Help CenterHastelloy Monel 400 K500 Nitronic Nickel Alloy Steel Sheet/Plate
Related Products
-
High-Performance Inconel 625 and Monel 400 Customizable PlatesUS$ 50 - 80MOQ: 1 Meter -
Wholesale Hardware Spare Parts Monel 40 Steel Wear-Resistant Cold-Rolled Steel PlateUS$ 50 - 80MOQ: 1 Meter
-
Monel 400 Nickel Base Alloy Plate Hot Rolled Stainless Steel Sheet Alloys Steel Shees Price Per KgNegotiableMOQ: 100000 Tons
-
China Factory High Quality 1mm 2mm 400/ Monel 400 Nice Price 3mm 4mm Alloy Monel Nickel Copper Metal Sheet/PlateNegotiableMOQ: 100000 Meters
-
High Quality Pure Nickel Sheet Monel 400 Plate Electrolysis/Anode Price Per KgNegotiableMOQ: 1 Meter
Monel 400 is a nickel-copper alloy (about 67% Ni - 23% Cu) that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. Alloy 400 is a solid solution alloy that can only be hardened by cold working.
This nickel alloy exhibits characteristics like good corrosion resistance, good weldability and high strength. A low corrosion rate in rapidly flowing brackish or seawater combined with excellent resistance to stress-corrosion cracking in most freshwaters, and its resistance to a variety of corrosive conditions led to its wide use in marine applications and other non-oxidizing chloride solutions.
Features:
* Resistant to seawater and steam at high temperatures
* Excellent resistance to rapidly flowing brackish water or seawater
* Excellent resistance to stress corrosion cracking in most freshwaters
* Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated
* Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but is seldom the material of choice for these acids
* Excellent resistance to neutral and alkaline salt
* Resistance to chloride induced stress corrosion cracking
* Good mechanical properties from sub-zero temperatures up to 1020° F
* High resistance to alkalis
* Industrial heat exchangers
* Chlorinated solvents
* Crude oil distillation towers
* Chemical and hydrocarbon processing equipment
* Gasoline and freshwater tanks
* Crude petroleum stills
* De-aerating heaters
* Boiler feed water heaters and other heat exchangers
Chemical Composition | |||||||
Grade | Ni% | Cu% | Fe% | Mn% | C% | Si% | S% |
Monel 400 | Min 63 | 28-34 | Max 2.5 | Max 2.0 | Max 0.30 | Max 0.50 | Max 0.024 |
Monel 400 International Brand | ||||
USA | GE | UK | FR | |
UNS | VDIUV | BS | AFNOR | |
Monel 400 | N04400 | W.Nr.2.4360 NiCu30Fe | NA 12 | Nu 30 |
Physical Properties | ||
Grade | Density | Melting Point |
Monel 400 | 8.83 g/cm3 | 1300ºC-1390ºC |
Mechanical Properties | ||||
Alloy | Tensile Strength (Rm N/mm2) | Yield strength (RP0.2N/mm2) | Elongation(A5%) | HB |
Monel 400 | 480 | 170 | 35 | ≥331 |
Production Standard | |||||
Bar | Forging | Pipe | Sheet/Strip | Welding Wire | |
Standard | ASTM B164 | ASTM B564 | ASTM B165 | ASTM B127 | ERNiCu-7 |
Zhongzheng Stainless Steel Co., Ltd. was established in 2018 with aregistered capital of 20 million yuan. lt is a manufacturing company thatintegrates the production of special materials, manufacturing andprocessing, sales, and technology development. The company covers anarea of 2,000 square meters and has 200 employees. it has built worldclass stainless steel seamless pipe (hot piercing, cold drawing, cold rollingproduction lines, precision steel pipe production lines, and large, mediumand small-sized welded pipe production lines. The company has beencommitted to providing high performance, high precision, hightemperature-resistant, high pressure-resistant, and corrosion-resistantsolutions and technical services for industrial equipment pipeline systems.The company specializes in producing a series of steel pipes, pipe fittingsflanges, etc., such as high-temperature (nickel-based) alloys, austeniticduplex steel, urea grade stainless steel, super stainless steel, etc. Thecompany is equipped with an annual production capacity of 5,000 tons ofstainless steel seamless pipe production line, 7,000 tons of welded pipeproduction line, and 500 tons of pipe fittings production line, etc. lt canoroduce stainless steel seamless pipes with diameters ranging from Φ6 toΦ762 and wall thicknesses ranging from 0.5 to 70 mm, stainless steelwelded pipes with diameters ranging from Φ15 to Φ2200 and wallthicknesses ranging from 0.5 to 80 mm, pipe fittings, and various stainlesssteel ingots, round steel, rough pipes, etc., according to customerrequirements and in accordance with standards such as GB, ASTM, etc.
Packaging & Delivery
The company has strong strength and has a professional and technical teamwith excellent technology and rich experience.The company has also introduced advanced production equipment andprocessing technology, which can provide customers with steel products ofvarious specifications and processing requirements. At the same time, thecompany has also established a complete after-sales service system to providecustomers with first-class services.
