Home > Metallurgy, Mineral & Energy > Alloy > Titanium Alloy > Incoloy 400 Nickel Alloy Plate & Sheet Laser Cutting Alloy Plate
Incoloy 400 Nickel Alloy Plate & Sheet Laser Cutting Alloy Plate
Negotiable
MOQ: 100000 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other
Shape:
Other
Color:
Titanium Gold
Payment & Shipping
Payment Methods:
Port of Shipment:
TIANJIN
Delivery Detail:
15 days
Related Products
-
Hot-Dipped Zinc Aluminium Alloy Coated 400 Aluminized Zinc Sheet PlateNegotiableMOQ: 1 Meter -
ASTM 400 Grade B Mild Carbon Steel Plate Hot Rolled Alloy Steel Sheet Iron Hot Rolled Steel Plat PriceNegotiableMOQ: 100000 Meters
-
Metal Aluminium 400 Alloy Al Aluminum Alloy Forged PlateUS$ 50 - 80MOQ: 1 Meter
-
Good Price China Manufacturers 3mm 2.5mm 400 Alloy Aluminum Sheet PlateUS$ 50 - 80MOQ: 1 Meter
-
Monel 400/K500 Copper Nickel Alloy Strip/Coil/Pipe/Tube/Round Bar/Rod/Plate/Sheet MonelNegotiableMOQ: 100000 Tons
Material
Other
Shape
Other
Color
Titanium Gold
Surface Treatment
Other, Coated
Specification
Thickness: 12mm
Origin
CHINA
| Commodity | 201 304 316 310s stainless steel 4x8 sheet metal prices per kg |
| Thickness | 0.3 mm-3mm |
| Width | 1219mm, 1250mm, 1524mm, 1500mm , etc |
| Length | 2000mm-6000mm or as customer request |
| Standard | AISI, ASTM, EN, BS, GB, DIN, JIS, etc |
| Material | 201, 202, 301, 321, 304, 304L, 316, 316L, 309S, 310S, 410, 410S, etc |
| Surface | 2B, BA, HL, 8K, No. 4, etc |
| Brand name | TISCO, BAOSTEEL |
| Packaging | Pallet and Waterproof material wrapped |
| Technique | Hot rolled / cold rolled |
| Delivery time | 7-25 working days after receiving the deposit. |
| Supply ability | 10000 metric tons/ month |
| Certification: | ISO9001: 2008 |
| Payment terms | 30% TT as deposit , the balance by TT or L/C at sight. |
| Applications | Stainless Steel hot rolled plate applies to construction field, ships building industry, petroleum and chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields. |
| Advantages | Strong corrosion and decorative effect; Excellent and high quality control; competitive price; Timely, reliable and efficient delivery; Customer service. Cheap, better, faster |
| Note | We can produce other standard as the customers' requirement |
Hot rolled Cold Rolled ASTM 304 4' x 8' stainless steel sheets , 304 4'x8' stainless steel sheets
Description
Inox steel plate,inox steel sheet,stainless steel sheet,stainless steel plate,cold rolled/hot rolledstainless steel sheet,ASTM stainless steel plate,stainless steel,plate
Standard
ASTM A240,JIS G4304, G4305,GB/T 4237,GB/T 8165,BS 1449,DIN17460,DIN 17441
Material
201,202,304,304L,309S,310S,316,316L,316Ti,317L,321,347H,409,409L, 410,420,430,904L
Model No.
304,0Cr18Ni9,EN1.4301,SUS304,TP304
Surface
No.1, No.4,2D,No.8,2B,BA,No.3,Hair line,Brushed,checkered,sand blast,checkered,embossed, mirror,8k,bright,etc
Exported to
USA,Germany,India,Iran,Dubai,Iraq,Viet Nam,Ireland,Sinagpore,Russia,Chile,Brazil,Argentina, Indonesia,Korea,and so on
Thickness
Form 0.1mm to 150mm
Width
1000mm,1219mm(4feet),1500mm,if you need,we can cut as your required.
Length
2000mm,2440mm(8feet),6000mm,or cut as your required.
Payment terms
T/T ,L/C, Western Union
Price terms
Ex-work,FOB,CIF,CFR,CNF
Application
Plate apply to construction field,shipbuilding industry,petroleum&chemical industry,war and electricity industries,food processing and medical industry,boiler heatexchanger,machinery and hardware fields.
