GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems

GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems thumbnail-1
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems thumbnail-2
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems thumbnail-3
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems thumbnail-4
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems photo-1
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems photo-2
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems photo-3
GE DS215DMCBG1AZZ03A – Processor and Communication Card for Mark V / GE Drive Systems photo-4
US$ 3216.00 ≥1 Blade
Key Specifications
Get Latest Price
I/O Number:
GE DS215DMCBG1AZZ03A
Place of Origin:
America
Communication Interface:
Modubus
Contact Supplier Request Quote Chat Now
Xiamen Xiongba E-commerce Co., LTD
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
I/O Number GE DS215DMCBG1AZZ03A
Place of Origin America
Communication Interface Modubus
Model Number GE DS215DMCBG1AZZ03A
Condition NEW
Warranty One Year
Package Original Packaging
HS Code 853890
Company's Order Placement Process and Guarantees

  • Warranty: 365 days coverage.

  • Lead time: 1 week if in stock; no more than one month at the latest.

  • Payment: 50% advance payment; full payment prior to delivery.

  • Express options: FedEx, UPS, DHL.

  • Each unit is functionally checked before dispatch, with anti-static packaging and shock-safe packing.

Key Features

  • Processor + Comms in one board – Coordinates control tasks while managing plant network traffic, reducing inter-board complexity.

  • ARCNET/Stage Link connectivity (where configured) – Typically supports the Mark V coaxial network for reliable controller-to-panel communications.

  • Backplane integration – Plug-in form factor with GE rack backplane connectivity; no field wiring lands on this board.

  • Firmware carried on socketed devices – The “AZZ03A” suffix indicates a specific hardware/firmware build; EEPROM/PROM sets are usually socketed for serviceability.

  • Form-Fit-Function replacement – Designed to drop into existing Mark V/GE drive cabinets with minimal configuration changes.

  • Diagnostic-friendly – Onboard status LEDs and clear test points (typical for DS215 series) make commissioning and fault isolation faster.

Technical Specifications
Brand / Model GE (General Electric) / DS215DMCBG1AZZ03A
Product Type Processor and communication card for Mark V / GE drive systems
HS Code 8538.90 (Parts suitable for electrical control apparatus)
Power Requirements Backplane supplied; typically +5 VDC and ±15 VDC, power draw
Dimensions & Weight Full-size DS215 PCB; approx. 330 × 280 mm; ~1.0 kg (typical)
Operating Temperature 0 to 60 °C (panel conditioned environment)
Signal Input/Output Types Digital backplane buses; ARCNET coax for plant network; service serial where fitted; no direct field I/O
Communication Interfaces ARCNET/Stage Link (BNC coax, typical); RS-232/RS-485 service; GE backplane interfaces
Installation Method Plug-in rack card; mates to backplane connectors; secure with captive screws; observe ESD precautions
Firmware/Revision Suffix “AZZ03A” indicates specific hardware/firmware build; typically uses socketed PROM/EEPROM sets
Typical Compatibility GE Mark V Speedtronic panels and select GE drive systems using DS200/DS215 backplanes (site verification recommended)
Application Fields

From my experience, this board is most often specified in:

  • Gas and steam turbine controls (Mark V Speedtronic cabinets)

  • GE industrial drives and excitation systems that share the DS200/DS215 architecture

  • Power generation, oil & gas, and metals plants where ARCNET-based panel networks are still standard

“We swapped in a DS215DMCBG1AZZ03A during a planned outage; align the PROM set, verify ARCNET link status, and it just works. Downtime was under two hours.” — Maintenance Supervisor, combined-cycle plant

D1F2A77952A7729F5FB225D562FE4249

Advantages & Value

  • Reliability – GE DS215 boards are known for stable operation in harsh, high-uptime environments.

  • Compatibility – Form-fit-function replacement reduces engineering changes; typically no cabinet modifications.

  • Lifecycle savings – Keeping mature Mark V assets online is often far cheaper than accelerating a full DCS upgrade.

  • Support – We can help match firmware revisions and check site compatibility before you place the order.

Installation & Maintenance

  • Cabinet environment – Install in a clean, dry, ventilated panel. Keep ambient 0–60 °C with stable airflow; avoid dust loading.

  • Power-down & ESD – De-energize the rack before handling. Use a grounded wrist strap and store the board in an ESD-safe bag when not installed.

  • Mounting – Slide the board into the designated slot, mate fully with the backplane connectors, and tighten the captive screws evenly.

  • ARCNET cabling – For coax networks, maintain 93 Ω cable and proper terminators. Check link LEDs and topology if communication alarms appear.

  • Firmware alignment – Match PROM/EEPROM sets to your site configuration. Keep a verified backup of the previous firmware image.

  • Routine care – Inspect connectors annually, clean dust with dry air (low pressure), and log any intermittent faults for trend analysis.

Quality & Certifications

  • Manufactured to GE’s industrial standards; components are typically UL-recognized.

  • CE conformity is usually determined at the panel/system level; board-level marking may vary by revision.

  • RoHS status depends on build date; many earlier revisions are non-RoHS, which is expected for legacy spares.

  • Warranty: 365 days (repair/replace as applicable).

If you share your existing part label or a photo of the PROM set, we can typically confirm drop-in compatibility for DS215DMCBG1AZZ03A before shipment. You might notice that this simple check avoids most commissioning surprises.
