizontal Tensile Testing Machine
US$ 69979.00
≥1 Set
Key Specifications
Get Latest Price
Warranty:
12 Months, 1 year
Model Number:
WAW-3000
Brand Name:
hensgrand
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
WAL-1000 Sling Rope Belt Anchor 100t Universal Horizontal Tensile Testing MachineUS$ 3000 - 9999MOQ: 1 Set -
30 Ton to 100Ton Tension Bench Pulling Tensile Testing Bed MachineUS$ 9000 - 30000MOQ: 1 Set
-
60ton 100Ton Hydraulic Load Test Bench, Horizontal Tensile Testing Bench/universal Sling Tensile Testing BedUS$ 55983.20 - 69979.00MOQ: 1 Set
-
200t Hydraulic Sling Chain and Separating Disc Horizontal Tensile Testing BenchUS$ 10000 - 56000MOQ: 1 Set
-
250 Ton Load Cell Hydraulic Computerized Horizontal Rope Sling Tensile Test BedUS$ 10000 - 90000MOQ: 1 Set
Warranty
12 Months, 1 year
Model Number
WAW-3000
Brand Name
hensgrand
Place of Origin
Shandong, China
Product name
WAW-300 Horizontal Tensile Testing machine
Usage
Long specimen, such as rope, chain, lifting, anchor,etc
Max. Load force
100/300/600/1000/2000/3000/5000KN
Sensor
Load cell
Certificate
CE ISO
Power supply
AC 3 Phase 380V 60/50Hz
Max test space
5m or customized
Max piston stroke
500mm or customized
Grip
Bolt or hydraulic
Customized support
OEM, ODM
Power
Hydraulic
Description
WAW-300 300kN 30Ton Computer hydraulic Horizontal Tensile Tester
Application:
It has widely application, for a variety of long, short sample test, especially for large, long length sample. Common test types such as: wire rope tensile test, lifting belt tensile test, safety rope tensile test, power fittings destruction test, etc
The machine adopting computer control, hydraulic servo drive, hydraulic single-pole bidirectional cylinder loading, precision spoke load sensor signal measuring force value, high accuracy sensor measurement displacement.
Smooth loading, accurate measurement, rapid control response, can achieve load control and displacement (speed) control, a variety of curve form. Can choose (superposition or a single display), can easily and accurately achieve the load, displacement and other digital calibration and verification, with full load protection and position protection, test data can be accessed arbitrarily and can re-analyze data and curves, including local amplification and data re-editing, test methods can be programmed and stored or read, and print out the test reports and curves
2.Standards
ASTMA370, ASTME4, ASTME8, ASTME9, ISO6892, ISO7438, ISO7500-1, EN10002-4, GB/T228-2002, GB 16491-2008, HGT 3844-2008 QBT 11130-1991, GB13-22-1991, HGT 3849-2008,GB6349-1986, GB/T 1040.2-2006, ASTM C165, EN826, EN1606, EN1607, EN12430 etc.
Technical parameter:
Model |
WAW-300/600/1000/2000/3000/5000L |
Max. Load(kN) |
300/600/1000/2000/3000/5000 |
Load accuracy |
Class 1 |
Load range |
2%～100%F·S |
Load resolution(kN) |
1/300000 |
Resolution of displacement (mm) |
0.01mm |
Max tensile space (mm) |
2000 ( can be customized ) |
Cylinder piston stroke(mm) |
1000 ( can be customized ) |
Displacement measuring range(mm) |
0～1000 |
Displacement accuracy |
±1% |
Range of stress loading |
1kN/s～100kN/s |
testing speed (mm/min) |
1~200 |
Piston speed |
0.1-250mm/min |
Power supply |
380 V / 3 phases 50 Hz. |
