HASTELLOY C-2000 alloy (UNS N06200) is unique among the versatile nickel-chromium-molybdenum materials in having a deliberate copper addition. This provides greatly enhanced resistance to sulfuric acid. It also has a high chromium content, to maximize its resistance to oxidizing chemicals and process streams contaminated with ferric ions and dissolved oxygen.
Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). It is able to withstand a wide range of oxidizing and non-oxidizing chemicals, and exhibits outstanding resistance to pitting and crevice attack in the presence of chlorides and other halides.
HASTELLOY C-2000 alloy is available in the form of plates, sheets, strips, billets, bars, wires, pipes, tubes, and covered electrodes. Typical chemical process industry (CPI) applications include reactors and heat exchangers.
Composition
The chemical composition of stainless steel grade Hastelloy C-2000 is outlined in the following table.
| Element | Min % | Max % |
| Cr | 22.00 | 24.00 |
| Mo | 15.00 | 17.00 |
| Fe | - | 3.00 |
| C | - | 0.01 |
| Si | - | 0.08 |
| Co | - | 2.00 |
| Mn | - | 0.50 |
| P | - | 0.025 |
| S | - | 0.01 |
| Cu | 1.30 | 1.90 |
| Al | - | 0.50 |
| Ni | bal |
Grade Specification
| Grade | UNS | DIN | EN | AMS | ASTM | JIS | |
| Hastelloy C-2000 | N06200 | 2.4675 | ASTM B574 ASTM B575 ASTM B619 |
- | |||
HASTELLOY C-2000 alloy is very amenable to the Gas Metal Arc (GMA/MIG), Gas Tungsten Arc (GTA/TIG), and Shielded Metal Arc (SMA/Stick) welding processes.
Wrought products of HASTELLOY C-2000 alloy are supplied in the Mill Annealed (MA) condition, unless otherwise specified. This solution annealing procedure has been designed to optimize the alloy's corrosion resistance and ductility. Following all hot forming operations, the material should be re-annealed, to restore optimum properties. The alloy should also be re-annealed after any cold forming operations that result in an outer fiber elongation of 7% or more. The annealing temperature for HASTELLOY C-2000 alloy is 1149°C (2100°F), and water quenching is advised (rapid air cooling is feasible with structures thinner than 10 mm (0.375 in). A hold time at the annealing temperature of 10 to 30 minutes is recommended, depending on the thickness of the structure (thicker structures need the full 30 minutes).
HASTELLOY C-2000 alloy can be hot forged, hot rolled, hot upset, hot extruded, and hot formed. However, it is more sensitive to strain and strain rates than the austenitic stainless steels, and the hot working temperature range is quite narrow. For example, the recommended start temperature for hot forging is 1232°C (2250°F) and the recommended finish temperature is 954°C (1750°F). Moderate reductions and frequent re-heating provide the best results, as described here. This reference also provides guidelines for cold forming, spinning, drop hammering, punching, and shearing. The alloy is stiffer than most austenitic stainless steels, and more energy is required during cold forming. Also, HASTELLOY C-2000 alloy work hardens more readily than most austenitic stainless steels, and may require several stages of cold work, with intermediate anneals.
While cold work does not usually affect the resistance of HASTELLOY C-2000 alloy to general corrosion, and to chloride-induced pitting and crevice attack, it can affect resistance to stress corrosion cracking. For optimum corrosion performance, therefore, the re-annealing of cold worked parts (following an outer fiber elongation of 7% or more) is important.
Physical Properties
The physical properties of Hastelloy(r) C-2000(r) are highlighted in the following table.
| Properties | Metric | Imperial |
| Density | 8.50 g/cm³ | 0.307 lb/in³ |
Mechanical Properties
The mechanical properties of Hastelloy(r) C-2000(r) flat products are given in the following table.
| Properties | Metric | Imperial |
| Tensile strength (@ thickness 25.4 mm/ 1.00 in.) | 752 MPa | 109000 psi |
| Yield strength (@ 20°C/ 68°F, thickness 12.7 mm/0.5000 in, 0.2% offset) | 345 MPa | 50000 psi |
| Elongation at break (@ thickness 6.35 mm/0.250 in., in 50.8 mm) | 62% | 62% |
| Seamless Pipe & Tube | Welded Pipe & Tube | Fittings | Billet, Rod and Bar | Forgings | Plate, Sheet and Strip |
| ASTM B622 | ASTM B619 ASTM B626 |
ASTM B366 ASTM B462 |
ASTM B574 | ASTM B564 ASTM B462 |
ASTM B575 |
Applications
Flare tips
Fluidized bed coal combustors
Radiant tubes
Tube hangers for petroleum refining and steam boilers
Coal gasifier internal components
Thermowells and refractory anchor bolts
Burners, combustion chambers
Retorts, muffles, annealing covers
Cryogenic structures
