Overview
G9 fresh air system intelligent controller can monitor indoor temperature and humidity, PM2.5, CO2 (optional), VOC (optional), simulated formaldehyde (optional) and other data in real time; WIFI can be connected (optional); With ModBus RTU (RS485) interface, users can connect to smart home and other background monitoring equipment status through ModBus interface; 0-10V voltage signal controls the start and speed of the fan, It can be widely used in residential, commercial and industrial occasions, and can effectively improve air quality to create a healthy, comfortable, efficient, environment-friendly and energy-saving living and working environment.
Technical parameter:
* Dimension: 86×86×40mm
* Warm-up time: 2 minutes
* Fixing hole distance: 60mm(standard)
* Response time: ≤10 seconds
* Wiring terminal: Max 2.5 mm2 wire
* Recovery time: ≤30 seconds
* Rated voltage: AC220V, 50/60Hz
* Operation temperature: -10℃ --- +50℃
* Standby Power: ≤2.0W
* Operating humidity: 5％RH——90％RH(No condensation)
* Control Power: about 200W
* Storage temperature: -10℃ --- +60℃
* Output interface: 3 speed fan
* Storage humidity: ≤60％RH
* Temperature display range: 0℃— 99℃
*Life: ≥ 3 years
* CO2 display range: 350ppm – 2000ppm (optional) * PM2.5 display range: 1ug/m3——999ug/m3
