HAWKER AX12-200 AGV BATTERY 12V200AH HAWKERPZS RGV BATTERY AGV-200
US$ 290.81 ≥1 Piece
Key Specifications
Get Latest Price
Type:
Lead-Acid Batteries
Usage:
Other, AGV，RGV
Discharge Rate:
High Discharge Rate
Contact Supplier Request Quote Chat Now
Hawker Battery Group Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Hong Kong
Delivery Detail:
5 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Lead-Acid Batteries
Usage Other, AGV，RGV
Discharge Rate High Discharge Rate
Rechargeable Chargeable
Electrolyte Other, lead-acid battery
Nominal Voltage 12V
Transport Package export wooden crate
Specification 12V200AH
Trademark HAWKERPZS
Origin CHINA

HAWKER AX12-200 AGV BATTERY 12V200AH HAWKERPZS RGV BATTERY AGV-200


国际店铺

　　Detailed description


　　Mobile machines,including all kinds of mobile intelligent robots and AGV vehicles,the power of its own source is the battery.In order to ensure that the mobile machinery can be continuous,stable,safe and reliable work,reasonable configuration of power supply,choose to use high efficiency,and low cost battery,it is very important.


　　Hawker Power Group Limited is the world's most advanced power supply manufacturer.To meet the requirements of emerging applications,with its advanced manufacturing equipment and processes,the latest patented technology and materials,designed for mobile mechanical power supply adsorption(AGM)AX series maintenance-free lead-acid sealed batteries.The series of batteries in strict compliance with the international standard battery production,not only to strengthen the deep cycle discharge and fast charge capacity,but also improve the use of security and reliability,no damage to equipment and the environment,no pollution.


　　Follow the standard


　　●Product design in line with international standards IEC 60896/21-22


　　●In accordance with the Eurobat guidelines issued in 1999,this series of products belong to the"long life"category


　　●Complies with Telcordia SR-4228


　　●UL certification(UL standard 1989)


　　●According to the US"DOT Regulation 49"and the ICAO ICAO and IATA"Packaging Directive 806",it was approved as a non-dangerous goods suitable for land,sea and air transport


　　●certified by ISO 9001:2000 and ISO 14001:2004 certified Hawker factory production


　　Specifications and technical specifications


　　Types


　　parameter


　　AGM(Adsorption)AX Series


　　AX12-18


　　AX12-26


　　AX12-33


　　AX12-45


　　AX12-60


　　AX12-75


　　AX12-100


　　AX12-120


　　AX12-150


　　AX12-180


　　AX12-200


　　Single voltage


　　12V


　　Rated Capacity


　　（25℃）


　　18AH


　　26AH


　　33AH


　　45Ah


　　60Ah


　　75Ah


　　100Ah


　　120AH


　　150AH


　　180AH


　　200AH


　　Internal resistance(mΩ)


　　10.0


　　8.0


　　9.0


　　7.0


　　6.5


　　6.0


　　5.0


　　4.5


　　4.0


　　4.0


　　3.8


　　Single


　　size


　　Length


　　(mm)


　　181


　　166


　　195


　　198


　　260


　　260


　　308


　　408


　　485


　　530


　　522


　　width


　　(mm)


　　77


　　175


　　130


　　166


　　170


　　170


　　170


　　177


　　170


　　210


　　240


　　height


　　(mm)


　　168


　　125


　　180


　　170


　　185


　　235


　　215


　　225


　　240


　　215


　　225


　　weight(kg)


　　5.9


　　9.0


　　10.2


　　14.6


　　20.2


　　23.5


　　30


　　36.5


　　47.0


　　53.0


　　63.0


　　Short circuit current


　　(A)


　　900


　　900


　　1150


　　1250


　　1450


　　1750


　　2300


　　2420


　　2950


　　3350


　　3750


　　Maximum discharge


　　Current(A)


　　180


　　260


　　330


　　450


　　600


　　765


　　1025


　　1200


　　1510


　　1850


　　2100


　　Maximum charge current(A)


　　3.6


　　5.2


　　6.6


　　9


　　12


　　15


　　20


　　24


　　30


　　36


　　40


　　Charging voltage：Temperature:25℃,float:13.62V;fast charge:14.2V


　　proper temperature：-10℃～40℃


　　Recommended temperature:20℃~25℃


　　Number of deep cycle discharges：More than 1200 times 50%DOD;more than 800 times 80%DOD


　　Terminal


　　M5


　　M5


　　M6


　　M6


　　M6


　　M6


　　M8


　　M8


　　M8


　　M8


　　M8



index



　　Detailed description


　　Hawker AGV Safe series of lead-acid battery charger is a high-frequency switching power supply as the core,the main power converter using high-frequency high-permeability nanocrystalline transformers,microcomputer control of intelligent automatic charger.


　　High-tech applications,improve the efficiency of the whole conversion.Products with high efficiency,energy saving significant features,compared to traditional charger energy saving 20%-30%.


　　This series of microcomputer computer built-in a variety of battery charging program,accurate simulation of different types of battery charging curve.Choose a different charging program,can AGM,colloid,semi-colloidal and rich liquid water and other lead-acid batteries to charge.


　　The charging system consists of the charger and the charged battery to form a binary closed loop circuit.The dU/dt and dI/dt techniques are used to dynamically track the battery to accept the current.The microcomputer automatically determines the parameters of the on-line charging program according to the status of the battery,controls the output current and voltage Charging time,the charging current from the beginning to the end of the battery in the vicinity of the acceptable charge current curve,so that the battery almost no gas precipitation conditions.Not only save electricity,to achieve rapid charging,but also no damage to the battery to extend battery life.Current output is the pulse current mode,improve the battery charging capacity,reduce the concentration of polarization,electrochemical polarization,reduce gas generation.This is a very important way to reduce the battery temperature rise,reduce the battery plate deformation,reduce the gas flushing plate,reduce the active material off.


