The Scroll Vacuum Pump is a highly efficient vacuum pump, ideal for applications requiring clean, oil-free vacuum. With its compact structure, it occupies minimal space, making it easy to install and move. This pump operates efficiently across a wide vacuum range, from atmospheric pressure to its ultimate vacuum, significantly simplifying the vacuum system.
Specification| Model / parameter | NY-WX-003/NY-WXB-003 | NY-WX-006/NY-WXB-006 | NY-WX-022/NY-WXB-022 | |
| Pumping speed（L/s） | 3 | 6 | 25 | |
| Extreme pressure（pa） | 3/100 | 3/100 | 3/100 | |
| Noise（dB） | 60 | 60 | 65 | |
| Length * width * height（mm） | Explosion proof motor | 463*298*287 | 514*370*333 | 722*442*406 |
| Ordinary motor | 448*218*251 | 489*313*314 | 662*375*406 | |
| weight（kg） | Explosion proof motor | 28 | 46 | 88 |
| Ordinary motor | 18 | 39 | 77 | |
| Intake port | KF25 | KF25 | KF40 | |
| Exhaust port | KF16 | KF25 | KF25 | |
| Pump speed（r/min） | 1400 | 1430 | 1445 | |
| Motor power（kW） | 0.25 | 0.75 | 3 | |
| Power Supply（V/Hz） | 380/50 | 380/50 | 380/50 | |
Scroll Vacuum Pumps are well-suited for a variety of applications, including laboratories, electronics, solar energy, and coating systems. Their oil-free operation ensures a clean vacuum environment, while their low noise and vibration make them ideal for sensitive setups. The simple, reliable design requires minimal maintenance, and the air-cooled structure eliminates the need for cooling water, expanding its application range.
Key Features:
Compact Design: Takes up minimal space and is easy to install and move.
Wide Vacuum Range: Operates efficiently from atmospheric pressure to its ultimate vacuum.
Oil-Free Operation: Ensures a clean vacuum environment.
Low Noise & Vibration: Ideal for sensitive environments.
Low Maintenance: Simple, reliable structure with minimal maintenance required.
Air-Cooled: No need for cooling water, increasing the range of applications.
Eco-Friendly: No emissions, waste, or pollution, reducing disposal costs.
Applications:
Electronics
Laboratories
Solar Energy
Coating Systems
Vacuum Equipment for Analytical Instruments
Oil Recovery Systems in Gas Stations
For more information about the Scroll Pump, contact Nuoxutech
