HAWKERPZS SGC-TO-S3B-1099 Lithium Iron Phosphate Battery 51.2V560Ah TOYOTA

HAWKERPZS SGC-TO-S3B-1099 Lithium iron phosphate battery 51.2V560Ah TOYOTA

cif price

Manufacturer Toyota

Model SGC-TO-S3B-1099

Capacity and voltage 560 ampere hours -51.2 volts

Color Black

Thickness 5T

Connector SB350

Weight 1099 kilograms

Size specification 811 × 740 × 555

cif price

Manufacturer Italy

Model SGC-61T-D1D-2130

Capacity and voltage: 608 ampere hours -80 volts

Color Black

Thickness 10T

Connector DIN320

Weight 2130 kilograms

Size specification 1410 × 740 × 830

Hawker Power Forklift Lithium Battery

Hawker Power Forklift Lithium Battery

Nominal voltage: 72V, 96V nominal capacity: 20-1000AH operating temperature: charging 0-45 ℃, discharging -20-60 ℃ Application field: industrial special equipment;

Order model

Nominal voltage (V)

Capacity (Ah)

size

（mm）

weight

(Kg)

EV72-86-L

seventy-three point six

eighty-six

750*380*252

two hundred and fifty

EV72-206-L

seventy-three point six

two hundred and six

850*450*340

five hundred and fifty

EV72-618

seventy-three point six

six hundred and eighteen

797*714*368

six hundred and thirty

EV96-412

ninety-six

four hundred and twelve

1590*500*500

five hundred and fifty

EV 96-206

ninety-six

two hundred and six

602*400*462

three hundred

EV96-277

ninety-six

two hundred and seventy-seven

1100*500*290

two hundred and seventy-seven

EV72-160 battery specifications can be customized. For more information, please contact Hawker Battery Wang Zelong

Battery type: Lithium iron phosphate battery

Maximum charging current: 1C

Maximum discharge current: 2C

Instantaneous discharge current: 3C

Discharge cut-off voltage: 66.7 V/87 V

Charging upper limit voltage: 84V/109.5V

Charging temperature: 0-45 ℃

Discharge temperature: -20~60 ℃

Storage temperature: -20~60 ℃

Temperature protection: 65 ℃± 5 ℃

Battery casing: Sheet metal casing

Port Design: Different Ports

Lithium battery protection: short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, temperature protection, etc

Communication interfaces: 485, CANOPEN, CAN, AO (0-5V represents 0-100%), DO (2 channels), DI, etc

Application areas: AGV, mobile robots, industrial machinery and equipment, emergency power supply, etc

Product Features

Fast charging: Supports 2C fast charging, and can be fully charged in up to half an hour.

Port design: Charging and discharging port design, supporting simultaneous charging and discharging without disturbing each other.

Self developed BMS:

A battery management system for mobile robots with rich communication interfaces.

It can achieve the function of recording, storing, and exporting fault data.

The control system is designed with extremely low power consumption. Shutdown status 30uA, power on status 30mA

Support customization of various non-standard functions.

Environmentally friendly and long-lasting: using automotive grade power lithium iron phosphate battery cells with high cycle life, in line with the values of low-carbon, energy-saving, and environmental protection;

Professional design: By filling the shock-absorbing structure inside the cold-rolled sheet metal shell, the requirements of strong heat dissipation, high safety, and high reliability are achieved.