　　This series of charger with anti-battery reverse,the output short circuit,the output overload protection.Also has the function of automatic switch machine,can be connected to long-term input power.Need to charge,connect the battery pack,the charger work;no charge,disconnect the battery pack,the charger to stop working,the operation is very simple,user-friendly.


　　Hawker AGV Safe intelligent automatic lead-acid battery charger is a high reliability,high stability of the new energy-saving lead-acid battery charger.


　　Specifications Model


　　Product model


　　Charging mode


　　Charging voltage/current


　　Battery capacity


　　Outline size


　　Net weight


　　Input power


　　Cell voltage


　　Ah


　　W*H*L(mm)


　　Kg


　　TP4-24


　　Three stage constant current


　　24V/4A


　　20-40


　　195*150*340


　　7


　　1Ф220VAC


　　TP8-24


　　Three stage constant current


　　24V/8A


　　45-70


　　195*150*340


　　7


　　1Ф220VAC


　　TP15-24


　　Three stage constant current


　　24V/13A


　　60-100


　　195*150*340


　　7


　　1Ф220VAC


　　TP20-24


　　Three stage constant current


　　24V/20A


　　100-150


　　195*150*340


　　7


　　1Ф220VAC


　　TP25-24


　　Three stage constant current


　　24V/25A


　　150-210


　　195*150*340


　　7


　　1Ф220VAC


　　TP30-24


　　Three stage constant current


　　24V/30A


　　180-250


　　195*150*340


　　8


　　1Ф220VAC


　　TP35-24


　　Three stage constant current


　　24V/35A


　　240-320


　　200*160*360


　　9


　　1Ф220VAC


　　TP15-48


　　Three stage constant current


　　48V/13A


　　60-100


　　195*150*340


　　7


　　1Ф220VAC


　　TP20-48


　　Three stage constant current


　　48V/20A


　　100-150


　　195*150*340


　　8


　　1Ф220VAC


　　TP25-48


　　Three stage constant current


　　48V/25A


　　150-210


　　195*150*340


　　9


　　1Ф220VAC


　　TP30-48


　　Three stage constant current


　　48V/30A


　　180-250


　　200*160*360


　　9


　　1Ф220VAC


　　TP40-48


　　Three stage constant current


　　48V/40A


　　240-320


　　200*160*360


　　10


　　1Ф220VAC


　　TP50-48


　　Three stage constant current


　　48V/50A


　　360-420


　　265*180*420


　　15


　　1Ф220VAC


　　TP15-72


　　Three stage constant current


　　72V/13A


　　60-100


　　195*150*340


　　8


　　1Ф220VAC


　　TP20-72


　　Three stage constant current


　　72V/20A


　　100-150


　　195*150*340


　　9


　　1Ф220VAC


　　TP25-72


　　Three stage constant current


　　72V/25A


　　150-210


　　200*160*360


　　10


　　1Ф220VAC


　　TP30-72


　　Three stage constant current


　　72V/30A


　　180-250


　　200*160*360


　　12


　　1Ф220VAC


　　TP15-96


　　Three stage constant current


　　96V/13A


　　60-100


　　195*150*340


　　8


　　1Ф220VAC


　　TP20-96


　　Three stage constant current


　　96V/20A


　　100-150


　　200*160*360


　　10


　　1Ф220VAC


　　TP25-96


　　Three stage constant current


　　96V/25A


　　150-210


　　265*180*420


　　15


　　1Ф220VAC


　　Protection characteristics


　　Overheating protection:when the internal temperature of the charger is over 75 degrees,the charger can be shutdown and the temperature will drop automatically to recharge the battery.


　　•short-circuit protection:when the charger output unexpected short circuit,the charger automatically shut down the output,after troubleshooting,delayed 10 seconds,restart charging.


　　Overheating protection:when the internal temperature of the charger is over 75 degrees,the charger can be shutdown and the temperature will drop automatically to recharge the battery.


　　•short-circuit protection:when the charger output unexpected short circuit,the charger automatically shut down the output,after troubleshooting,delayed 10 seconds,restart charging.


　　Technical index


　　Rated input voltage:AC220V+15%


　　•rated frequency:45~65 Hz


　　Battery voltage:24V/48V/72V/96V and so on


　　The full load efficiency:93%


　　•maximum charging current:4,8,13,20,25A,etc.


　　The average charge and floating charge:automatically


　　Battery type:AGM,colloid,semi colloid and water rich water injection battery(charging program has been set at the factory.If you have to make a choice again,you need to do it under the guidance of a professional


　　Shutdown mode:automatic,or timer,or disconnect the charging plug,automatic shutdown


　　Cooling mode:forced air cooling


　　Display mode:LED digital meter,with LED light indication charging state


　　Mechanical shock and seismic rating:comply with SAEJ1378 requirements


　　Protection level:IP46


　　Operating temperature:-5 DEG C to+45 DEG C


　　Storage temperature:-30 DEG C to+70 DEG C


　　Charging control:temperature compensation control,never overcharge,lack of charge


　　Battery charging curve


　　Indicator light display


　　Red light-charging in progress.


　　The yellow light-the lights,the battery into floating state.When the yellow light is on,the capacity of the battery has reached 90%.After 2 hours,it reaches more than 96%.After 5 hours,it reaches more than 99%.


　　Light green-charging program complete.Battery capacity is more than 100%.


　　Display


　　Check the button in the panel:A-U-charge current,battery voltage,H charging time,charging C ah,E power.Button to see the parameters,the display automatically restores the charging current after 5 seconds.
