EXIDE Traction Battery 12 BSX200 24V200Ah Linde 24V 2PZB200
Cell Designation
2PZJD160 3PZJD240 4PZJD320 5PZJD400 6PZJD480 7PZJD560 8PZJD640
2PZJD230 3PZJD345
4PZJD460 5PZJD575 6PZJD690 7PZJD805 8PZJD920
2PZJD250 3PZJD375 4PZJD500 5PZJD625 6PZJD750 7PZJD875 8PZJD1000
2PZJD280 3PZJD420 4PZJD560 5PZJD700 6PZJD840 7PZJD980 8PZJD1120
2PZJD310 3PZJD465 4PZJD620
5PZJD775 6PZJD930 7PZJD1085 8PZJD1240
EXIDE Traction Battery 12 BSX200 24V200Ah Linde 24V 2PZB200
HAWKERPZS
2PZJD160 3PZJD240 4PZJD320 5PZJD400 6PZJD480 7PZJD560 8PZJD640
2PZJD230 3PZJD345
4PZJD460 5PZJD575 6PZJD690 7PZJD805 8PZJD920
2PZJD250 3PZJD375 4PZJD500 5PZJD625 6PZJD750 7PZJD875 8PZJD1000
2PZJD280 3PZJD420 4PZJD560 5PZJD700 6PZJD840 7PZJD980 8PZJD1120
2PZJD310 3PZJD465 4PZJD620
5PZJD775 6P
HAWKERPZS
2PZJD160 3PZJD240 4PZJD320 5PZJD400 6PZJD480 7PZJD560 8PZJD640
2PZJD230 3PZJD345
4PZJD460 5PZJD575 6PZJD690 7PZJD805 8PZJD920
2PZJD250 3PZJD375 4PZJD500 5PZJD625 6PZJD750 7PZJD875 8PZJD1000
2PZJD280 3PZJD420 4PZJD560 5PZJD700 6PZJD840 7PZJD980 8PZJD1120
2PZJD310 3PZJD465 4PZJD620
The 5PZJD775 6P HAEWKERPZS series battery is a highly reliable and cost-effective battery. This new series of products adheres to the technological characteristics of Hawker Power as a global leader in industrial batteries. A super cost-effective electric forklift battery.
Product Structure
HAWKERPZS's essential series products are new European designed open lead-acid batteries, using DIN and JIS specifications.
This series of products has a sturdy structure and adopts mature tubular electrode plate technology. The battery cells and battery covers are made of high-temperature resistant polypropylene material welded through heat sealing technology, which can effectively prevent acid leakage.
The battery cells are installed in customized boxes, connected by flexible bolts, sealed and insulated with connecting strips, ensuring safety, reliability, and easy maintenance.
The exhaust port cover adopts a flip design and is equipped with an electrolytic liquid level mark, which is safe to use and can fully discharge the gas released during charging, making maintenance convenient.
Optional
The electrolyte float and electrolyte warning light of JIS series batteries can be installed according to the height of the battery.
The water addition system is also available for ordering. This system can safely add water to the most suitable location through a water addition device, and can greatly shorten the water addition time.
It is recommended that users choose Hawker modular high-frequency chargers to be used in conjunction with batteries. Choosing chargers of the same series can keep the battery charging in the best condition, thereby maximizing the battery's service life.
The charger uses high-quality electronic components, and a perfect charging curve can not only optimize battery charging, but also save a lot of power consumption, which is energy-saving and environmentally friendly.
HAWKER charger adopts innovative module design, making maintenance and use more convenient.
Characteristics
High reliability and cost-effectiveness
Advanced structure, high-quality components
Suitable for most brand hosts and vehicle models
Hawker Power Group's globally unified design and manufacturing process
Our branches are located in various regions, providing convenient and timely service and support
PzJD&PzJB cells-Hawker essential,bolt-on connectors,dimensions resembling DIN/EN 60254-2,IEC 60254-2,GBT 7403-1/2ZJD930 7PZJD1085 8PZJD1240
EXIDE Traction Battery 12 BSX200 24V200Ah Linde 24V 2PZB200
EXIDE Traction Battery 12 BSX200 24V200Ah Linde 24V 2PZB200
The XFC battery series for Enersys' Hawk material processing equipment has been expanded to include a 2-volt battery series with flexible charging options.
As shown in the Hawker XFC series, the 2V battery uses a thin pure lead plate, which can operate in a partially charged state and can work at high discharge rates.
Users can fully utilize flexible charging as the battery can be charged as needed at any time. The battery can be quickly charged from 60% of the Ministry of Defense in less than four hours, or alternatively charged without damage.
They are made of lead plates, much thinner than the lead antimony grids used in other power batteries. This allows them to maintain 30% more power and provide 20% more electricity. A low impedance board means that a high current positive electrode can be obtained during discharge and recharge.
