Yokogawa PW301 Power Module

Yokogawa PW301 Power Module photo-1
Yokogawa PW301 Power Module photo-2
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Efficiency ≥90% (at full load)
Operating Temperature -20℃~+60℃
Input Voltage AC 85-264V (50/60Hz)
Yokogawa PW301
I. Overview
The Yokogawa PW301 is a high-performance industrial power supply module introduced by Yokogawa, primarily designed to provide stable and reliable DC power for automation control systems, precision instruments, and industrial equipment. Focused on high reliability, high efficiency, and intelligent monitoring, it is suitable for scenarios with strict power stability requirements, such as petrochemical, power, metallurgy, and pharmaceutical industries. The module supports redundant configuration, forming a redundant system with other power modules to ensure continuous power supply during power anomalies and reduce system downtime risks. Additionally, the PW301 features stronger environmental adaptability and intelligent management functions, meeting the high requirements of modern industrial automation for power supplies.
II. Functional FeaturesHigh-Reliability Redundant Power Supply
  • Supports hot-swappable redundant configuration. The backup module automatically switches in when the main power supply fails, with a short switching time (millisecond-level) to ensure continuous system operation.

  • Adopts low-ripple and low-noise design, with high output voltage stability, suitable for precision equipment sensitive to power quality.

Multiple Intelligent Protection Mechanisms
  • Overload Protection: Real-time monitors load power, automatically limiting current or cutting off power when exceeding the rated value to prevent equipment damage.

  • Short-Circuit Protection: Immediately cuts off output when detecting output short-circuit to avoid burning the power module and backend equipment.

  • OverTemperature Protection: Equipped with a high-precision temperature sensor, automatically derating operation or alarming when overheated to prevent component aging.

  • Under-Voltage/Over-Voltage Protection: Adapts to power grid fluctuations, protecting internal circuits during abnormal input voltage.

Wide-Range Input and High-Efficiency Conversion
  • Supports wide-voltage input of AC 85-264V (compatible with global power grids) or DC input such as DC 24V/48V (optional for specific models).

  • Conversion efficiency exceeds 90%, reducing energy loss and heat dissipation requirements, suitable for long-term full-load operation.

Intelligent Monitoring and Communication
  • Equipped with multi-status LED indicators (power normal, fault, redundancy status, etc.) to intuitively display working status.

  • Supports communication interfaces such as RS-485 and Modbus, enabling upload of power status (voltage, current, temperature, fault information) to PLC or DCS systems for remote monitoring and early warning.

Flexible Installation and Environmental Adaptation
  • Supports 19-inch rack installation or DIN rail installation, adapting to standard industrial control cabinets for convenient installation and maintenance.

  • Wide temperature working range (-20℃~+60℃ for some models), adapting to harsh industrial environments, with built-in dust-proof design to extend service life.

PW301 (4)

III. Technical Parameters
Parameter TypeDetailed Indicators
Input Voltage- AC type: AC 85-264V (50/60Hz)
- DC type: DC 18-72V (e.g., optional DC 24V, DC 48V)
Output VoltageDC 24V (typical value, optional DC 12V, DC 48V), output current: 5A, 10A, 20A, 30A, etc.
Output Power100W~600W (varying by model)
Efficiency≥90% (at full load)
Operating Temperature-20℃~+60℃ (full load at -20℃~+50℃, derating required at +50℃~+60℃)
Protection ClassHousing IP20 (indoor use), internal moisture-proof and dust-proof design
Installation Method19-inch rack, DIN rail (supporting horizontal/vertical installation)
Communication InterfacesRS-485, Modbus RTU (optional), contact output (fault alarm)
IV. Working Principle
The Yokogawa PW301 is based on high-frequency switching power supply technology combined with intelligent control logic, with the working process as follows:
Input Voltage Processing
  • The AC input type converts AC to DC through a rectifier bridge, eliminating interference via EMI filtering; the DC input type directly stabilizes and filters the input voltage to ensure stable input.

High-Frequency Switching Conversion
  • Adopts PWM (Pulse Width Modulation) technology, converting DC voltage into high-frequency pulses (typically over 100kHz) via MOSFET or IGBT switching tubes. After step-down/step-up by a high-frequency transformer, smooth DC output is obtained through Schottky diode rectification and LC filter circuit.

Closed-Loop Voltage Stabilization Control
  • The output voltage is sampled by resistive voltage division, compared with the reference voltage, and the error signal adjusts the duty cycle of the switching tube via a PI controller to achieve precise stabilization of the output voltage (accuracy up to ±1%).

Redundancy and Protection Mechanisms
  • Redundancy Control: When multiple PW301 modules are connected in parallel, "main-backup current sharing" is achieved through redundant diodes or a dedicated controller, allowing the backup module to take over seamlessly when the main module fails.

  • Protection Logic: Sensors (current, temperature, voltage) real-time monitor status. In case of abnormalities, the control chip triggers the protection circuit to cut off output and send alarm signals via communication interfaces.

Intelligent Management
  • Built-in microprocessor real-time calculates power efficiency, load rate, and temperature trends, supporting parameter configuration (such as output voltage threshold, alarm delay time, etc.) via communication interfaces to enhance system management flexibility.

PW301 (2)

V. Common Faults and Solutions
Fault PhenomenonPossible CausesSolutions
No output voltage1. Input power not connected or voltage abnormal
2. Internal fuse blown
3. Main control chip failure
1. Check input power wiring and voltage with a multimeter
2. Replace the fuse with the same specification (if replaceable)
3. Contact the manufacturer for maintenance; avoid disassembling by oneself
Unstable output voltage1. Input voltage out of range
2. Aging filter capacitor
3. Excessive instantaneous load fluctuations
1. Check input power stability and install a voltage stabilizer if necessary
2. Replace capacitors by professionals
3. Inspect load equipment to eliminate poor contact or short circuit
Overload alarm1. Load power exceeds rated value
2. Output line short circuit
3. Abnormal current sharing in redundant system
1. Reduce load or replace with a high-power module
2. Detect lines with a multimeter to eliminate short-circuit points
3. Check redundant connection cables and configuration parameters
Module overheating1. Poor ventilation in installation environment
2. Dust accumulation or failure of cooling fan
3. Long-term full load with high ambient temperature
1. Ensure module spacing ≥5cm and install in a ventilated area
2. Clean fan dust, test fan rotation, and replace if necessary
3. Reduce load or install forced cooling devices
Communication abnormality1. Poor contact of communication cable
2. Incorrect baud rate/protocol configuration
3. Module communication chip failure
1. Check cable connection and replace with shielded cable
2. Reconfigure communication parameters referring to the manual
3. Contact technical support for module detection
Abnormal LED indicator1. Indicator damage (rare)
2. Internal hardware failure of module
3. Communication interruption between redundant modules
1. Confirm the meaning of indicators referring to the manual (e.g., flashing frequency represents fault type)
2. Power off and restart; if invalid, report for repair
3. Check connection cables and address settings of redundant modules
