Help CenterYS-730D Dry Microbial Penetration Tester
Related Products
-
YS-227K Medical Mask Synthetic Blood Penetration TesterUS$ 3000.00 - 6000.00MOQ: 1 Unit -
YS-227Y Bacteriophage Penetration Tester (4-Station)US$ 6200.00 - 15000.00MOQ: 1 Unit
-
YS-730W Wet Microbial Penetration TesterUS$ 3000.00 - 6000.00MOQ: 1 Unit
-
YS-227Y Medical Protective Clothing Synthetic Blood Penetration Tester (4-Station)US$ 6200.00 - 12600.00MOQ: 1 Unit
-
YS-227Y Medical Protective Clothing Synthetic Blood Penetration Tester (Single Station)US$ 2500.00 - 6000.00MOQ: 1 Unit
【Scope of Application】:
Bacteria can penetrate barrier materials via dry organic/inorganic particles (e.g., bacteria-carrying skin flakes through surgical gowns, or particles through packaging). This tester determines material resistance to penetration by bacteria carried on dry particles within the size range of human skin flakes.
【Compliant Standards】:
1. ISO 22612 Protective clothing — Protection against infectious agents — Test method for resistance to dry microbial penetration
2. YY/T 0506.5-2009 Surgical drapes, gowns and clean air suits for patients, clinical staff and equipment — Part 5: Test method for resistance to dry microbial penetration
【Instrument Features】:
1. Biosafety cabinet provides sterile, particle-free workspace.
2. Equipped with lighting and UV sterilization.
3. Reliable, stable testing; low noise (≤65dB).
4. Front-opening glass door for easy operation/observation.
5. Removable stand; adjustable feet + 4 auxiliary casters for mobility.
6. Biosafety cabinet exhaust system; HEPA inlet/outlet for safety.
7. Fully touchscreen interface; user-friendly.
8. Stainless steel test vessels; easy cleaning.
【Technical Parameters】:
1. Workbench
1.1. Vibration type: Pneumatic ball vibrator
1.2. Frequency: 20,800 times/min (347Hz)
1.3. Force: 650N
1.4. Max particle concentration: 3,500 particles/L (≥0.5μm)
1.5. Size: 40x40cm
1.6. Material: Marble slab
1.7. Test vessel: Stainless steel
1.8. Test stations: 6
1.9. Filter: >99.99% efficiency
2. Biosafety Cabinet
2.1. Provides localized particle-free/sterile workspace; controlled exhaust filtration.
2.2. Fluorescent lamps: 18W x 3
2.3. UV lamp: 20W x 1
2.4. Airflow velocity: ≥0.3–0.5±0.025m/s
2.5. Dimensions: 1000x800x2040mm (WxDxH) (two-piece)
2.6. Weight: ~190kg
2.7. Air source: ≥0.8MPa
2.8. Power: AC220V, 50Hz
