7BBL Brewhouse System Craft Beer Production Equipment Needed To Brew Beer
Project Recommend
7BBL wine craft beer brewing equipment brewhouse system equipment
We are factory supplied with good quality,more competitive price and installation service. Lifetime guarantee are assured.
Whether you are creating a business or brewery renovation project, come here!
A perfect solution is always for you!
* Less capital investment, quick return
* Flexible configuration, easy follow brewing
* Health, safety life style, and potential market
Investing a brewery in local region
* Cope with the hand-brew market demand
* Customize design,meet the diverse need
* Warranty for 3 years and lifetime repair guarantee
Kelang company is an international comprehensive enterprise specializing in R&D,production,technical support and services for beer equipment and wine equipment.The product includes large,medium and small brewery equipment,hotel,taproom,bars brewed beer equipment,teaching laboratory equipment,various types of wine equipment,and provide beer equipment accessories, auxiliary equipment,control equipment,supply the main and auxiliary materials of beer brewing,brewing technique training and other services.
Capacity/batch | 100L | 200L | 300L | 500L | 1000L |
Model | TS-100L | TS-200L | TS-300L | TS-500L | TS-1000L |
Area | 15M2 | 25M2 | 35M2 | 45M2 | 80M2 |
Power | 8kw | 12kw | 20kw | 35kw | 35/15kw |
Frementation cycle | 8~20days | 8~20days | 8~20days | 8~20days | 8~20days |
Note:1.1Hectolitre(HL)=100Liter; 1Barrel(BBL)=117Liter
2.Water supply: water supply, for mashing, cooling, cleaning
3. Electricity supply: 3-phase electricity
4. Voltage/frequency adjust to your local power supply
5.Material: malted barley or wheat, hops, water
Conical dimple jacketed SUS304 fermentation tank 1000L
Fermentation system
Fermentation systems consists of Fermentation Tank and Bright Beer Tank.Fermentation Tank structure and design differs depending on fermentation process.
The component can be seen by the table below.
Fermenter | SUS304 | 100L/200L |
Interior | SUS304 | Thickness 2.5mm |
Exterior | SUS304 | Thickness 1.5mm |
Bottom cone | 60 degree | Yeast outlet |
Cooling method | Glycol cooling | Dimple jacket |
Temperature control | PT100 | |
Pressure display | Pressure gauge | |
Pressure relie | pressure relief valve | |
Cleaning | SUS304 | CIP arm with 360 spary cleaning ball |
Insulation layer | Polyurethane | 70~80mm |
Manway | SUS304 | Clamp or flange manway |
Sampling valve | SUS 304 | Aseptic type, no dead coner |
Dry hops adding port | SUS304 | Optional, clamp type |
Carbonation device | SUS304 | Optional |
Yeast adding tank | SUS304 | 1L/2L |
Bright beer tank | SUS304 | 100L/200L, single or double walled available |
