DIN cast iron globe valve range:
Size DN50~DN250
Pressure:PN10/PN16
DIN cast iron globe valve standard:
Design Standard:DIN 3356
Face to Face:DIN3202-F1
Flange Standard:DIN2532/DIN2533
Testing Standard:ISO 5208
Material of parts:
Body:Cast Iorn/Ductile Iron
Stem:2Cr13/SS304/SS316/Carbon Steel
Disc:A105+2Cr13,2Cr13
Seat:Brass
Product Overview
Our Industrial Flange or BW Ends Cast Iron Forged Stainless Steel Globe Valve is a top - notch product designed to meet the diverse needs of industrial fluid control systems. Manufactured by Chengxin Valve Co., Ltd., a well - established manufacturer since 1993, this valve combines high - quality materials and advanced manufacturing techniques to ensure reliable performance in various applications.
Design and Standards
Standard Compliance: This globe valve adheres to the DIN standard, which is widely recognized and respected in the international market. The DIN standard ensures that the valve meets strict quality and dimensional requirements, making it compatible with other components in industrial pipelines.
Sealing Form: It features a Bellows Globe Valve sealing form. The bellows design provides excellent sealing performance, preventing leakage of fluids even under high - pressure and high - temperature conditions. This sealing form also helps to protect the valve stem from corrosion and contamination, extending the service life of the valve.
Material and Construction
Cast Iron and Forged Stainless Steel: The valve body is made of cast iron, which offers high strength and durability. Cast iron is resistant to wear and corrosion, making it suitable for use in harsh industrial environments. The forged stainless steel components, such as the valve stem and disc, provide superior mechanical properties and corrosion resistance. Stainless steel is known for its ability to withstand aggressive chemicals and high - temperature fluids, ensuring the long - term reliability of the valve.
Flange or BW Ends: This valve is available with either flange or BW (Butt Weld) ends. Flange ends are easy to install and remove, allowing for quick maintenance and replacement. They are also suitable for applications where the valve needs to be connected to other flanged components. BW ends, on the other hand, provide a more permanent and leak - tight connection, which is ideal for high - pressure and high - temperature applications.
Performance and Functionality
Flow Control: The globe valve is designed to provide precise flow control. The valve disc can be adjusted to regulate the flow rate of fluids through the valve. This makes it suitable for applications where accurate flow control is required, such as in chemical processing, power generation, and water treatment plants.
Pressure Resistance: Our globe valve can withstand high pressures, making it suitable for use in high - pressure pipelines. The robust construction and high - quality materials ensure that the valve can operate safely and reliably under extreme pressure conditions.
Temperature Resistance: It can also handle a wide range of temperatures. Whether it is used in low - temperature cryogenic applications or high - temperature steam systems, the valve can maintain its performance and integrity.
Quality Assurance and Certification
Production Certifications: Our company holds ISO9001, ISO14000, and OHSAS18001 certifications. The ISO9001 certification ensures that our manufacturing processes are of high quality and meet international standards. The ISO14000 certification demonstrates our commitment to environmental protection, while the OHSAS18001 certification shows our attention to occupational health and safety. These certifications guarantee that the Industrial Flange or BW Ends Cast Iron Forged Stainless Steel Globe Valve is produced under strict quality control and safety management systems.
Market and Application
Main Markets: Our valve has a significant presence in South America, Eastern Europe, Africa, and the Mid - East. We have an overseas office to better serve our international customers and ensure timely delivery and after - sales support.
Diverse Applications: This globe valve can be used in a variety of industries, including oil and gas, chemical, power, water treatment, and food and beverage. In the oil and gas industry, it can be used for pipeline flow control and wellhead applications. In the chemical industry, it can handle corrosive chemicals. In the power generation industry, it can be used in steam and water systems.
If you are interested in our Industrial Flange or BW Ends Cast Iron Forged Stainless Steel Globe Valve, please feel free to contact our manager, Mr. LI. You can reach him via WhatsApp at +8618333988751 or by mobile phone at 86 - 13231988751. Our company is located at the industrial estate of Weizhuang Town, Longyao County, Hebei Province. With our high - quality products and professional service, we are confident that we can meet your industrial valve needs.
