Alloy 59 is a nickel-chromium-molybdenum alloy with high mechanical strength and excellent corrosion resistance. The alloy also possesses high resistance to stress corrosion cracking, chloride pitting and oxidizing and reducing media.
The following datasheet will provide more details about alloy 59.
Chemical CompositionThe following table shows the chemical composition of alloy 59.
| Element | Content (%) |
|---|---|
| Nickel, Ni | 56 - 63 |
| Chromium, Cr | 22 - 24 |
| Molybdenum, Mo | 15 - 16.5 |
| Iron, Fe | ≤1.5 |
| Manganese, Mn | ≤0.5 |
| Cobalt, Co | ≤0.3 |
| Aluminum, Al | 0.1-0.4 |
| Silicon, Si | ≤0.1 |
| Phosphorous, P | ≤0.015 |
| Carbon, C | ≤0.01 |
| Sulfur, S | ≤0.005 |
The physical properties of alloy 59 are outlined in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.6 g/cm³ | 0.311 lb/in³ |
The mechanical properties of alloy 59 are outlined in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength (@sheet and strip 0.5 to 6.4 mm) | 690 MPa | 100000 psi |
| Yield strength (@rod, bar, forgings > 100 mm) | 320 MPa | 46400 psi |
| Modulus of elasticity | 210 GPa | 30500 ksi |
| Elongation at break | 40% | 40% |
The thermal properties of alloy 59 are given in the following table.
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion coefficient (@20-100°C/68-212°F) | 11.9 µm/m°C | 6.61 µin/in°F |
| Thermal conductivity | 10.4 W/mK | 72.2 BTU in/hr.ft².°F |
The following are some of the major applications of alloy 59:
Flue gas scrubber components
Pulp and paper industry
Sulfuric acid coolers
Seawater equipment
Waste incinerators
Stock
Form |
Specification |
Supply Form |
Others |
Sheet |
Thickness:0.40-4.75mm,General Width:1000,1219,1500mm |
Whole Coil or piece of it |
Cold Annealed,Surface 2B,2E |
Plate |
Thickness:4.76-60mm,Width:1500,2000,2500mm,Length:3000,6000,8000,8500mm(Under 10mm plate can be coiled) |
Whole Coil or piece of it |
Single hot rolling,Solid solution annealed state,Surface 1D |
Belt |
Thickness:0.10-3.0mm,Width:50-500mm |
Whole Coil or Specified size |
Cold Annealed,Surface 2B,2E |
Bar & Rod |
Rolled barΦ5-45mm,Length≤1500mm |
Polished Bar(circle,Square) |
Solution annealing,descaling |
Forged barΦ26-245mm,Length≤4000mm | |||
Weld tube |
Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm |
Base on your requirement |
Use for PHE |
Seamless Tube |
Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm |
Base on your requirement |
Use for PHE |
Wire |
Outer diameterΦ0.1-13mm |
Base on your requirement |
Ni & Ni alloy, Ti & Ti alloy |
Forged piece |
roundness and square alloy |
Base on your requirement |
Steel, Alloy |
Flangs |
All kinds of Flangs |
Base on your requirement |
Steel, Alloy |
Welding Material |
Coil wire Φ0.90mm/1.2mm/1.6mm |
Base on your requirement |
Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France. |
Straight WireΦ1.2mm/1.6mm/2.4mm/3.2mm/4.0mm | |||
Welding rodΦ2.4mm/3.2mm/4.0mm | |||
Tube |
Elbow, three links, four links, different diameter size |
Base on your requirement |
Ni & Ni alloy, Ti & Ti alloy |
Explosive bonded laminate |
Raw Sheet Thickness≥2mm |
Base on your requirement |
Ni & Ni alloy, Ti & Ti alloy |
