Help CenterWE-300E 300KN 30T Digital Steel Rebar Hydraulic Universal Tensile Strength Testing Machine
Related Products
-
HST China Servo Hydraulic Testing Machine Hydraulic Material Testing Equipments Universal Testing MachineUS$ 87473.75 - 90972.70MOQ: 1 Set -
HST 300KN Computer Servo Control Utm Universal Tensile Compressiontesting MachineUS$ 73477.95 - 76976.90MOQ: 1 Set
-
WE-600E Digital Hydraulic Universal 600KN 60T Tensile Strength Testing MachineUS$ 7000 - 9000MOQ: 1 Set
-
HST 200Ton 2000kn Steel Rebar Universal Strength Tester Price Tension Test Equipment 100TonUS$ 223932.80 - 244926.50MOQ: 1 Set
-
HST LAW -2000D 2000KN 2000KN Computer Servo Steel Strand Tensile Testing MachineUS$ 31680 - 35200MOQ: 1 Set
WE-1000E 1000kn digital display hydraulic universal steel testing machine
1. Application
Steel Rebar Tensile Testing Machine is suitable for doing testing experiments
such as the tensile, compression, bending and sheartesting for all kinds of metal materials and nonmetal materials such as plastic, concrete, cement and so on.
2. Standards
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
3. Features
3.1 Specially designed extra-thick jaws block,sample clamp more reliable
3.2 Wear-resistant lining,protect jaws block
3.3 Fast operation testing system,multi specimen information imput
3.4 Consistant resolution,make sure data accuracy
3.5 Testing data real time display
3.6 Testing data auto analysis,save and print
3.7 Overload protection
3.8 History record check function
3.9 Software reserved data interface
4. Main Specifications
|
Model |
WE-100E |
WE-200E WE-300E |
WE-600E |
WE-1000EE |
WE-1200E |
WE-2000E |
|||
|
Control Way |
DIgital meter |
||||||||
|
Number of Screw drivers |
4 |
||||||||
|
Max. Load(KN) |
100 |
200 /300 |
600 |
1000 |
1200 |
2000 |
|||
|
Load Accuracy |
≤± 1%/ ≤± 0.5% |
||||||||
|
Load Range |
2%~100%FS |
||||||||
|
Load Resolution |
1/300000 |
||||||||
|
Deformation Measurement Range |
2%~100%FS |
||||||||
|
Deformation Accuracy |
≤± 1% |
||||||||
|
Displacement Resolution |
0.01mm |
||||||||
|
Testing speeds (mm/min) |
0.1~118 |
0.1~123 |
0.1~123 |
0.1~70 |
0.1~70 |
0.1~70 |
|||
|
Adjustable crosshead speed(mm/min) |
450 |
450 |
350 |
350 |
320 |
320 |
|||
|
Displacement Error |
≤±0.5% |
||||||||
|
Max. Piston Stroke(mm) |
200 |
200 |
200 |
200/250 |
250 |
250 |
|||
|
Max. Tension Test Space (mm) |
780 |
780 |
900 |
950/980 |
930 |
1250 |
|||
|
Max. Compression Test Space |
550 |
550 |
650 |
700 |
640 |
850 |
|||
|
Column Effective Spacing(mm) |
485 |
485 |
500 |
560/580 |
610 |
800 |
|||
|
Clamping Method |
Hydraulic Automatic Clamp |
||||||||
|
Flat Specimen Clamping Width(mm) |
80*80 |
80*80 |
90*90 |
100*100 |
120*110 |
150*120 |
|||
|
Compression Plate Size |
Φ 160mm |
||||||||
|
Bending Roller Distance |
450mm |
||||||||
|
Width Of Bending Rollers |
120mm |
||||||||
|
Power Supply |
3-phase, AC380V, 50Hz (Can Be Customized) |
||||||||
