250 Ton load cell hydraulic computerized horizontal rope sling tensile test bed
1. Application:
WAL Series Computer Control Hydraulic Servo Horizontal Tensile Testing Machine is suitable for tensile test of long materials like wire rope, cable, nylon rope and chain etc. It applies the full digital controller, servo control system along with the standard analytic software, so it can realize close loop control for load and displacement, digitally setting zero, software/hardware digitally calibrating, protection, limit-position signal input, thus the machine posses user’ programming function. In addition the machine can be equipped with special analytic software and print the report templet according to the requirements from the customers. It’s widely used in some plants who produce longer materials.
2. Standards
ASTMA370, ASTME4, ASTME8, ASTME9, ISO6892, ISO7438, ISO7500-1, EN10002-4, GB/T228-2002, GB 16491-2008, HGT 3844-2008 QBT 11130-1991, GB13-22-1991, HGT 3849-2008,GB6349-1986, GB/T 1040.2-2006, ASTM C165, EN826, EN1606, EN1607, EN12430 etc.
3. Safety Device
2.1 Stroke protection: Machinery,computer double protection, prevent over preset
2.2 Force protection: system setting
2.3 Emergency stop device: handing emergencies
4. Specifications
|
Model |
WAL-5000 |
|
Max. Load(kN) |
5000 |
|
Load accuracy |
Class 1 |
|
Load range |
2%~100%F·S
|
|
Load resolution(kN) |
1/300000 |
|
Resolution of displacement (mm) |
0.01mm |
|
Max tensile space (mm) |
12000 |
|
Cylinder piston stroke(mm) |
1000 |
|
Displacement measuring range(mm) |
0~1000 |
|
Displacement accuracy |
±1% |
|
Range of stress loading |
|
|
testing speed (mm/min) |
1~200 |
|
Piston speed |
0.1-250mm/min |
|
Power supply |
380 V / 3 phases 50 Hz. |