Also can be made according to the customer's required.
Package
Standard export seaworthy packing:
1. bundle package 2. wooden case,wooden pallet package ntainer or bulk
4. special according to customer request
Delivery Time
1.The products in stock will delivery immediately received the payment.
2.According to the order quantity,promopt delivery.
Quality control
Mill Test Certification is supplied with shipment,Third Part Inspection is acceptable.
Container Size
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM
Contact
If you have any needs,pls feel free to contact me.
Finishings of Stainless Steel Sheets
| No.03 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. |
Kitchen utensils,Building, construction |
| No.04 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. |
Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size |
Building Construction. |
| Mirror No.08 | Shinning like a mirror |
Builiding Construction |
INCOLOY alloys belong to the category of super-austenitic stainless steel alloys. Nickel, chromium and iron are the principal constituents of this alloy. By adding different additives this alloy can be made to resist different chemical reagents. Good strength and resistance to corrosion are characteristics of these alloys.
Additives such as molybdenum and nitrogen are added to the alloy in order to increase its resistance to pitting, crevice corrosion and thermal stability. The nickel and chromium content extend the corrosion resistance of this alloy over a wide range of environments like non-oxidizing acids, aqueous, caustic chlorides, halides and pulp-mill bleaches. This alloy is available in the form of bars, billets, sheets, round, plate, strips and wire.
This datasheet will look into the chemical composition, properties and applications of INCOLOY 25-6MO.
Chemical Composition
The chemical composition of INCOLOY alloy 25-6MO is given in the following table.ElementContent (%)
| Iron, Fe | 47.3 |
| Nickel, Ni | 24-26 |
| Chromium, Cr | 19-21 |
| Molybdenum, Mo | 6-7 |
| Manganese, Mn | ≤2 |
| Others | Remainder |
Physical Properties
The following table discusses the physical properties of INCOLOY alloy 25-6MO.PropertiesMetricImperial
| Density | 8.03 gm/cm3 | 0.290 lb/in3 |
Mechanical Properties
The mechanical properties of INCOLOY alloy 25-6MO are tabulated below.PropertiesMetricImperial
| Tensile strength(annealed) | 689 MPa | 100 ksi |
| Yield strength(annealed) | 331 MPa | 48 ksi |
| Elongation at Break( in 2 in 50 mm) | ≥42% | ≥42% |
| Hardness, Rockwell B | 86 | 86 |
| Modulus of Elasticity | 188 GPa | 27300 ksi |
| Poissons Ratio | 0.33 | 0.33 |
Other Designations
Some of the designations used to denote INCOLOY alloy 25-6MO are listed below:-
UNS N08926
Fabrication
Machinability
Machining characteristics of this INCOLOY alloy 25-6MO is similar to that of other austenitic alloys.
Machining of INCOLOY alloy 25-6MO should be done at a slightly lower speed when compared stainless steel using rigid tooling and optimum lubrication and cooling.
Welding
INCOLOY alloy 25-6MO can be welded by gas metal arc welding, gas tungsten arc welding, shielded arc welding, plasma arc welding and submerged metal arc welding. The filler metal and electrodes are usually made of INCONEL alloy.
Hot working
INCOLOY alloy 25-6MO can be hot worked at temperature ranges of 980-1150°C (1800-2100°F).
Cold Working
Cold rolling may be done on the alloy after annealing.
Annealing
INCOLOY alloy 25-6MO should be annealed at temperatures greater than 1175°C (2150°F).
Applications
The INCOLOY alloy 25-6MO is used in the following applications:
Chemical and food processing
Paper bleaching plants
Marine and offshore platform equipment
Air pollution control systems
Salt plant evaporators
Condenser tubes, service water pipes and feed water heaters.
2. Our Service For You
Pre-sale Service
1. Sample can be offered with sample charge and courier fee by buyer's side.
2. We have full stock,and can deliver within short time.Many styles for your choices.
3. OEM and ODM order are accepted, Any kind of logo printing or design are available.
4. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you
5. All of our products are produce by our professional workman and we have our high-work-effect foreign trade team,you can totally believe our service.