The electrolyte is absorbed in a high-quality microporous glass pad separator, which has high absorption and stability, and can provide up to 1200 cycles of stable performance at a discharge depth of 60%.
The Hawker Range currently has 30 batteries. Their capacity range is 130 to 750 Ah, with various standard industrial sizes suitable for industrial and material handling applications.
Enersy Hawker Power XFC Series
The success of thin sheet pure lead technology led to Hawker ® Development of XFC 2-volt Battery Series ™ Batteries to meet the requirements of various material processing equipment. With the increase of energy density and the improvement of fast charging capability, these maintenance free batteries can be used at any time and charged whenever possible. Advanced communication with Hawker HF chargers, Life IQTM, and LifeSpeed IQTM ensures long-term high performance and energy efficiency.
Enersys Hawker Motive Power XFC Bloc Series
These pure lead maintenance free batteries have excellent cycling performance (up to 1200 cycles at 60% DOD) and very fast charging (less than 5 hours using the relevant HF charger at 60% DOD).
Hawker ® XFC ™ The Bloc battery solution provides complete freedom of use, without the need to extend charging time, and allows users to "opportunity to charge", providing almost continuous machine availability: charging whenever possible (during breaks, at the end of shifts).
Battery technology has taken a step forward - providing true 'daytime cleaning' flooring and fast cycling capabilities in all other applications: pallet trucks AGV、 Transport vehicles and electric industrial vehicles
oduct Voltage (V) Capacity (Ah) Dimension (mm) Weight (kg) Terminal
5Hr L W H
6XFC130 2 130 47 198 370 8.9 Bolt On Connectors
9XFC195 2 195 65 198 370 12.6 Bolt On Connectors
12XFC260 2 260 83 198 370 16.4 Bolt On Connectors
15XFC325 2 325 101 198 370 20.1 Bolt On Connectors
18XFC390 2 390 119 198 370 23.8 Bolt On Connectors
6XFC164 2 164 47 198 435 10.8 Bolt On Connectors
9XFC246 2 246 65 198 435 15.3 Bolt On Connectors
12XFC328 2 328 83 198 435 19.8 Bolt On Connectors
15XFC410 2 410 101 198 435 24.4 Bolt On Connectors
18XFC492 2 492 119 198 435 29.0 Bolt On Connectors
6XFC130 9XFC195 12XFC260 15XFC325 18XFC390 6XFC164 9XFC246 12XFC328 15XFC410 18XFC492 6XFC190 2 190 47 198 505 12.2 Bolt On Connectors
9XFC285 2 285 65 198 505 17.4 Bolt On Connectors
12XFC380 2 380 83 198 505 22.6 Bolt On Connectors
15XFC475 2 475 101 198 505 27.8 Bolt On Connectors
18XFC570 2 570 119 198 505 33.0 Bolt On Connectors
6XFC220 2 220 47 198 541 13.8 Bolt On Connectors
9XFC330 2 330 65 198 541 19.8 Bolt On Connectors
12XFC440 2 440 83 198 541 25.7 Bolt On Connectors
15XFC550 2 550 101 198 541 31.6 Bolt On Connectors
18XFC660 2 660 119 198 541 37.6 Bolt On Connectors
6XFC234 2 234 47 198 574 14.8 Bolt On Connectors
9XFC351 2 351 65 198 574 21.1 Bolt On Connectors
12XFC468 2 468 83 198 574 27.5 Bolt On Connectors
15XFC585 2 585 101 198 574 33.8 Bolt On Connectors
18XFC702 2 702 119 198 574 40.2 Bolt On Connectors
6XFC250 2 250 47 198 600 15.6 Bolt On Connectors
9XFC375 2 375 65 198 600 22.2 Bolt On Connectors
12XFC500 2 500 83 198 600 28.8 Bolt On Connectors
15XFC625 2 625 101 198 600 35.5 Bolt On Connectors
18XFC750 2 750 119 198 600 42.1 Bolt On Connectors
Product Voltage (V) Capacity (Ah) Dimension (mm) Weight (kg) Terminal
5Hr L W H
12XFC25 25 250 97 144 9.6 M6 Female
12XFC35 35 250 97 194 13.2 M6 Female
12XFC48 48 220 121 248 18.7 M6 Female
12XFC58 58 280 97 248 19.1 M8 Female
12XFC60 60 329 166 166 24.2 M6 Female
12XFC82 82 395 105 248 27.2 M8 Female
12XFC85 85 302 175 227 31.5 M6 Female
12XFC115 115 338 173 273 43.0 M6 Female
12XFC158 158 561 125 263 50.8 M8 Female
12XFC177 177 561 125 297 58.8 M8 Female
HAWKERPZS,HAWKER,2PZB200,24V25Ah,HAWER,USA,HAWKER (MSDS,)
Dangerous goods certificate, cargo transportation appraisal report (sea/air/railway/road) for foreign and export trade.
AGV Batteries，HAWKER，HUADA HAWKER，
