Bottom loading composite hose is widely used in the applications of bottom loading production refinery and bulk distribution. And bottom loading composite hose is the best choice for handling lightweight distillates, including gasoline, aromatics, MTBE, MEK and so on. However, it cannot be used for chemicals which are corrosive and aggressive. You can use our chemical composite hose to handle chemicals.
The structure of bottom loading composite hose
Bottom loading composite hose is composed of five parts: inner wire, outer wire, liner, carcass and cover.
Inner wire: galvanized mild steel.
Outer wire: galvanized mild steel.
Liner: polypropylene and polyester.
Carcass: multiple layers of polypropylene fabric and film.
Cover: abrasion resistant PVC coated fabric.
Features of bottom loading composite hose:
Lightweight and easy to operate.
Excellent flexibility.
Outstanding durability.
The details of bottom loading composite hose:
Temperature range: -22°F to +212°F (-30°C to +100°C).
Inner diameter: 1", 1.5", 2", 2.5", 3", 4", 6", 8" and 10".
Outside diameter: 1.5", 2", 2.5", 3", 3.5", 4.5", 5", 7", 9.5" and 11.5".
Bend radius: 4", 5.5", 7", 8", 11", 15.5", 16", 20", 30" and 36".
Working pressure: 200psi or 150psi.
Standard length: 60ft and 40ft.
The specification of bottom loading composite hose
ID |
OD |
Bend radius |
Weight |
Working pressure |
Standard length |
Available length |
inch |
inch |
inch |
lb/ft |
psi |
ft |
ft |
1 |
1.5 |
4 |
0.5 |
200 |
60 |
80 |
1.5 |
2 |
5.5 |
0.8 |
200 |
60 |
80 |
2 |
2.5 |
7 |
1.3 |
200 |
60 |
80 |
2.5 |
3 |
8 |
1.7 |
200 |
60 |
80 |
3 |
3.5 |
11 |
2.0 |
200 |
60 |
80 |
3 |
4.5 |
11 |
3.0 |
200 |
60 |
80 |
4 |
4.5 |
15.5 |
3.5 |
200 |
60 |
80 |
4 |
5 |
16 |
4.3 |
200 |
60 |
80 |
6 |
7 |
20 |
7.2 |
200 |
60 |
100 |
8 |
9.5 |
30 |
10.0 |
200 |
60 |
80 |
10 |
11.5 |
36 |
13.7 |
150 |
40 |
50 |
Application of bottom loading composite hose:
Bottom loading composite hose is suitable for handling lightweight distillates, including gasoline, aromatics, MTBE, MEK and so on.
