ABB UAC318AE (HIEE300744R0001) – Communication Interface Module for Advant Controller Systems

The ABB UAC318AE, part number HIEE300744R0001, is a communication interface module designed for ABB Advant Controller installations. In many cases it’s used to connect legacy Advant/AC 4xx controllers with serial devices or controller-to-controller links, keeping mature plants talking to modern equipment without a full DCS migration.

From my experience, plants typically drop the UAC318AE into an existing Advant rack to add robust, isolated serial connectivity and leverage proven diagnostics. It seems to be a straightforward way to extend life-cycle and avoid re-engineering field wiring.

• Native Advant compatibility – Fits ABB Advant Controller 4xx/OCS racks via the backplane; no external power needed at the module.

• Isolated serial communications – Typically provides one or more isolated serial channels (RS‑232/RS‑485) for linking drives, protection relays, analyzers, and third‑party PLCs.

• Deterministic backplane integration – Low latency data exchange with the controller CPU for stable cyclic updates.

• Front-panel diagnostics – Status LEDs and clear fault indications speed up commissioning and troubleshooting.

• Protocol flexibility – Often configured for common serial protocols (e.g., Modbus RTU/ASCII or peer messaging on Advant/MB 300 segments), depending on firmware options.

• Industrial temperature and EMC design – Built for cabinet environments with good immunity to noise and typical 0…55 °C operating range.

You’ll usually see UAC318AE applied where a legacy Advant controller needs serial links to field assets or third-party skids. Typical areas:

• Oil & Gas – compressor control panels, metering skids, burner management serial links.

• Power Generation – excitation systems, vibration monitoring racks, PLC-based auxiliary equipment.

• Chemicals & Petrochem – analyzers, packaged units, and legacy drives on RS‑485.

• Pulp & Paper / Metals – machine section PLCs, weighers, and protection relays.

•


• Lifecycle extension – Keeps established Advant installations productive without forcing a controller upgrade.

• Interoperability – Bridges to Modbus/serial ecosystems and existing MB 300 segments, reducing custom engineering.

• Low risk integration – Backplane-native, with clear diagnostics and stable firmware baselines.

• Cost control – Avoids re-wiring and re-commissioning of proven plant assets; shorter shutdown windows.

• Supportability – Widely installed in the field; spares strategies are straightforward in most cases.

A maintenance lead in a power plant told me they swapped in UAC318AE during a planned stop to pick up a new analyzer skid. “Configuration was predictable, and the LED diagnostics saved us an hour during I/O checks,” was the gist.

• Cabinet & environment – Mount in a clean, ventilated control cabinet (typically 0…55 °C). Keep clear airflow around the rack and avoid high-vibration spots.

• Wiring – Use shielded twisted pair for RS‑485; ground shields at one end as per site EMC practice. Observe maximum segment length for the baud rate used.

• ESD & handling – Treat as a static‑sensitive device. Insert firmly along guide rails to ensure full backplane engagement.

• Commissioning – Verify firmware revision compatibility with your controller image. Set port parameters (baud, parity, addressing) and confirm status LEDs indicate healthy link.

• Routine upkeep – Periodically check terminal tightness, inspect connectors for oxidation, back up configuration files, and schedule firmware updates during planned outages if applicable.

• CE marked; designed for industrial EMC and Low Voltage Directive compliance.

• Manufactured under ISO 9001 quality systems; RoHS conformity typically available for current builds.

• UL/cUL markings may apply depending on region and batch; verify against the product label.

• Standard commercial warranty is commonly 12 months from shipment; extended coverage can be arranged in many cases.

• Advant Controller AC 4xx CPUs (e.g., PM5xx family) – host controller for the UAC318AE.

• Advant rack and power units – provide the backplane power and mechanical slotting.

• Shielded RS‑485/RS‑232 cable kits – for reliable device connections in noisy environments.

If you can share your controller type, firmware revision, and the serial protocol you’re targeting, I can confirm port counts and exact compatibility for UAC318AE in your setup.
