Clear Laminated Glass

Clear Laminated Glass

Clear PVB (Polyvinyl Butyral) Laminated Glass is a type of safety glass made by sandwiching a layer of PVB resin between two or more layers of glass under heat and pressure. This process bonds the layers together, creating a durable and impact-resistant material.

PVB Thickness

The thickness of the PVB interlayer in laminated glass varies depending on the application, safety requirements, and performance needs (such as impact resistance, sound insulation, or UV protection). Here are the standard PVB thickness options and their typical uses:

Standard PVB Thickness Options:

1) 0.38 mm (15 mils)

① Commonly used in automotive windshields (usually two layers, totaling 0.76 mm).

② Basic safety glass for architectural applications.

2) 0.76 mm (30 mils, most common)

① Standard for architectural laminated glass (e.g., windows, facades, railings).

② Balances safety, clarity, and cost-effectiveness.

3) 1.14 mm (45 mils)

① Used for enhanced impact resistance (e.g., hurricane-prone areas, security glazing).

② Better sound insulation than 0.76 mm.

4) 1.52 mm (60 mils) and above

①High-security applications (e.g., banks, bullet-resistant glass when combined with multiple layers).

② Acoustic glass for superior noise reduction.

Multi-Layer PVB Configurations:

1) For bulletproof or blast-resistant glass, multiple PVB layers (e.g., 2.28 mm, 3.04 mm) are used between glass panes.

2) Acoustic PVB (specialized sound-dampening interlayers) may vary in thickness for better noise control.

Composition & Manufacturing:

1) Tempered Glass: The glass is heat-treated (tempered) to increase its strength (4-5 times stronger than regular glass). When broken, it shatters into small, blunt pieces (safer than sharp shards).

 2) Laminated Glass: Two or more layers of tempered glass are bonded together with a durable interlayer (usually PVB - Polyvinyl Butyral or EVA - Ethylene Vinyl Acetate), creating a strong, cohesive unit.

Glass Thickness

Total thickness: 6.38-17.52mm

Glass thickness details:

5+0.38pvb+5mm;  6+0.38pvb+6mm;

5+0.76pvb+5mm;  6+0.76pvb+6mm etc.

PVB Thickness

0.38mm, 0.76mm, 1.14mm, 1.52mm etc.

Key Features of PVB Laminated Glass:

1) Safety & Security:

① If broken, the glass fragments adhere to the PVB interlayer, reducing the risk of injury from sharp shards.

② Provides resistance against forced entry and vandalism.

2) Sound Insulation:

The PVB layer dampens sound, making it ideal for noise reduction in buildings near highways or airports.

3) UV Protection:

Blocks up to 99% of harmful UV rays, protecting interiors (furniture, flooring, etc.) from fading.

4) Structural Strength:

More resistant to wind, impact, and blast pressures compared to standard glass.

5) Design Flexibility:

Available in various tints, colors, and thicknesses; can be combined with tempered or heat-strengthened glass.
