2x4 Cascade Optical Switch

2x4 Cascade Optical Switch photo-1
2x4 Cascade Optical Switch photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Glsun
Place of Origin:
China
Model Number:
SUN-FSW-2×4-A-B-C-D-E-F
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Glsun
Place of Origin China
Model Number SUN-FSW-2×4-A-B-C-D-E-F

SUN-FSW-2×4 Optical Switch is an ideal component for OADM, OXC, system monitoring and protection. With compact package, this fiber optic switch can be easy to integrate into a high density optical communication system.


Features
·Wide Wavelength Range
·Low Crosstalk
·High Stability, High Reliability
·Epoxy-free on Optical Path


Applications
·R&D in Laboratory
·System Monitoring
·OADM
·OXC

Specifications

Parameters

Unit

SUN-FSW-2×4

Wavelength Range

nm

850±40 / 1300±40

1260 ~ 1650

Test Wavelength

nm

850 / 1300

1310 / 1550

Insertion Loss

dB

Typ: 1.5   Max: 1.8

Return Loss

dB

MM ≥ 30   SM ≥ 50

Crosstalk

dB

MM ≥ 35   SM ≥ 55

PDL

dB

≤ 0.15

WDL

dB

≤ 0.35

Repeatability

dB

≤ ±0.05

Power Supply

V

5.0 ± 5%

Durability

Cycles

≥ 10 Million

Switching Time

ms

≤8

Optical Power

mW

≤500

Operating Temperature

-5 ~ +70

Storage Temperature

-40 ~ +85

Relative Humidity

%

5 ~ 95

Dimension

mm

(L)95×(W)76×(H)14 ±0.2

Optical Route

Ordering Information

SUN-FSW-2×4-A-B-C-D-E-F

A

B

C

D

E

F

Fiber Type

Switch Type

Test Wavelength

Tube Type

Fiber Length

(Include connector)

Connector

SM: SM, 9/125

M5:MM, 50/125

M6:MM, 62.5/125

X: Others

L: Latching

X: Others

850: 850nm

1310: 1310nm

1550: 1550nm

1310/1550:1310/1550nm

X:Others

90:900um

X: Others

05: 0.5m±5cm

10: 1.0m±5cm

15: 1.5m±5cm

X: Others

OO:None

FP: FC/PC

FA:FC/APC

SP: SC/PC

SA:SC/APC

STP:ST/PC

STA:ST/APC

LP: LC/PC

LA: LC/APC

X: Others

Product Tags: Module , Switch , 2x4 , OADM , OSW , Mechanical , Wavelength Range:850±40 / 1300±40; 1260 ~ 1650nm , OXC
