Help CenterOil Free Air Compressor With Real-Time Pressure Monitoring and Alarm System
Related Products
-
Energy Efficient Oil Free Air Compressor With Isothermal Compression and Low Maintenance CostNegotiableMOQ: 1 Set -
Oil Free Air Compressor 7.5-250KW Water-Cooled or Air-Cooled Models Available for Various ApplicationsNegotiableMOQ: 1 Set
-
Oil Free Air Compressor 50L Tank Capacity With Automatic Pressure ControlNegotiableMOQ: 1 Set
-
Oil Free Air Compressor Replacement With Compact Integrated Design and Stable PerformanceNegotiableMOQ: 1 Set
-
Industrial Oil-Free Water Lubricated Air Compressor 0.8-1.2MPa for Critical ApplicationsNegotiableMOQ: 1 Unit
Jiangsu Saidesi Compressor Co., Ltd., established in 2013 and located in Suqian, China, specializes in manufacturing high-quality Oil Free Air Compressors with Real-Time Pressure Monitoring and Alarm System. Our 1,000-3,000 square meter factory employs 11-50 skilled professionals to deliver reliable compressed air solutions globally. This advanced compressor eliminates oil contamination risks while providing precise pressure control – perfect for sensitive applications requiring clean air.
Key Features:
100% Oil-Free Operation: No lubricant means zero contamination for critical applications
Smart Pressure Monitoring: Digital display shows real-time PSI/bar readings
Safety Alarm System: Audible/visual alerts for abnormal pressure conditions
Low Maintenance Design: Fewer moving parts reduce servicing needs
Energy Efficient: Optimized performance lowers operating costs
Technical Specifications:
| MODEL | Capacity (m²/min) | Water Inlet 32℃ (T/H) | Water (L) | Power (KW) | Noise (dB(A)) | Outlet (INCH) | Dimension (WxDxH mm) | Weight (Kg) |
|---|---|---|---|---|---|---|---|---|
| WSV-10A | 1.2-0.8 | 2.0 | 10 | 7.5 | 58±2 | G3/4" | 800x800x1100 | 510 |
| WSV-15A | 1.6-1.1 | 2.5 | 26 | 11 | 60±2 | G3/4" | 1200x760x1300 | 620 |
| WSV-20A | 2.4-1.8 | 3.5 | 26 | 15 | 63±2 | G3/4" | 1200x760x1300 | 670 |
| WSV-25A | 3.1-2.1 | 4.0 | 30 | 18.5 | 65±2 | G1" | 1400x900x1450 | 720 |
| WSV-30A | 3.5-2.8 | 5.0 | 30 | 22 | 65±2 | G1" | 1400x900x1450 | 760 |
| WSV-40A | 5.1-3.6 | 7.0 | 40 | 30 | 68±2 | G11/4" | 1550x1150x1500 | 1050 |
| WSV-50A/W | 6.3-4.8 | 9.0 | 40 | 37 | 68±2 | G11/4" | 1550x1150x1500 | 1200 |
| WSV-60A/W | 7.4-5.6 | 10.0 | 90 | 45 | 70±2 | G2" | 1800x1300x1750 | 1450 |
| WSV-75A/W | 9.7-7.7 | 12.0 | 100 | 55 | 70±2 | G2" | 1800x1300x1750 | 1550 |
| WSV-100A/W | 13.0-9.7 | 18.0 | 100 | 75 | 73±2 | G2" | 1800x1300x1750 | 1650 |
| WSV-120A/W | 14.8-12.6 | 20.0 | 120 | 90 | 73±2 | G21/2" | 2200x1550x1800 | 2400 |
| WSV-150A/W | 19.8-15.6 | 24.0 | 120 | 110 | 78±2 | G21/2" | 2200x1550x1800 | 2550 |
| WSV-175A/W | 23.1-16.8 | 31.0 | 120 | 132 | 78±2 | G21/2" | 2200x1550x1800 | 2750 |
| WSV-200A/W | 28.1-22.5 | 36.0 | 160 | 160 | 80±2 | G3" | 3000x1800x2100 | 3800 |
| WSV-250A/W | 33.9-25.2 | 38.0 | 160 | 185 | 80±2 | G3" | 3000x1800x2100 | 4000 |
| WSV-280A/W | 36.8-29.1 | 42.0 | 200 | 200 | 80±2 | G4" | 3100x1850x2000 | 4200 |
| WSV-350A/W | 39.7-29.5 | 46.0 | 200 | 220 | 82±2 | G4" | 3100x1850x2000 | 4400 |
| WSV-420A/W | 43.5-34.1 | 52.0 | 200 | 250 | 82±2 | G4" | 3100x1850x2000 | 4600 |
Why Choose Our Compressor?
Precision pressure control (±0.2 bar accuracy)
Stainless steel air path prevents corrosion
Compact footprint saves workspace
Multi-stage filtration system (optional)
Remote monitoring capability (optional upgrade)
With exports to North America, Europe, Asia, and other major markets through Qingdao/Shanghai/Tianjin ports, we've served diverse industries including pharmaceuticals, food processing, and electronics manufacturing. Our compressor's intelligent monitoring system prevents equipment damage from pressure fluctuations, while the oil-free design meets strict air purity standards. Contact us today to discuss your specific compressed air requirements.
FAQ:
Q: What maintenance does this compressor require?
A: Regular filter replacement (every 3-6 months) and annual motor checks are recommended.
Q: Can the alarm thresholds be adjusted?
A: Yes, both high and low pressure alarm points are user-configurable.
Q: Is this suitable for continuous operation?
A: Designed for 24/7 use with proper duty cycle management.
Q: What's the warranty period?
A: Standard 2-year warranty on core components.
Q: Are replacement parts readily available?
A: Yes, we maintain global spare parts inventory.
Q: Can you provide technical support for installation?
A: Remote guidance available, with optional on-site service.
