TRICONEX 9662-610 Analog Output Module

TRICONEX 9662-610 Analog output module

Performance advantage

High-precision output: Typically featuring 16-bit resolution, it can achieve precise analog output, with an output accuracy of approximately ±0.1% FSR (full scale). It can precisely output analog signals to on-site equipment, ensuring the control accuracy of the actuator. For instance, in chemical production, it can precisely control the opening degree of the regulating valve, meeting the high-precision requirements for parameter control in complex processes.

Multi-channel independent output: Generally, there are 8 output channels. Each channel can be configured and controlled independently, and the channels are isolated from each other, which can effectively reduce the interference between channels. It can simultaneously provide independent analog control signals for multiple field devices and is suitable for complex systems that require the coordinated control of multiple parameters.

High reliability: As a product of the TRICONEX series, it inherits the brand's feature of high reliability. The module adopts a robust hardware design and has excellent anti-interference capability, enabling stable operation in harsh industrial environments such as high temperatures, high humidity, and strong electromagnetic interference. It also supports hot-swappable function, facilitating maintenance and replacement during system operation without affecting the normal operation of the entire system.

Self-diagnosis of faults: It has the function of self-diagnosis of faults, which can monitor the working status of the module in real time. When a fault occurs, it can promptly issue an alarm signal, facilitating maintenance personnel to quickly locate and eliminate the fault, improving the availability of the system and maintenance efficiency, and reducing downtime.

Multiple output ranges are available: It can provide multiple output ranges, such as 4-20mA current signal or 0-10V voltage signal, etc., which can meet the control requirements of different on-site equipment and have strong compatibility.

Good communication compatibility: Supports multiple bus protocols, such as EtherCAT, Profinet-RT, Modbus-RTU, Modbus-TCP /IP, etc., facilitating integration with PLCS or upper computer systems of different brands, and can be flexibly integrated into various industrial automation control systems.

Functional features: This module is mainly used to convert the digital signals output by the control system into analog signals to drive the on-site actuators, such as control valves and frequency converters. It usually has a high-precision analog output capability and can provide multiple output ranges, such as the common 4-20mA current signal or 0-10V voltage signal, etc., which can meet the control requirements of different field devices.

Technical parameters: Generally, it has a resolution of 16 bits or higher, capable of achieving precise analog output, and the output accuracy usually reaches around ±0.1% FSR (full scale). It has multiple independent output channels. Commonly, there are 8 output channels. Each channel can be configured and controlled independently, and the channels are isolated from each other, which can effectively reduce the interference between channels.

Application scenarios: Mainly applied in safety instrumented systems (SIS) and distributed control systems (DCS) in industries such as petroleum, chemical engineering, power, and metallurgy. For example, in petrochemical production, the temperature and pressure regulating valves that can be used to control the reaction vessels can precisely adjust the valve opening according to the process requirements to ensure the stability and safety of the production process. In power systems, it can be used to control the excitation system of generators and regulate the output voltage of generators, etc.
