| Parameter | Details |
|---|---|
| Alloy Name | Hastelloy C-2000 |
| UNS Number | N06200 |
| Material Type | Nickel-Based Corrosion-Resistant Alloy |
| Product Form | Pipe / Tube (Seamless & Welded) |
| Standards | ASTM B619, ASTM B622, ASTM B626, ASME SB-622 |
| Chemical Composition | Ni (Nickel): Balance Cr (Chromium): 22.0-24.0% Mo (Molybdenum): 15.0-17.0% Cu (Copper): 1.3-1.9% Fe (Iron): 3.0-6.0% Co, Mn, Si, C, P, S: Trace amounts |
| Outer Diameter (OD) | 6 mm - 500 mm (customizable) |
| Wall Thickness | 0.5 mm - 50 mm (customizable) |
| Length | Up to 12 meters (custom lengths available) |
| Surface Finish | Annealed, Pickled, Polished |
| Density | 8.50 g/cm³ |
| Melting Point | 1325-1370°C |
| Tensile Strength | ≥ 690 MPa |
| Yield Strength | ≥ 283 MPa |
| Elongation | ≥ 40% |
| Corrosion Resistance | Exceptional resistance to both oxidizing and reducing environments, including sulfuric acid, hydrochloric acid, and ferric/ cupric chlorides |
| Applications | Chemical Processing, Marine Industry, Pollution Control, Pulp & Paper Industry, Power Plants, Pharmaceutical Industry, Heat Exchangers |
Broad-Spectrum Corrosion Resistance:
Designed to withstand both oxidizing and reducing environments, making it superior to other Hastelloy grades like C-276 and C-22.Exceptional Acid Resistance:
Outstanding performance in sulfuric acid, hydrochloric acid, and phosphoric acid environments, even at high concentrations and temperatures.Copper Addition for Enhanced Performance:
The addition of copper improves resistance to sulfuric acid and mixed acid systems, where traditional nickel alloys may struggle.Pitting and Crevice Corrosion Resistance:
Highly resistant to localized corrosion such as pitting, crevice corrosion, and stress corrosion cracking (SCC), especially in chloride-rich environments.High Thermal Stability:
Maintains mechanical strength and corrosion resistance at elevated temperatures, suitable for heat exchangers and reactors.
Chemical Processing Plants: Reactors, storage tanks, and heat exchangers
Marine Environments: Piping systems exposed to seawater and harsh chemicals
Pollution Control Equipment: Scrubbers, ducting, and stack liners
Pharmaceutical & Food Processing: Corrosion-resistant piping and vessels
Power Generation: Heat recovery steam generators and condensers
Hastelloy grades: Hastelloy C276, Hastelloy C22, Hastelloy C-2000, Hastelloy C-4, Hastelloy C, Hastelloy B, Hastelloy B-2, Hastelloy B-3, Hastelloy X, Hastelloy G-30, Hastelloy G-35, etc.
| Hastelloy | ||||||||||||
| Grade | Ni | Cr | Fe | Mo | W | Co | C | Mn | Si | S | P | Other |
| C-276 | Rom | 15-16.5 | 4-7 | 15-17 | 3-4.5 | 2.5 | 0.01 | 1 | 0.08 | 0.001 | 0.015 | v0.1-0.3 |
| C-22 | 56-59 | 20-22.5 | 2-6 | 12.5-14.5 | 2.5-3.5 | 2.5 | 0.015 | 0.5 | 0.08 | 0.02 | v0.35 | |
| C-2000 | Rom | 22-24 | 3 | 15-17 | 2 | 0..01 | 0.5 | 0.06 | 0.01 | 0.025 | Al0.5 Cu1.6 | |
| B-2 | Rom | 0.4-0.7 | 1.6-2 | 26-30 | 1 | 0.01 | 1 | 0.08 | 0.01 | 0.02 | Cu0.5 | |
| B-3 | 64 | 1-3 | 1-3 | 27-32 | 3 | 3 | 0.01 | 3 | 0.1 | 0.01 | 0.03 | v0.2 Al0.5 Ti0.2 Cu0.2 |
| G-30 | Rom | 28-31.5 | 13-17 | 4-6 | 1.5-4 | ≤5 | 0..03 | ≤2 | ≤1 | ≤0.02 | ≤0.04 | Nb/Ta0.3-1.5 Cu1-2.4 |
| X | Rom | 20.5-23.5 | 17-20 | 8-10 | 0.2-1 | 0.5-2.5 | 0.05-0.15 | 1 | 1 | 0.015 | 0.025 | Al0.5 Ti0.15 B0.005 |
| C-4 | Rom | 14-18 | 3 | 14-17 | 2 | 0.015 | 1 | 0.08 | 0.7 | 0.04 | Ti0.7 | |
| G-35 | 8-10 | 5 | 33 | 2 | 0.03 | 2-3 | 1.5 | 1 | 2 | 0.02 | Cu0.04 | |
| C | Rom | 14.5-17.5 | 4-7 | 15-17 | 3-4.5 | 0.03 | 1 | 0.03 | 0.04 | |||
| Hastelloy | Density g/cm3 | Melting point ºC | Elongation A5 % | Tensile Strength Rm N/mm2 | Yield Strength RP0.2N/mm2 |
| C-276 | 8.9 | 1325-1370ºC | 62 | 758 | 363 |
| C-22 | 8.9 | 1325-1370ºC | 40 | 690 | 283 |
| C-2000 | 8.5 | 1399ºC 2550°F | 45 | 690 | 283 |
| B-2 | 9.2 | 1330-1380ºC | 40 | 745 | 325 |
| B-3 | 9.22 | 1370-1418ºC | 40 | 760 | 350 |
| G-30 | 8.22 | 1399ºC 2550°F | 62 | 524 | 200 |
| X | 8.3 | 1260-1355ºC | 30 | 690 | / |
| C-4 | 8.64 | 399°C 2550°F | 40 | 690 | 280 |
| G-35 | 8.22 | 1370-1400ºC | / | / | / |
| C | 8.94 | 1330-1380 ºC | 40 | 690 | 310 |
