  1. Product Overview
                The integrated ultrasonic liquid level meter is a non-contact measuring instrument. The ultrasonic pulse emitted by the transmitting ultrasonic transducer propagates through the propagation medium to the surface of the measured object, and after reflection, it returns to the receiving transducer through the sound transmission medium. The time taken for the ultrasonic pulse to propagate from emission to reception in the sound transmission medium is measured. Then, based on the speed of sound in the sound transmission medium, the distance from the transducer to the object surface can be calculated, thereby determining the liquid level.

Main Technical Indicators

  1. 1. Measurement range: 5m, 10m;
  2. 2. Measurement accuracy: 0.25%, 0.5% ;

     3. Display: Chinese and English LCD display;

  1. 4. Resolution: 3mm or 0.1% (whichever is larger);
  2. 5. Analog output: 4-wire 4~20mA/750Ω load; 2-wire 4~20mA/250Ω load;
  3. 6. Power supply: 220VAC, 24VDC (optional);
  4. 7. Ambient temperature: Display instrument -20~60℃, probe -20~80℃;
  5. 8. Protection grade: IP65;
  6. 9. Storage requirements: Corrosive gases (with optional anti-corrosion probe), steam, vibration, dust, and foam in the environment must be specified in advance;
  7. 10. This series of ultrasonic probes can also be customized according to customer needs: special probes such as high pressure resistance, high temperature resistance, small caliber, and small blind zone;
