ABB CI856K01 3BSE026055R1 Communication Interface

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

ABB CI856K01 3BSE026055R1 Communication Interface thumbnail-1

ABB CI856K01 3BSE026055R1 Communication Interface thumbnail-2

ABB CI856K01 3BSE026055R1 Communication Interface photo-1

ABB CI856K01 3BSE026055R1 Communication Interface photo-2

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating Temperature -5℃ - +55℃

Power Supply 24V DC

Dimensions 110mm×160mm×60mm

I. Overview
ABB CI856K01 3BSE026055R1 is a communication interface module that plays a key role in the field of industrial automation. It is responsible for S100 I/O communication in ABB's AC 800M control system architecture. The module is connected to the CEX - Bus through the backplane, and this connection method provides a physical foundation for its stable operation. The ribbon connector on the backplane TP856 can be conveniently connected to the bus expansion board in the S100 I/O rack, and it also supports simple DIN rail mounting, bringing great convenience to equipment deployment. Its core function is to realize efficient data interaction between the AC 800M system and the S100 I/O system, enabling the control system to accurately obtain various information of on - site equipment and issue control commands in a timely manner. Through it, up to 5 S100 I/O racks can be connected to the same CI856 module, and each I/O rack can accommodate up to 20 I/O boards. This strong expansion capability greatly improves the compatibility and scalability of the system, meeting the needs of industrial automation projects of different scales.

II. Technical Parameters
Power supply mode: It is uniquely powered by the processor unit through the CEX bus. This design makes the module not need an additional external power supply, simplifies the system wiring, reduces the risk of faults caused by external power supplies, and also reduces the occupation of space in the control cabinet.
CEX bus connection capability: Up to 12 modules of this type can be connected to the CEX bus. This multi - module connection capability makes it possible to build large - scale and complex industrial automation systems, which can be flexibly configured according to the actual project needs to enhance the overall performance of the system.
Connector type: It adopts a miniribbon (36 - pin) connector. This connector has good electrical connection performance and mechanical stability, which can effectively ensure the reliability of data transmission and reduce interference and loss during signal transmission.
Power consumption: During operation, the typical current consumption at 24V voltage is 120mA, with low energy consumption. While meeting the communication function requirements, it will not cause too much burden on the system power supply, which helps to reduce the overall energy consumption of the system.
Operating temperature: The suitable operating temperature range is 0℃ to 55℃. Within this temperature range, the module can maintain stable performance and can adapt to the temperature changes in most conventional industrial environments.
Dimensions and weight: The module is approximately 18.5cm x 5.9cm x 12.75cm in size and weighs 0.7kg (including the packaging weight of 1.5kg). Its compact size and moderate weight facilitate the operation of installation and maintenance personnel, and it will not occupy too much space when installed in the control cabinet.

III. Functional Features
Hot - swap function: It supports the hot - swap feature, which means that during the operation of the system, maintenance personnel can directly replace the faulty module without stopping the machine. This function greatly improves the convenience and efficiency of system maintenance, avoids production stagnation caused by module failure shutdown, effectively reduces maintenance costs and time costs, and ensures the continuity and stability of the production system.
Code locking device: It is equipped with a code locking device, which can prevent the wrong installation of incompatible components and ensure the stability and reliability of the system from the hardware level. During the equipment installation and maintenance process, it effectively avoids system faults caused by the wrong installation of components due to misoperation and improves the overall safety of the system.
I/O system compatibility: It can seamlessly connect the AC 800M system and the S100 I/O system to realize efficient communication between devices of different architectures. This compatibility advantage enables enterprises to make full use of the existing S100 I/O equipment resources when upgrading or transforming the automation system, protect past investments, and at the same time integrate them into the advanced AC 800M control system to optimize equipment performance and improve system functions.
Strong expansion capability: It can connect up to 5 S100 I/O racks, and each rack can accommodate 20 I/O boards, providing a broad space for the expansion of the system's I/O points. Enterprises can flexibly add I/O equipment according to the expansion of production scale or changes in process requirements to meet the needs of monitoring and controlling more on - site equipment and improve the adaptability and flexibility of the system.

Product Tags: CI856K01 , 3BSE026055R1 , Processor Unit
